Sequentix P3 SEQUENCER Operation Manual page 60

As you select a new group using the step keys, the group name will appear as an informational
message on the top line of the display.
You will get to know where the ones you like to use are found pretty quickly. Until then, keep this
page handy.
The complete list of the events in each group can be found in the later section, Using Auxiliary Events.
Selecting Controllers or Events
To select a controller or event from the group, use the DATA knob to scroll through the options, or use
the "next" soft-key, F2, to step through the group members one by one.
Once you have found the controller or event you wish to use, press the "save" soft-key, F1, to store the
assignment and exit the aux config page.
If you want to assign more than one aux at the same time, you can use the STEP MODE key to
advance to the next aux while in the aux config page.
Note that this will also save any changed assignment for the current aux.
For example, let's assume you have just entered pattern edit , and want to assign Aux A in the pattern
to send MIDI after -touch:
switch UPPER MODE to AUX
•
The quickest way to do this is to hold FUNC and press the STEP MODE button, the short-cut
mentioned before.
Alternatively, press UPPER MODE three times to select AUX.
hold FUNC and press STEP MODE to enter the aux config page
•
press step key 14, to select the "MIDI Send" group
•
This group contains three MIDI send functions - pitch-bend, after-touch and program change.
• either move the DATA knob or press the "next" soft-key, F2, until "send midi a/t" appears in
the top line of the display
press the "save" soft-key, F1
•
P3 will return to the normal pattern edit display, and you can set after-touch values to be sent on
whichever steps you want using the UPPER knobs.
