Summary of Contents for CAS PD-2
-
Page 2: Table Of Contents
CONTENTS PRECAUTIONS ............4 PREFACE ..............6 NAMES AND FUNCTIONS ......6 OPERATIONS ............8 1. General Weighing ........... 9 2. ECR Interface............9 ERROR MESSAGE ..........10 SPECIFICATIONS ..........11... -
Page 3: Preface
PREFACE... -
Page 5: Names And Functions
PREFACE Thank you for purchasing our CAS PD-II. These series have been designed with CAS reliability, under rigid quality control and with outstanding performance. Your specialty departments can enjoy these high quality reliable CAS products. We believe that your needs will be satisfied and you will have proper reliability. - Page 6 DISPLAY...
-
Page 7: Operations
■ KEY FUNCTIONS FUNCTIONS Used to set the zero point to 0.00 or 0.000. Used as ENTER key in Setup Mode. Used to enter a tare weight and used to cancel a tare weight. Used as ESC key in Setup Mode. Used to switch between lb and kg. -
Page 8: Ecr Interface
2. Weighing with Tare ■ There is the weight of container being used for a commodity. ■ The TARE key subtracts the weight of the container. Place the container on the platter. Press the TARE key, NET lamp is On. Place an item in the container. -
Page 9: Error Message
9600 Baud Rate, 7 Date bit, Even Parity. 1 Stop bit ERROR MESSAGE ERROR REASONS SOLUTIONS Failure of A/D Module Call your CAS dealer Set the platter empty Err 1 An error of initial zero range Make sure there is a platter on the scale... -
Page 10: Specifications
SPECIFICATIONS MODEL 15 lb(6kg) 30 lb(15kg) 60 lb(30kg) 150 lb(60kg) 5 lb x 0.002 lb 15 lb x 0.005 lb 30 lb x 0.01lb 60 lb x 0.02 lb 15 lb x 0.005 lb 30 lb x 0.01 lb 60 lb x 0.02 lb 150 lb x 0.05 lb DIVISION DUAL INTERVAL 3kg x 1g... - Page 11 MEMO...
- Page 12 MEMO...
- Page 13 MEMO...
