Specifications - Icom IC-M801GMDSS Instruction Manual

• General
• Frequency coverage :
Receive 0.5–29.9999
Transmit 1.6–2.9999
6.0–6.9999
12.0–13.9999
18.0–19.9999
25.0–27.5000
• DSC channels : 2187.5 kHz, 4207.5 kHz,
6312.0 kHz, 8414.5 kHz,
12577.0 kHz, 16804.5 kHz
• Type of emission :
Transceiver J3E
F1B
DSC receiver F1B
• No. of memory Ch. : 1205 channels (max.)
160 user programmable, 249 ITU
SSB duplex, 124 ITU SSB
simplex, 662 ITU FSK duplex and
10 Semi/Auto channels
: SO-239×2 (50 Ω)
• Antenna connector
• Usable temp. range : –15˚C to +55˚C
• Frequency stability : ±10 Hz
(Approx. 5 min. after [DC ISOLATE] is turned ON.)
• Power supply : 21.6–31.2 V DC
• Current drain :
Transmit at max. power 30 A
Receive at max. audio
• Dimensions
(projections not incl.)
Main unit 367(W)×95(H)×260(D) mm
Controller
(RC-25GMDSS)
220(W)×110(H)×84.4(D) mm
Speaker
(SP-24E)
110(W)×110(H)×84.4(D) mm
• Weight (approx.) :
Main unit 8.5 kg
Controller
(RC-25GMDSS)
570 g
Speaker
(SP-24E)
370 g
• CONTROLLER connector : 8-pin connector
• GPS connector : RCA (NMEA0183 ver. 3.01)
• REMOTE connector : D-sub 9-pin (RS-232C/NMEA)
• AF/MOD connector : D-sub 9-pin
• PRINTER connector : D-sub 25-pin
(Unit: MHz)
4.0–4.9999
8.0–8.9999
16.0–17.9999
22.0–22.9999
, H3E,* J2B
(USB/LSB*) (AFSK)
, A1A*
(FSK) (CW)
*Receive only
(floating ground)
Less than 3.0 A
:

SPECIFICATIONS

• Transmitter
• Output power
1.6–3.9999 MHz
4.0–27.5000 MHz
• Spurious emission
• Carrier suppression
• Unwanted sideband
suppression
• Mic. connector
• Receiver
• Sensitivity
Transceiver
,
J3E, A1A
(20 dB SINAD)
J2B, F1B
(20 dB SINAD)
H3E
(20 dB SINAD)
DSC receiver
(J2B)
• Spurious response rejection ratio:
Transceiver
DSC receiver
• AF output power
(at 24 V DC)
• CLARITY variable range : ±150 Hz
• Headphone connector : 3-conductor 3.5 (d) mm (
• SP connector
All stated specifications are typical and subject to change without no-
tice or obligation.
14
:
85 W p-p
125 W p–p
: 43 dB below peak output power
: 40 dB below peak output power
: 55 dB below peak output power
(w/1 kHz AF input; at max power)
: 8-pin connector (2.4 kΩ)
:
30 dBµV emf
(0.5–1.5999 MHz)
13 dBµV emf
(1.6–1.7999 MHz)
8 dBµV emf
(1.8–29.9999 MHz)
13 dBµV emf
(1.6–1.7999 MHz)
8 dBµV emf
(1.8–29.9999 MHz)
44 dBµV emf
(0.5–1.5999 MHz)
30 dBµV emf
(1.6–1.7999 MHz)
24 dBµV emf
(1.8–3.9999 MHz)
0 dBµV emf
(all channels)
More than 70 dB
(0.5–29.9999 MHz)
More than 60 dB
(1st image)
More than 50 dB
(except 1st image)
: More than 4.0 W at 10% distortion
with a 4 Ω load
1
⁄
8
1
: 2-conductor 3.5 (d) mm ( ⁄
8
1
2
3
4
5
6
7
")
")/4 Ω
8
9
10
11
12
13
14
15
16
17
67
