Super Circuits DMR4 Quick Start Manual

HARD DISK DRIVE COMPARTMENT
To remove hard disk drive compartment, turn the hard disk
lock to the down position. Lift the hard disk drive compartment
handle and pull the hard disk drive compartment out.
To insert the hard disk drive compartment, turn the hard disk
lock to the down position. Lift the hard disk drive compartment
handle and insert the hard disk drive compartment. To power
on the hard disk drive, turn the hard disk lock to the left
position.
Green light indicates the hard disk drive is storing or
retrieving data. Red light signals the hard disk is reaching
capacity.
PLAYBACK
.
PLAY button to playback last recorded video.
Press the
The monitor will display a flashing
PLAY button will light up indicating the unit is in
the
playback status
Press the .STOP button to stop playback at any time.
PAUSE button during playback to freeze the
Press the
display. During the freeze, press this to display one framelfield
of a picture at a time in the forward direction.
MANUAL RECORDING
In live display, press the OREC button to begin recording
video onto a hard disk with the corresponding settings.
The monitor will display a flashing
status.
.Press the .STOP button to stop recording at any time.
JOG/SHUTTLE DIAL FASTISLOW PLAYBACK
Turn the SHUTTLE dial righvleft to view recorded video at a
faster rate in the forwardlbackward direction. Release the
SHUTTLE dial to return to normal speed.
Each subsequent turn of the shuttle dial to the righffleft
increases the rate at 2X, 4X, 8X,16X, 30Xand IOOX
During the freeze l press
Turn the JOG d~al rightheft to display one framelfield of a
picture at a time in the forwardlbackward direction.
Turn the SHUTTLE dial rightheft to view recorded video at a
slower rate in the forwardlbackward direction. Release the
SHUTTLE dial and then press the
the normal speed of playback.
Each subsequent turn of the shuffle to the righvleft
decreases the rate at 1/2X, 1/4X, 1/8X and 1/16X
V
Enter
PLAY message and
REC message and the
PAUSE button):
.
PLAY button to return to
<
DISPLAY MODE SWITCH
When connected to a multiplexer, press the MONITOR button
to switch between the multiplexer decoded video and the encoded
video to be displayed. When the button light is on it indicates the
unit is displaying the decoded video. In this mode, the unit doesn't
display the OSD message of the unit on the screen. However, it
doesn't affect the unit's OSD message, which is recorded into hard
disk drive. When the button light is off it indicates the unit is
displaying encoded video (The image switch swiftly).
KEYLOCK OPERATION
For Key Lock operation, simultaneously press the
buttons once (at least 3 seconds) to lock the unit; to release
Key Lock, simultaneously press these two buttons again.
SEARCH RECORDED VIDEO
Press the SEARCH button to enter the search mode.
Use the "
LIST, TIME SEARCH, THUMBNAIL or SD CARD and press
the ENTER button.
"A", " V "
Use the
press the ENTER button
MENU SETUP
Press the SETUP button to enter the setup menu.
Use the
menus. Press again to exit the setup mode.
Press the ENTER button to enter the selected menu and
save the settings.
SYSTEM INFORMATION
Press the DISPLAY button to display the system operation
status on the screen.
Insert a SD card into the SD slot. Start playback of recorded
video.
Press the 1lPAUSE button during playback to freeze the
desired image.
Press the ENTER button to save the image.

rear view

V
to select the specific recorded video and
"A", "V", "
buttons to navigate through
INTO S D C AR D
SD
Card
ALARM
