Quick connect nozzles
The color-coded quick connect nozzles
provide a wide array of spray widths
from 0° to 65° and are easily accessible
when placed in the convenient nozzle
holder.
0° spray angle = Red nozzle
For particularly stubborn accumulation
of grime. Not recommended for soft
materials like sidings, decks, painted
surfaces, cars.
25° spray angle = Green nozzle
For dirt accumulation over a large surface.
40° spray angle = White nozzle
For moderate dirt accumulation over a
large surface.
65° spray angle = Black detergent
nozzle
For operating with detergent or cleaning
with low pressure.
WARNING
High pressure in nozzle area.
Risk of injury caused by improperly
locked nozzle.
8
English

USING THE ACCESSORIES

Make sure you hear a 'click' when in-
serting the nozzle tip into the wand.
Pull the nozzle to make sure it is
seated properly before operating
your unit.
(See ASSEMBLY INSTRUCTIONS:
Step 6 and Step 7)
WARNING
To avoid serious injury never point
spray nozzle at yourself, other per-
sons or animals.
