Super Circuits DVR Quick Operation Manual

DVR Quick Operation Guide

Changing Views and Selecting Cameras

UP/DOWN Change
Camera Layout
UP/DOWN Change
Camera Layout

Recording Video

Typically when installing a DVR, one will configure the unit to record 24/7 or more commonly, to record
only when movement is detected on a particular camera. A small indicator is shown on each video screen,
identifying the recording mode for that camera: M- Motion recording, S- Scheduled recording, R- manual
Recording. A small red square in the video window also indicates that recording is occurring. Unless you have specifically
configured your DVR to be manually activated by pressing "REC" button, we advise that you do not use that button unless
you have a clear view of a video screen and can visually confirm, if recording is in progress or not. Pressing the "REC"
button while the DVR is recording video will CANCEL the current recording. Pushing the "REC" button while no recording is
in progress, will activate recording on all channels configured to allow manual recording. Generally it is better to trust your
DVR to record video based upon the settings you've established and tested during setup.

Locating and Playing Back Recorded Video

1) Press to search for video. Use arrow keys to navigate and
2) Choose the desired method of searching for video:
Time Line (LIST) Search:
• Use arrow keys to select date (orange dates contain video)
• Use arrow keys and
time line to begin playback.
• Parts of the time line containing video are colored:
Pink = Scheduled Recording | Yellow = Motion Recording
Red = Manual Recording | Green = Sensor Recording.
• Pressing on a time will begin video playback
1-877-995-2288 or email sales@supercircuits.com, or please feel free to browse our website at www.supercircuits.com.
Supercircuits is a registered trademark of Supercircuits INC. Copyright © 2009 Supercircuits, Inc. All rights reserved. www.supercircuits.com
1
2
3
4
LEFT/RIGHT Changes Which
Cameras are Displayed
1
1 2
4
3 4
7
to select the desired time on the
For order assistance, questions and inquiries, please contact one of our sales consultants at:
Full Screen
1 2 3 4
1 2 3
5 6 7 8
4 5 6
9 10 11 12
7 8 For cameras 1-9 push the numeric key. For
13 14 15 16
cameras 10-16, push the
1 5
2 6
followed by the desired camera number.
3 4 7 8
1 2 3 4
2 3
5 6 7 8
5 6
9 10 11 12
8
13 14 15 16
Zoom
GoTo (Time):
• Use arrow keys to choose desired date /time, then
press

Video Playback Control:

Press
press
Push the desired camera number
to bring that single camera to a
full screen view.
button first
When viewing full screen, the
button will electronically magnify
the image. Use arrow keys to move
around the magnified view.
or to choose options.
to start playback.
to control playback or
to exit playback and back up in menus.
Cont. on back
