WLAN link Gives information about the wireless LAN access of the internal wireless net-
work adapter of the base station. The WLAN link display can assume three
states:
off
green
green
¸
WLAN data Gives information about the data traffic in the wireless LAN access.
The WLAN data display can assume three states:
off
green
green
¹
Security Status of the firewall. Indicates the status of the security settings and averted
(LANCOM
attacks to the protected network.
1811 Wireless
DSL only)
green
red/
green
red
VPN Status of a VPN connection.
off
green
green
green
green
2.3.2

The back of the unit

The connections and switches of the router are located on the back panel:
LANCOM 1811 Wireless DSL – LANCOM 1821+ Wireless ADSL
No wireless LAN adapter found
constantly on Wireless LAN adapter ready for use
flickering Activity in wireless LAN (blinking frequency indicates the
number of registered stations)
No data traffic
flickering Data traffic
flashing Error in the wireless LAN (e.g. sending error because of bad
connection quality)
constantly on Security settings ok. Packet filter rules are set.
blinking Insecure configuration
flickering Security alert: data packet filtered by firewall rules
No VPN tunnel established
blinking Negotiating VPN connection
flashing Establishing first connection
inverse flashing Establishing further connection
constantly on VPN connection established
Chapter 2: Installation
