KIT FEATURES
Rear support
provisions
CD jewel case
pocket
KIT COMPONENTS
Radio Housing (A)
Radio Housing (B)
(2) Rear
Supports
TOOLS REQUIRED
86-5618 - Head unit
removal keys
Phillips screwdriver
99-5804
99-5804
AW-586FT
AW
-586FT
INSTALLA
INSTALLATION
APPLICATIONS
APPLICATIONS
CAR
CAR
FORD
Excursion 2000-05................................ 1
Expedition 1999-02..............................1
Explorer 1995-01.................................1
F-Series Truck 1999-03.......................1
Ranger 1995-09...................................1
Windstar 1999-03..................................1
F-Series Super DutyTruck 2004-01.......1
E-Series Van 1998-04...........................1
LINCOLN
Blackwood 2001-03..............................1
Navigator 1998-02...............................1
MAZDA
B-Series Pickup 1995-09......................1
MERCURY
Mountaineer 1997-01...........................1
1-800-221-0932
1-800-221-0932
© COPYRIGHT 2001-09 METRA ELECTRONICS CORPORATION
© COPYRIGHT 2001-09 METRA ELECTRONICS CORPORATION
TION
www.metraonline.com
www.metraonline.com
rev. 08/05/09
