Controlling your camera

You can control the camera from the Call Control page.
The camera controls (pan, tilt, zoom) are available when
the cursor is placed in the Main Source video area. Live
snapshots are automatically taken during this period.
Note that the camera controls are not available if the system
is in standby mode.
D14908.08 SX20 Administrator Guide TC7.2, AUGUST 2014.
Introduction Web interface Web interface
Navigate to: Call Control
Pan and tilt
Use the left and right arrows
to pan the camera, and the up
and down arrows to tilt it.
System settings
www.cisco.com — Copyright © 2012-2014 Cisco Systems, Inc. All rights reserved.
17
Administrator Guide
Setting passwords Appendices
Choose which camera to control
Click the arrow to open the
drop-down list. Then choose the
camera you want to control.
Use + and - to zoom in and out.
Camera presets
If a camera preset is defined it is listed
here. Click the preset's name to move
the camera(s) to the preset position.
Click OK to close the window.
Zoom
