- Page 1 UseR MANUAl ViViana - ViViana Plus - dorina eNGlIsH/INGlese...
- Page 2 ENGLISH...
-
Page 3: Table Of Contents
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. enGLiSH .............................................. -
Page 4: English
Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. If it is damaged or lost, request another copy from the area technician. -
Page 5: Devices
devices TeRMs ANd deFiNiTioNs (in the relevant models) Aeration: Air renewal is required both for the disposal of the combustion products, and to prevent mixtures with a door micro switch: With the door open, the operation of the hazardous content of non-combusted gases. burn pot cleaning system is blocked closed hearth appliance: Appliance designed for operation with closed combustion chamber. -
Page 6: General
FUNcTioNAl oPeRATioNs diAgRAM State of the art installation and proper system operation include a series of activities: 1. Preliminary activities: Š Verification of the suitability of the power of the heat generator based on the characteristics of the system Š verification of the suitability of the installation site, Š... -
Page 7: Installation
iNsTAllATioN Installation in premises with fire hazards is forbidden. Installation in residential premises (except for sealed operation appliances) is also forbidden: Š in which there are liquid fuel-operated appliances with continuous or intermittent operation, which draw the combustion air in the room in which they are installed, or Š... -
Page 8: Fumes Exhaust System
veNTilATioN ANd AeRATioN oF The iNsTAllATioN PReMises Ventilation is deemed sufficient when the room is equipped with air inlets according to the table: Air inlet See figure 2 Percentage of the net opening section with Minimum net opening value of Appliance categories Reference standard respect to the appliance fumes... -
Page 9: Smoke Duct
Š nominal diameter; Š distance from combustible materials, indicated in millimetres, followed by the arrow and flame symbol; Š installer data and date of installation. Every time one must cross combustible materials, the following indications must be complied with: sYMbol descRiPTioN qUoTA[MM] Minimum distance of combustible materials from the intrados of the framework/floor/wall... - Page 10 Š counter-slope sections are not allowed; Š the smoke ducts must have, along their entire length, a diameter that is no less than that of the attachment of the appliance exhaust pipe; any section changes are allowed only on the inlet to the chimney; Š...
-
Page 11: Chimney
exAMPles oF coRRecT coNNecTioN To The chiMNeY Protection from rain Protection from rain and wind and wind Steel plate, airtight Max 3 mt 3 - 5% Insulated "T" fitting with inspection plug "T" fitting with "T" fitting with inspection plug inspection plug it is mandatory to use airtight pipes. -
Page 12: Fumes Exhaust System Product Requirements
coMbUsTioN PRodUcTs oUTleT qUoTA The outlet quota is determined by measuring the minimum height between the roof covering and the lower point of the fumes expulsion section into the atmosphere; this quota must be outside the reflux area and at an adequate distance from obstacles which hinder or make the expulsion of the combustion products difficult or from openings or accessible areas. -
Page 13: Technical Installation Documentation
coverings and finishings The coverings and finishings must only be applied after having verified the proper operation of the appliance according to the indicated modalities TechNicAl iNsTAllATioN docUMeNTATioN When installation is complete, the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... -
Page 14: Hot Air Ducting
TO DeaCTivaTe THe DuCTinG mOTOR. DO nOT COveR OR ClOse DuCTinG! DuCTinG OF THe viviana plus mODel CannOT be aDjusTeD. by DeFaulT iTs FunCTiOninG is paRallel TO FROnT venTilaTiOn. see THe FOllOwinG CHapTeR FOR iTs manaGemenT. -
Page 15: Pellets And Feeding
Pellets and feeding Pellets are made by applying high pressure to sawdust, or wood waste products (not containing paint) from sawmills, carpentry and other activities related to processing and working with wood. Given that it does not use any glue to hold it together this type of fuel is completely environmentally friendly. -
Page 16: The Display Description Of Controls And Symbols
The Display DescripTion of conTrols anD symbols ON/OFF Display OF variOUs Display BUTTON TexT messages OF pOwer OperaTiON pOwer TemperaTUre seTTiNg aDJUsTmeNT Display icons key indicates the presence of an alarm. it indicates weekly programming functioning On: indicates the presence of an alarm indicator on = weekly programming active Off: indicates the absence of alarms indicator off = weekly programming not active... -
Page 17: Menu Structure
menu sTrucTure Key 1 to confirm parameter/ programming and exit. Keys 2 and 3 to set data/parameters. Keys 4 and 5 to go forward or backward in the menu. To access the menu, keep key 5 pressed for a few seconds. seT clock 2 - 3 enable chrono... -
Page 18: Remote Control (Optional)
remoTe conTrol (opTional) The heating power, the desired room temperature and the appliance ignition/switch off, can be adjusted using the remote control. To ignite the stove, press key 1 for a few seconds; the appliance will automatically enter the ignition phase. it is possible to adjust power by using keys 4 and 5, whereas the desired temperature can be adjusted using keys 2 and 3. -
Page 19: Adjusting Time, Day, Month And Year
aDjusTinG Time, Day, monTh anD year set clock allows to adjust the time and date CONTrOls prOCeDUre press key 5 for a few seconds, until seT clock appears. Š Confirm using key 5. Š Use key 3 to select the day. Š... -
Page 20: Functioning And Logic
funcTioninG anD loGic iGniTion Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes are given for the ignition stage, after ignition and once the control temperature has been reached, the stove interrupts the ignition phase and switches to the sTarT-Up mode. -
Page 21: User Menu
clean check up 1 - 2 BUrN pOT BOTTOm shoulD The alarm "clean check up" be TriGGereD, make sure ThaT The boTTom of The burn poT is free from resiDues or scalinG. The holes aT The boTTom musT be compleTely free To GuaranTee correcT combusTion. -
Page 22: Reset
sTBy FUNCTiON seT aT ON if the stby function is active (ON), when the stove reaches the set room temperature and exceeds it by 2°C, it will switch off after a default delay time, displaying stand - by. when the room temperature is 2°C lower than the setting, the stove will start to work again at the power set on the display, displaying wOrK. -
Page 23: Programming Example
proGramminG example let's suppose that the weekly programmer function is to be used and the 2 time slots are to be used in the following way: - 1st time slot: from 08:00 to 12:00 every day of the week, with room temperature at 19°c, excluding saturday and sunday - 2nd time slot: from 15:00 to 22:00 only on saturday and sunday, with room temperature at 21°c 1sT Time slOT swiTCh-OFF... -
Page 24: Cleaning And Maintenance
CLEANING AND MAINTENANCE ALWAYS FOLLOW THE INSTRUCTIONS UNDER 100% SAFE CONDITIONS! Š Make sure the power cable's plug has been pulled out, as the generator might have been programmed to turn on. Š Make sure all the parts of the generator are cold. Š... - Page 25 DaILY ScraperS: Use the scrapers, moving upwards (for models with upper scrapers) or pulling and pushing them (for the inserts and models with front scrapers). please note: scrapers are preferably used when the stove is cold; if used when the stove is hot, it is recommended to use special gloves to protect against the heat as they can get very hot.
- Page 26 cLeanIng the burn pot anD combuStIon chamber 1. Vacuum the residues in the burn pot 2. Take out the burn pot from the designated compartment; 3. Vacuum the ash from the burn pot's seat and the combustion chamber (3.1) 4. Use the special poker supplied to clear the holes in the burn pot. 5.
- Page 27 everY 3/4 DaYS - weeKLY aSh Drawer Every 3-4 days check the ash drawer and empty it at least one/twice a week. If there is a lower door, open/remove it. Take out the removable ash drawer and empty it in a special container. Vacuum the area underneath the removable ash drawer.
- Page 28 cLeanIng the Lower Sump (IF there IS one) Some stove models have an inspection sump behind the ash drawer or underneath the combustion chamber. In this case, just open, remove the clamping screws and vacuum the ash inside. ENGLISH...
-
Page 29: Routine Maintenance Carried Out By Authorised Technicians
routIne maIntenance carrIeD out bY authorISeD technIcIanS routine maintenance must be performed at least once a year. As the generator uses pellets as solid fuel, it needs an annual routine maintenance interval that needs to be performed by an authorised technician by only using original spare parts. Failure to do so can affect the appliance's safety and you may no longer be entitled to the warranty conditions. - Page 30 The images are for illustration purposes. Fumes motor (disassembly and cleaning and fumes pipe), new silicone in required points Inspection of gaskets, ash drawer and burn pot door (replace them and apply silicone where required) Combustion chamber (total cleaning of the entire chamber) and ignition plug tube cleaning ...
- Page 31 The images are for illustration purposes. Fumes motor (disassembly and cleaning and fumes pipe), new silicone in required points Inspection of gaskets, ash drawer and burn pot door (replace them and apply silicone where required) Combustion chamber (total cleaning of the entire chamber) and ignition plug tube cleaning ...
-
Page 32: Displays
Displays Display Reason solution Stove off staRt The start phase is in progress pellet feeDing The feeding of the pellet during the ignition phase is in progress ignition The ignition phase is in progress staRt-up The start phase is in progress WoRk The normal work phase is in progress MoDulation... -
Page 33: Alarms
alaRMs Display explanation solution On: indicates the presence of an alarm Off: indicates the absence of alarms Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 1 for 3 seconds only if the fumes motor has stopped and if 15 minutes have passed from displaying the same alarm. - Page 34 ENGLISH...
- Page 35 ENGLISH...
- Page 36 +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com The Manufacturer reserves the right to vary the features and data shown in this booklet at any time and without prior notice, in order to improve its products. This manual cannot be considered as a contract for third parties.
