KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets
A
B
Metra. The World's Best Kits.
®
GM Small trucks/SUV's
KIT FEATURES
• ISO DDIN radio provision
APPLICATIONS
Chevrolet S-10 Blazer 1998-2002*
Chevrolet S-10 Pickup 1998-2002*
GMC Jimmy (a.k.a. Jimmy Envoy) 1998-2001
GMC Sonoma 1998-2002*
Isuzu Hombre 1998-2000
* Only for early 2002 models denoted by a DIN and a half size radio
MetraOnline.com
1998-2002
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
95-3027
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: 70-1858
Antenna Adapter: 40-GM10
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 9/32" socket wrench • cutting tool • Scribe tool
Attention!
Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
REV. 5/22/19 INST95-3027
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metra Electronics 95-3027
Summary of Contents for Metra Electronics 95-3027
- Page 1 When testing the aftermarket equipment, ensure that all factory equipment is connected before cycling the key to ignition. Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 5/22/19 INST95-3027...
- Page 2 DASH DISASSEMBLY KIT PREPARATION 1. Remove (2) 9/32” screws securing the 1. Place the radio trim panel over the driver’s side knee bolster to the dash. factory dashboard trim panel. (Figure A) (Figure A) 2. Using a scribe tool, score the area in the 2.
- Page 3 KIT PREPARATION KIT ASSEMBLY (CONT.) 4. Slide the radio trim panel into the 1. Secure the radio brackets to the radio bottom opening of the factory using the screws supplied with the dashboard trim panel, then clip in the radio. (Figure A) top portion. Note, if the center bar of 2.
- Page 4 Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow. Metra recommends MECP certified technicians Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 5/22/19 INST95-3027...
