Summary of Contents for Extraflame VIVIANA EVO
- Page 1 UseR MANUAl VIVIANA EVO - VIVIANA PLUS EVO MADE ITALY design & production 004276730 - Rev 000 eNGlIsH/INGlese...
- Page 2 ENGLISH...
-
Page 3: Table Of Contents
attENtIoN SurfacES caN bEcoME VEry Hot! aLWayS uSE ProtEctIVE GLoVES! During combustion, thermal energy is released that significantly increases the heat of surfaces, doors, handles, controls, glass, exhaust pipes, and even the front of the appliance. Avoid contact with those elements if not wearing protective clothing (protective gloves included). -
Page 4: English
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. -
Page 5: Routine Maintenance
Š DO NOT LEAVE THE PACKAGING ELEMENTS WITHIN REACH OF CHILDREN OR UNASSISTED DISABLED PERSONS. Š THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL FUNCTIONING OF THE PRODUCT. Š WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH, ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID Š... -
Page 6: Installation
InstallatIon general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... - Page 7 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...
-
Page 8: Pellets And Feeding
Pellets and feeding Pellets are made by applying high pressure to sawdust, or wood waste products (not containing paint) from sawmills, carpentry and other activities related to processing and working with wood. Given that it does not use any glue to hold it together this type of fuel is completely environmentally friendly. -
Page 9: Hot Air Ducting
HOT AIR DUCTING Š The pipe destined for ducting the hot air must have an internal diameter of 80 mm, be insulated and protected from heat loss. Š The length must not exceed 6 metres. Š Installation of the pipes used for ducting the hot air must be performed by qualified staff and/or the manufacturer's technical after- sales assistance. -
Page 10: The Display Description Of Controls And Symbols
The Display DescripTion of conTrols anD symbols ON/OFF Display OF variOUs Display BUTTON TexT messages OF pOwer TemperaTUre seTTiNg OperaTiON pOwer aDJUsTmeNT Display icons key indicates the presence of an alarm. On: indicates the presence of an alarm it indicates weekly programming operation Off: indicates the absence of alarms indicator on = weekly programming active Flashing: indicates the deactivation of the depression... -
Page 11: Menu Structure
menu sTrucTure Key 1 to confirm parameter/ programming and exit. Keys 2 and 3 to set data/parameters. Keys 4 and 5 to go forward or backward in the menu. To access the menu, keep key 5 pressed for a few seconds. seT clock 2 - 3 enable chrono... -
Page 12: Remote Control (Optional)
remoTe conTrol (opTional) The heating power, the desired room temperature and the appliance ignition/switch off, can be adjusted using the remote control. To ignite the stove, press key 1 for a few seconds; the appliance will automatically enter the ignition phase. it is possible to adjust power by using keys 4 and 5, whereas the desired temperature can be adjusted using keys 2 and 3. -
Page 13: Adjusting Time, Day, Month And Year
aDjusTinG Time, Day, monTh anD year set clock allows to adjust the time and date CONTrOls prOCeDUre press key 5 for a few seconds, until seT clock appears. Š Confirm using key 5. Š Š Use key 3 to select the day. press key 5. -
Page 14: Functioning And Logic
funcTioninG anD loGic iGniTion Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes are given for the ignition stage, after ignition and once the control temperature has been reached, the stove interrupts the ignition phase and switches to the sTarTiNg mode. -
Page 15: Easy Setup
easy seTup The volumetric weight of the pellet is the ratio between the weight and the volume of the pellet. This ratio can change while maintaining the quality of the pellet. By using the easy seTUp function, it is possible to change the calibration of the volumetric weight, increasing or decreasing the pre-set values. -
Page 16: Reset
reseT allows all values that can be modified by the user to be reset to the default values. The modified data is the following: CONTrOls prOCeDUre press key 5 until seT clock appears. Š press key 3 several times until user appears. Š... -
Page 17: Programming Example
proGramminG example let's suppose that the weekly programmer function is to be used and the 2 time slots are to be used in the following way: - 1st time slot: from 08:00 to 12:00 every day of the week, with room temperature at 19°c, excluding saturday and sunday - 2nd time slot: from 15:00 to 22:00 only on saturday and sunday, with room temperature at 21°c 1sT Time slOT swiTCh-OFF sTop... -
Page 18: Cleaning And Maintenance
cLeanIng anD MaIntenance aLwaYS foLLow the InStructIonS In MaxIMuM SafetY conDItIonS! Š Make sue the power cable is unplugged since the generator could be programmed to start. Š That the generator is cold in its entirety. Š The ashes are completely cold. Š... - Page 19 Open the door - Clean the glass with a damp cloth Never spray the detergent or any other liquid used for cleaning directly on the ceramic glass cLeanIng the burn pot anD coMbuStIon chaMber 1. Vacuum the residues in the burn pot 2.
- Page 20 everY 3/4 DaYS - weekLY aSh Drawer Every 3-4 days check the ash drawer and empty it at least one/twice a week. If there is a lower door, open/remove it. Take out the removable ash drawer and empty it in a special container. Vacuum the area underneath the removable ash drawer.
- Page 21 ENGLISH...
-
Page 22: Routine Maintenance Carried Out By Authorised Technicians
routIne MaIntenance carrIeD out bY authorISeD technIcIanS routine maintenance must be performed at least once a year. As the generator uses pellets as solid fuel, it needs an annual routine maintenance interval that needs to be performed by an authorised technician by only using original spare parts. - Page 23 The images are for illustration purposes. Fumes motor (disassembly and cleaning and fumes pipe), new silicone in required points Inspection of gaskets, ash drawer and burn pot door (replace them and apply silicone where required) Combustion chamber (total cleaning of the entire chamber) and ignition plug tube cleaning ...
- Page 24 The images are for illustration purposes. Fumes motor (disassembly and cleaning and fumes pipe), new silicone in required points Inspection of gaskets, ash drawer and burn pot door (replace them and apply silicone where required) Combustion chamber (total cleaning of the entire chamber) and ignition plug tube cleaning ...
-
Page 25: Displays
Displays Display Reason solution Stove off staRt The start-up phase is in progress pellet feeDing The feeding of the pellet during the ignition phase is in progress ignition The ignition phase is in progress staRt-up The start-up phase is in progress WoRK The normal work phase is in progress MoDulation... -
Page 26: Alarms
alaRMs Display explanation solution On: indicates the presence of an alarm Off: indicates the absence of alarms Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 1 for 3 seconds only if the fumes motor has stopped and if 15 minutes have passed from displaying the same alarm. -
Page 27: Guarantee Terms
Extraflame S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website. - Page 28 AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating.
- Page 29 ENGLISH...
- Page 30 ENGLISH...
- Page 31 ENGLISH...
- Page 32 Extraflame S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
