E30GI / E30GID
G A S I N S E R T - G L A S S B U R N E R w / I P I
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage, personal
injury or loss of life. Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
Report # 0268GN023S
CERTIFIED TO/ CERTIFIÉ AUX: ANSI Z21.88 / CSA2.33 VENTED GAS FIREPLACE HEATERS
50-2581
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E30GID and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro E30GID

Summary of Contents for Enviro E30GID

  • Page 1 E30GI / E30GID G A S I N S E R T - G L A S S B U R N E R w / I P I OWNER’S MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in • A barrier designed to reduce the risk of burns from the accordance with their instructions. Carefully read all the hot veiwing glass is provided with this appliance and shall instructions in this manual first.

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions......................2 Table of Contents......................4 Codes And Approvals.......................5 Specifications........................6 Rating Label Location...................6 Dimensions......................6 Install Depth......................6 E30 Options Dimensions..................7 Operating Instructions....................8 Lighting and Turning Off Instructions..............8 Venturi Adjustment....................9 Normal Sounds During Operation.................9 Remote Control Operations..................9 System Description.....................10 Technical Data....................10 Transmitter....................10 Battery Holder.....................11 Operating Procedure...................12...

  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer. See “D ”...

  • Page 6: Specifications

    Specifications ating abeL ocation The rating label is located on the bottom of the unit, behind the front access door. imensions 18.00 19.000 16.000 7.00 7.00 *Shown with Contemporary 15.40 surround 13.93 panel* 27.74 2.32 28.75 21.47 24.38 18.78 14.00 16.27 19.85 16.70...

  • Page 7: E30 Options Dimensions

    Specifications e30 o ptions imensions 8 " 25" 8 " 8 " Figure 2: E30 Contemporary Surround with Base Shelf and Riser. Table 2: E30 Options Dimensions. Regular Surround Contemporary Surround Extruded Surround Height 25” (635mm) 25” (635mm) 25” (635mm) Width ”...

  • Page 8: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...

  • Page 9: Venturi Adjustment

    Operating Instructions entuRi Djustment The venturi adjustment lever is located on the right side of the unit, below the door (see Figure 4). To avoid touching hot surfaces under the unit, use the Door Tool to adjust the venturi. The venturi allows the amount of air coming into the fireplace to be adjusted in order to accommodate different climates and venting arrangements.

  • Page 10: System Description

    Operating Instructions For E30GID models refer to the separate Dexen user manual supplied for remote control operations. ystem escRiption The Proflame 2 Remote Control System consists of two (2) elements: 1. Proflame 2 Transmitter. 2. Integrated Fireplace Controller (IFC) and wiring harness to connect to the gas valve, stepper motor battery holder, and convection fan.

  • Page 11: Battery Holder

    Operating Instructions Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART Temperature CPI mode Set Point Aux ON Temperature/Level/State ot used Flame ON Split Flow ot used Dimmer ON Comfort fan ot used Figure 6: Proflame 2 Transmitter LCD Screen. atteRy oLDeR The Battery Holder (Figure 7) connects directly to the IFC with a wiring harness.

  • Page 12: Operating Procedure

    Operating Instructions peRating RoceDuRe Initializing The System For The First Time Install the four (4) AA batteries into the IFC battery holder. Note the polarity of the battery and insert into the battery bay as indicated on the body of the battery holder. Press and release the reset button (see Figure 7). The IFC will “beep”...
  • Page 13 Operating Instructions Remote Flame Control The Proflame 2 GTMF has six (6) flame levels. With the system on, and the flame level at the maximum in the appliance, pressing the Down Arrow Key once will reduce the flame height by one step until the flame is turned off. The Up Arrow Key will increase the flame height each time it is pressed.
  • Page 14 Operating Instructions Split Flow Control This function is not used on the E30 and can be disregarded. Figure 14: Split Flow Control Aux Control This function is not used on the E30 and can be disregarded. Figure 15: Aux Control Key lock This function will lock the keys to avoid unsupervised operation.
  • Page 15 Operating Instructions Low Battery Power Detection Transmitter: The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of changes to the room thermostat set point, etc. When the Transmitter batteries are low, a Battery Icon will appear on the LCD display of the Transmitter (see Figure 17) before all battery power is lost.

  • Page 16: Maintenance And Service

    Maintenance And Service Warning: Failure to position the parts in accordance with this manual, or failure to use only parts specifically approved with this appliance, may result in property damage or personal injury. At least once a year, run through the following procedures to ensure the system is clean and working properly.

  • Page 17: Cleaning The Firebox

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 16). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 18: Fuel Conversion

    Maintenance And Service onVeRsion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 19 Maintenance And Service 7. Convert the SIT gas valve: a) Use a T-20 driver to remove the two screws that hold the servo regulator to the gas valve and disconnect the wire harness from the IFC. b) Remove the rubber regulator diaphragm that is situated between the servo regulator and the valve body.

  • Page 20: Initial Installation

    The E30GI / E30GID may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of noncombustible materials. Before starting, refer to please reference the information in Table 5 and Figures 27 and 28.

  • Page 21: Venting

    Initial Installation QUALIFIED INSTALLERS ONLY Non-Combustible Facing Material Only Non-Combustible Framing i.e. steel stud All Sides of Build Out Sealed off Surround Panel Finished Opening Dimensions (H x W) = Surround Panel - Desired Overlap Figure 26: Installation with a non-combustible build out. enting WARNING: This appliance has been designed to draw room air for proper heat circulation from the sides and bottom of the unit, and out the top front.
  • Page 22 Initial Installation QUALIFIED INSTALLERS ONLY An approved chimney liner and rain cap must be used. A throat connector or flashing must be installed to ensure a tight seal, top performance, safety and efficiency. Carefully follow the manufacturer’s instructions that accompany the chimney liner kit. Use double walled aluminum flex vent from either M&G DuraVent DirectVent Pro or ICC Excel Direct (see table 6).

  • Page 23: Baffle Plate Adjustment

    leak into the chimney. Refractory, glass doors, screen rails, screen mesh and log grates can be removed from the fireplace before installing the unit. Initial Installation QUALIFIED INSTALLERS ONLY The height for the vent must be between 8 ft (2.44 m) and 30 ft (9.14 m). Install a sealed vent cap to prevent leakage of room air up through chimney.

  • Page 24: Installing The Unit

    Initial Installation QUALIFIED INSTALLERS ONLY nstaLLing the • Remove the packaging from the appliance and check to make sure there is no damage. Carefully check the glass door. Do not use the unit if it is damaged. In the event damage is found, please report it to your dealer as soon as possible.
  • Page 25 Initial Installation QUALIFIED INSTALLERS ONLY 5. Stretch the Ø3” (76mm) flex vent liners to the length needed to ensure they can be easily connected to the vent terminals. M&G 6. Install the flex pipe assembly up through the chimney, DirectVent ensure that the pipe slides through far enough to connect EXCELDirect onto the vent cap.

  • Page 26: Zero Clearance Fireplace Installation

    Initial Installation QUALIFIED INSTALLERS ONLY 14. As you push the unit into its final position in the fireplace, if the vent collar plate was removed, reinstall it on the stove by pulling it into the brackets on top and reinstall the two Torx T-20 screws.

  • Page 27: Electrical Requirements

    18 AWG wire with a temperature rating of at least 105°C. Note: For E30GID specific wiring diagram refer to the Dexen user manual supplied and label attached to the fireplace.

  • Page 28: Gas Line Connection

    Initial Installation QUALIFIED INSTALLERS ONLY onnection WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. Gas Line Connection: • A ⅜” NPT male pipe nipple (supplied with the unit) will have to be turned into the valve at the lower left side rear of this fireplace (see Figures 36 and 37).

  • Page 29: Adjusting The Pilot Flame

    Pilot Pilot Inlet Adjustment Solenoid Pressure Screw Figure 38: Valve Details. See Dexen User Manual for E30GID valve details NEVER USE AN OPEN FLAME FOR LEAK TESTING. e30giD Djusting iLot Lame Does not appLy to moDeLs The pilot flow adjustment is set to maximum at the factory and should not need to be adjusted.

  • Page 30: Secondary Installation

    Secondary Installation afety cReen nstaLLation emoVaL To install the safety screen hold it upright in front of the fireplace with four (4) hooks pointing towards the fireplace. Slide the hooks into the corresponding brackets on each side of the cabinet (see figures 40 and 41).

  • Page 31: Optional Trimmable Panels

    Secondary Installation ptionaL iDeD RimmabLe aneLs Modifying the Surround Panel: The E30 Trimmable Surround Panels are large rectangular panels that may be cut for use in cases that a non- standard fireplace opening (e.g. an arched opening) is to be filled. Optionally this surround can be left uncut and placed in front of the fireplace opening.

  • Page 32: Surround Panel Installation

    Secondary Installation uRRounD aneL nstaLLation WARNING: The surround becomes hot when the unit is operating; ensure that the unit is turned off, and that it has cooled to room temperature before beginning this installation. Height Width 3-Sided Surround 25” (635 mm) ”...

  • Page 33: Firebox Liner And Burner Tray Removal / Installation

    WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. 1. Ensure the E30GI / E30GID is turned off and allow the unit to cool.

  • Page 34: Glass Media Installation

    Secondary Installation Lass eDia nstaLLation Pour the glass media into the tray and evenly distribute over the entire tray (see figure 55). Make sure the burner starter tube is un-obstructed for a clear path to the pilot flame and keep the pilot area clear of any glass media (see figure 56).

  • Page 35: Troubleshooting

    Troubleshooting e30giD iagnostic Lash oDes Does not appLy to moDeLs 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset.
  • Page 36 Troubleshooting Note: For E30GID specific troubleshooting refer to the Dexen user manual supplied Problem Possible Cause Solution The pilot flame has gone out · Turn it ON Thermostat The On/Off switch is turn to OFF does not work The thermostat is set too high ·...
  • Page 37 Troubleshooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.

  • Page 38: Parts List

    Note: For E30ID specific replacement parts refer to the Dexen user manual supplied Reference Part Description Part Number Number E30 DV Flue Adaptor Bottom Gasket 50-2497 E30GI / E30GID Owner’s Manual 50-2581 E30GI Conversion Kit NG to LP 50-2487 E30GI Conversion Kit LP to NG 50-2542 E30 Door Release Tool...

  • Page 39: Parts Diagram - Components

    Parts Diagram - Components...

  • Page 40: Warranty

    Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.

  • Page 41: Installation Data Sheet

    DIRECT VENT _________________________________________ NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in WC PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com Winter 2021 C-15571...
