About this Manual ............................................................................................................................ 1-1
Safety Messages Used in this Manual .............................................................................................. 1-1
Pre-Delivery Inspection .................................................................................................................... 1-2
Front Axle Tire Alignment ............................................................................................................... 1-2
Service and Assistance ...................................................................................................................... 1-2
Reporting Safety Defects .................................................................................................................. 1-2
Vehicle Certification Label ............................................................................................................... 1-3
specifications and Capacitites ........................................................................................................... 1-4
Owner and Vehicle Information ....................................................................................................... 1-6
2008 New Vehicle Limited Warranty ............................................................................................... 1-7
General Warnings ............................................................................................................................. 2-1
Driving Safety ................................................................................................................................... 2-1
Fuel and LP Gas ................................................................................................................................ 2-1
LP Gas Leaks .................................................................................................................................... 2-2
Propane Gas Leak Detector .............................................................................................................. 2-2
Carbon Monoxide Warning .............................................................................................................. 2-3
Carbon Monoxide Alarm .................................................................................................................. 2-3
Smoke Alarm .................................................................................................................................... 2-4
Fire Extinguisher ............................................................................................................................... 2-5
Electrical ........................................................................................................................................... 2-5
Loading ............................................................................................................................................. 2-5
Maintenance ...................................................................................................................................... 2-6
Emergency Exits ............................................................................................................................... 2-6
Formaldehyde Information ............................................................................................................... 2-7
Mold, Moisture and Your Motor Home ............................................................................................ 2-7
Roadside Emergency ........................................................................................................................ 2-8
Jump Starting .................................................................................................................................... 2-9
Engine Overheat ............................................................................................................................... 2-9
Seats - Driver/Co-Pilot ..................................................................................................................... 3-1
Passenger Footrest ............................................................................................................................ 3-2
Seat Belts .......................................................................................................................................... 3-2
Child Restraints ................................................................................................................................. 3-3
Key One Lock System ...................................................................................................................... 3-4
Power Door Locks ............................................................................................................................ 3-4
Mirrors - Power Electric ................................................................................................................... 3-5
Rearview Monitor System ................................................................................................................ 3-6
Rev. 0820090622

TABLE OF CONTENTS

Copyright 2007 Winnebago Industries, Inc. All rights reserved.
Part No. 161500-08-018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Meridian ITASCA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winnebago Meridian ITASCA

Summary of Contents for Winnebago Meridian ITASCA

  • Page 1: Table Of Contents

    Seat Belts ............................3-2 Child Restraints ..........................3-3 Key One Lock System ........................3-4 Power Door Locks ..........................3-4 Mirrors – Power Electric ........................3-5 Rearview Monitor System ........................ 3-6 Rev. 0820090622 Part No. 161500-08-018 Copyright 2007 Winnebago Industries, Inc. All rights reserved.
  • Page 2 Table Of Contents Power Sunvisors ..........................3-7 Parking Brake ........................... 3-7 Exhaust Restriction Braking System ....................3-7 Hazard Warning Flashers ........................3-8 Signal Lever/Headlight Hi/Lo Beam ....................3-8 Map Light Switch ..........................3-9 Steering Column Adjustment ......................3-9 Battery Boost Switch ........................3-9 Air Conditioner/Heater –...
  • Page 3 Table Of Contents Air Conditioner Filter ........................4-12 Washer/ Dryer ..........................4-12 5 – PROPANE GAS Propane Gas Supply .......................... 5-1 Safe Use of the Propane Gas System ....................5-2 Propane Gas Warnings and Precautions ................... 5-3 Propane Gas Pressure Regulator ....................... 5-4 Propane Vaporization in Cold Weather ....................
  • Page 4 Table Of Contents TV Antenna ............................8-3 TV Signal Amplifier ......................... 8-4 Cable TV, Satellite and Phone Hook-Ups ..................8-5 TV Digital Satellite System Wiring ....................8-5 TV Digital Satellite System – Automatic ..................8-5 TV Digital Satellite Dish – In-Motion ....................8-6 Exterior Entertainment Center ......................
  • Page 5 Table Of Contents Bathroom ............................11-8 Doors and Windows ........................11-8 Vehicle Storage – Preparation ......................11-9 Vehicle Storage – Removal ......................11-9 Chassis Service and Maintenance ....................11-10 Coach Maintenance Chart ......................11-11 Sealants – Recommended Application ..................11-14 12 –...

  • Page 7: Introduction

    DANGER indicates a directly hazardous are intended as a guide, and in no way situation which, if not avoided, will result extend the responsibilities of Winnebago in death or serious personal injury. Industries beyond the standard written warranty as presented in this manual.

  • Page 8: Pre-Delivery Inspection

    If you need warranty repairs while traveling you may take your motor home to any authorized CAUTION indicates a potentially Winnebago or Itasca dealership and request their hazardous situation which, if not avoided, assistance. could result in damage mainly to...

  • Page 9: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago 9. Rear Axle Wheel Configuration: Single or Industries. Dual as it relates to the inflation.

  • Page 10: Specifications And Capacitites

    SECTION 1 – INTRODUCTION SPECIFICATIONS AND CAPACITITES Model Length 37' 7" 39' 3" Exterior Height 12' 2" 12' 2" Exterior Width 8' 5.5" 8' 5.5" Exterior Storage (cu. ft.) 118.2 149.5 Awning Length 19' 6" Interior Height 7' 2.5" 7' 2.5" Interior Width 8' 0.5"...
  • Page 11 SECTION 1 – INTRODUCTION Specifications and Capacities Notes: ® ® Freightliner Chassis, Cummins ISB 6.7L turbo-charged diesel, 350-hp, rear radiator, Allison ® speed electronic 3000 MH transmission, NeWay front & rear air suspension, 170-amp. alternator, exhaust brake, 4-wheel ABS, Stylized Aluminum Wheels. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit.

  • Page 12: Owner And Vehicle Information

    Motor Home Serial Number __________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 13: 2008 New Vehicle Limited Warranty

    ITEMS NOT SUBJECT TO WARRANTY COVERAGE Winnebago Industries, Inc. of Forest City, Iowa, warrants each new Chassis, drivetrain and related components* Winnebago and Itasca motor home to the owner for recreational use Wheels* in the U.S.A. and Canada as follows:...
  • Page 14 If you are touring or have moved, contact any unresolved warranty disputes for recreational vehicles. This dispute Winnebago Industries motor home dealer in the United States or resolution program reviews eligible product and service related Canada for warranty service.

  • Page 15: Safety And Precautions

    SECTION 2 – SAFETY AND PRECAUTIONS • Use care when accelerating or decelerating on GENERAL WARNINGS a slippery surface. Abrupt speed changes can cause skidding and loss of control. • Only seats equipped with seat belts are to be occupied while the vehicle is moving. •...

  • Page 16: Lp Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS • Never use an open flame to test for LP gas LP GAS LEAKS leaks. Replace all protective covers and caps on LP system after filling. Make sure valve is The following procedures are located in the closed and the door is latched securely.

  • Page 17: Carbon Monoxide Warning

    SECTION 2 – SAFETY AND PRECAUTIONS Because propane gas is heavier than air, the CARBON MONOXIDE leak detector is located on a cabinet face near the WARNING floor of the coach. WARNING WARNING Never use an open flame to test for gas Avoid inhaling exhaust gases, as they leaks.

  • Page 18: Smoke Alarm

    InfoCase for further instructions. may not be recommended for RV application. Replacement We recommend obtaining a replacement from your Winnebago Industries dealer. When replacing this alarm, we recommend replacing only with a similar model. Other brands may not be recommended for RV application.

  • Page 19: Fire Extinguisher

    We recommend obtaining a replacement only from your Winnebago Industries dealer or a reliable RV parts supplier.

  • Page 20: Maintenance

    SECTION 2 – SAFETY AND PRECAUTIONS MAINTENANCE • Do not remove the radiator cap while engine and radiator are still hot. Always check coolant level visually at the see-through coolant reservoir. • Never get beneath a vehicle that is held up by a jack only.

  • Page 21: Formaldehyde Information

    SECTION 2 – SAFETY AND PRECAUTIONS Mold is a plant and requires its own special FORMALDEHYDE environment to grow. That environment includes INFORMATION organic materials, nutrients, moisture, and proper temperature. Some of the materials used in this recreation vehicle emit formaldehyde. Eye, nose, and throat How Can I Avoid Mold? irritation, headache, nausea, and a variety of To reduce the ability for mold to grow, you...

  • Page 22: Roadside Emergency

    The deflated If Winnebago Industries determines that mold tire will slow the vehicle. is present in the Winnebago/Itasca motor home • If you must change lanes to get to a safe as a result of a manufacturing defect reported to...

  • Page 23: Jump Starting

    SECTION 2 – SAFETY AND PRECAUTIONS For information on what to do in case of overheating, consult your chassis manual. WARNING Stay out from beneath the motor home while it is suspended by the towing assembly unless the vehicle is adequately supported by safety stands.

  • Page 25: Driving Your Motor Home

    SECTION 3 – DRIVING YOUR MOTOR HOME The information in this section refers only to features installed or adapted to the dash and driver compartment area by Winnebago Industries. It also includes passenger seating in the living area of the coach.

  • Page 26: Passenger Footrest

    SECTION 3 – DRIVING YOUR MOTOR HOME • Swivel the seat the rest of the way to face the PASSENGER FOOTREST living area. • Tilt the steering wheel down. - If Equipped • Reverse the procedure to face the seat The co-pilot seat is equipped with a manual forward.

  • Page 27: Child Restraints

    SECTION 3 – DRIVING YOUR MOTOR HOME Unfastening 1- Insert tab into buckle Press the release button in the buckle. Hold slot until it ‘clicks’ and is onto the tongue when you release it from the locked buckle to keep it from retracting too rapidly. When the lap-shoulder belt is in use, the lap belt must ride low across the hip area and the 3- Press to...

  • Page 28: Key One Lock System

    If your coach has a dinette, it may be equipped our factory database, so if you ever lose your with a child seat tether anchor loop located on the keys, any Winnebago Industries dealership can floor directly behind the forward facing dinette order a new key for you.

  • Page 29: Mirrors - Power Electric

    SECTION 3 – DRIVING YOUR MOTOR HOME To access the keyless entry control box, remove 4 screws and open the panel carefully to avoid damage or disconnection of wiring looms. Power Door Lock Switch Keyless Remote Entry System Keyless Entry Control Box in The keyless entry is a remote control power 12-volt electrical compartment.

  • Page 30: Rearview Monitor System

    SECTION 3 – DRIVING YOUR MOTOR HOME REARVIEW MONITOR SYSTEM Move Selector Switch L or R to select mirror. Center “neutral” position disables arrows –If Equipped to avoid unintentionally moving a mirror. Press Arrow Buttons to move mirror surface in direction indicated. The rearview camera monitor system lets you Mirror Heaters see what’s directly behind your coach for...

  • Page 31: Power Sunvisors

    SECTION 3 – DRIVING YOUR MOTOR HOME The sideview cameras activate with the PARKING BRAKE corresponding turn signals and replace the rear camera view on the monitor until the turn is –Freightliner Chassis completed or the signal lever is canceled manually.

  • Page 32: Hazard Warning Flashers

    SECTION 3 – DRIVING YOUR MOTOR HOME The increased back pressure would normally HAZARD WARNING FLASHERS stop the engine except the forward momentum of the vehicle keeps the drivetrain and the engine The hazard warning flashers provide turning. additional safety when the vehicle must be This controlled back pressure helps to regulate stopped on the side of the roadway and presents a a vehicle’s downhill speed, such as on...

  • Page 33: Map Light Switch

    SECTION 3 – DRIVING YOUR MOTOR HOME Adjust Steering Wheel or Column signal and downward for left turn signal. An audible chime will alert you when the signals are Press the pedal down to adjust either the tilt or flashing. telescope.

  • Page 34: Defrost Fans

    SECTION 3 – DRIVING YOUR MOTOR HOME Fan Switch Mode Selector Temp Control Please refer to the manufacturer’s operating Further Information guide in your InfoCase for detailed instructions on programming preset station buttons and using Please read the information provided by the this full-featured radio/audio system.

  • Page 35: Cb Radio Power Wiring

    SECTION 3 – DRIVING YOUR MOTOR HOME NOTE:The Aux. Battery Disconnect switch must be on while listening to the dash radio because the audio relay is powered by house batteries. If the Aux Batt switch is off, the speakers will not emit sound. See the dash radio manufacturer’s information in your InfoCase for operating instructions.

  • Page 36: Fuel Selection - Diesel Engine

    SECTION 3 – DRIVING YOUR MOTOR HOME Look for a pair of wires, yellow (+) and white FILLING THE FUEL TANK – (-), with connectors and flag labels, suspended DIESEL ENGINE from the wiring harness. –If Equipped Diesel fuel, especially #2 grade, can foam up while being pumped into the tank.

  • Page 37: Engine Block Heater - Diesel Engine

    SECTION 3 – DRIVING YOUR MOTOR HOME FRONT SERVICE ACCESS (Hood) The hood panel can be opened for access to service items such as: • Air Hose Connector • Windshield Washer Fluid Reservoir • Generator Oil Dipstick Use the special key to rotate the hood locks, ENGINE BLOCK HEATER –...

  • Page 38: Engine Top Access Covers - Rear

    SECTION 3 – DRIVING YOUR MOTOR HOME Rear Engine (Shown with grille panel open) With the grille panel open, you can access the following service points: Engine Oil Fill (Located top of engine) • Engine Oil Dipstick • Engine Oil Fill Cap •...
  • Page 39 SECTION 3 – DRIVING YOUR MOTOR HOME Accessing the Engine • Lift the hinged bed board upward against wall. Support the bed board with a suitable prop item as shown (if bed is not equipped with struts). CAUTION A falling bed board can injure. Assure the bed is properly Lift bed to supported.

  • Page 40: Fuel/Water Separator - Diesel Engine

    SECTION 3 – DRIVING YOUR MOTOR HOME Propping the Bed Board The fuel/water separator is located at the forward right side of the engine beneath the rear of the chassis. Aluminum Tube Diesel Fuel/Water Transmission Engine Oil Filter Separator Filter - Fluid Filter - - Typical Typical...

  • Page 41: Chassis Battery Cutoff Switch

    SECTION 3 – DRIVING YOUR MOTOR HOME NOTE: Your chassis engine cooling system is filled with special extended-life coolant that is not the same as common anti- freeze available at retail outlets. The coolant system MUST be refilled or topped up with the same type of coolant as equipped to maintain the special long- life properties.

  • Page 42: Windshield Washers And Wipers

    SECTION 3 – DRIVING YOUR MOTOR HOME WINDSHIELD WASHERS AND WIPERS The windshield washer fluid reservoir is located in the front of the coach behind the hood panel. A long-necked funnel may be required for filling. We recommend using commercially available premixed solutions for best results.

  • Page 43: Suspension Alignment And Tire Balance

    SECTION 3 – DRIVING YOUR MOTOR HOME Refer to your chassis manual for further SUSPENSION ALIGNMENT information. AND TIRE BALANCE MOUNTAIN DRIVING The front suspension and steering system of this vehicle was factory aligned using highly Special techniques must be used when driving accurate equipment prior to delivery to the in mountainous or hilly country.

  • Page 45: Appliances And Systems

    SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motor home are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. REFRIGERATOR The refrigerator in your coach can operate Bubble must be at least 1/2 inside circle from either of two energy sources available to the motor home:...

  • Page 46: Ice Maker

    SECTION 4 – APPLIANCES AND SYSTEMS To Open: operate on 120-VAC household current if the shoreline is connected or the auxiliary 1. Use a screwdriver or coin to turn the latch generator is running. knobs to the vertical position as shown. AU (Automatic Mode) - Refrigerator will automatically start operating on 120-VAC household current if the shoreline is...

  • Page 47: Range Top

    SECTION 4 – APPLIANCES AND SYSTEMS Unlike homes, the amount of oxygen supply is limited due to the size of the recreational vehicle, and proper ventilation when using the cooking Microwave/Range Hood - Typical appliances avoids dangers of asphyxiation. (brand, model, and appearance It is especially important that cooking shown may vary from your model) appliances not be used for comfort heating, as the...

  • Page 48: Generator Hourmeter

    SECTION 4 – APPLIANCES AND SYSTEMS Water and Holding Tank Levels Press and Hold the appropriate button to show approximate tank level on the monitor lights The approximate fluid levels are measured by OnePlace Monitor Panel sets of electronic sensors (detector cells) on the sides of the tanks.

  • Page 49: Solar Charger Panel

    SECTION 4 – APPLIANCES AND SYSTEMS Gray Waste Tank Selector (Model Battery Voltage Meter 39Z only) Press the “House Battery” switch position to check the level of charge (voltage) in the 12-volt This model has two gray water tanks. Because house batteries.

  • Page 50: Energy Management System (Ems)

    SECTION 4 – APPLIANCES AND SYSTEMS ENERGY MANAGEMENT SYSTEM (EMS) The Energy Management System (EMS) monitors the electrical usage of the appliances and equipment in the coach and distributes the electrical loads to avoid nuisance tripping of the shoreline circuit breaker. This system works together with the energy efficient central air conditioner to allow you to run both compressors at the same time on a 30-amp shoreline...

  • Page 51: Pressure-Temperature Relief Valve

    SECTION 4 – APPLIANCES AND SYSTEMS Be sure the water heater is filled with water before starting either electric or propane gas operation. To fill the water heater, turn the Water Pump switch on and open a hot water faucet anywhere in the coach. When water begins to flow steadily from the faucet, the water heater is full.

  • Page 52: Motor Aid Water Heater

    SECTION 4 – APPLIANCES AND SYSTEMS Lift handle straight out to open P-T valve when water heater is cold* Water Heater Exterior Service Access 4. Let the handle of the P-T valve snap shut. Normally there is an air gap at the top of the water heater tank which acts as a pressure buffer.

  • Page 53: Propane Gas Furnace

    SECTION 4 – APPLIANCES AND SYSTEMS Turn thermostat off for 3-5 minutes, check to be sure propane gas tank valve CAUTION is open and tank is not empty, then try steps 2-4 again. If the furnace will not light after three Any leak in the heat exchanger or its attempts, go to Shut Down steps and supply or return lines could cause loss of...
  • Page 54 SECTION 4 – APPLIANCES AND SYSTEMS changing the temperature setpoint. A few Temperature Selector seconds after you release the temperature selector button, the display will return to showing the current room temperature. Cooling (A/C): • Slide the thermostat switch to Cool position. •...

  • Page 55: Furnace-A/C Thermostat Operation Chart

    SECTION 4 – APPLIANCES AND SYSTEMS FURNACE-A/C THERMOSTAT OPERATION CHART The following chart shows the system functions with the “Heat/Cool” thermostat. Disregard references to heat functions when using the “Cool Only” thermostat in the rear bedroom. X = Switch Position O = Switch position does not matter or is inactive for this feature FAN MODE FAN SPEED...

  • Page 56: Air Conditioner Filter

    SECTION 4 – APPLIANCES AND SYSTEMS cleaning or service. Remove the screws under the NOTE:Do not block the filter in any way, such as lower edge of the panel and swing it upward for by setting packages or newspapers, etc. access to the condenser.
  • Page 57 SECTION 4 – APPLIANCES AND SYSTEMS To Open During a Dry Cycle: 1. Advance the Program Selector to “Reset” (the “Status/Door Lock” LED will blink quickly to indicate that the cycle has stopped, but the door is STILL LOCKED). 2. When the “Status/Door Lock” LED blinks SLOWLY (takes 1-2 minutes), you can open the door.

  • Page 59: Propane Gas

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY WARNING The propane gas system supplies fuel for the gas range/oven, water heater, furnace and refrigerator (while in gas mode). When used and Do not alter or remove propane tank handled properly, this system is safe and gauge at any time.

  • Page 60: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS phone directory yellow pages for locations of local propane gas refilling stations or bulk DAN GE R dealerships. NOTE: If you travel outside the U.S. with your DO NOT FILL CONTAINER TO MORE motor home, you may find butane or THAN 80 PERCENT OF CAPACITY.

  • Page 61: Propane Gas Leaks

    SECTION 5 – PROPANE GAS • Exercise caution at all times. Be familiar with PROPANE GAS WARNINGS the distinctive odor of propane gas. If a leak is AND PRECAUTIONS suspected, turn off the supply valve immediately. Have the propane gas system It is illegal for vehicles equipped with propane checked by your dealer or other qualified tanks to travel on certain roadways or through...

  • Page 62: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS WARNING WARNING Propane cylinders shall not be placed or Visually inspect the pressure regulator stored inside the vehicle. vent periodically for blockage by Propane cylinders are equipped with accumulated debris or insect nests, etc. safety devices that relieve pressure by Vent obstruction could result in excessive discharging propane to the atmosphere.

  • Page 63: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.
  • Page 64 NOTES...

  • Page 65: Electrical

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motor home that is •...

  • Page 66: Connecting The Power Cord

    SECTION 6 – ELECTRICAL Connecting The Power Cord To connect to an external source, remove the cord from the utility compartment and plug it into a suitable 50-amp power receptacle to provide external power to the coach and converter/ charger system. NOTE: Some parks do not have 50-amp service available, so you will need to connect to a standard 30-amp service pole using an...

  • Page 67: Inverter/Charger Unit - 2000W

    SECTION 6 – ELECTRICAL Park Fuses or Breakers Most campgrounds are equipped with a fuse or circuit breaker at the receptacle. This protects the park’s wiring, as well as the power cord on your vehicle, from electrical damage. If electrical power fails, contact the park attendants and have them check the fuse or breaker for your supply receptacle.

  • Page 68: Power Center

    SECTION 6 – ELECTRICAL If your battery does not charge as described The refrigerator draws its electrical above, it is possible the battery is defective. current through the inverter and not directly from the shoreline. If the If the batteries are extremely discharged, the refrigerator is in ELECTRIC or AUTO charger unit will not activate to charge batteries mode, it will continue to draw from...

  • Page 69: Circuit Breakers - House 120-Volt Ac

    SECTION 6 – ELECTRICAL Charging Section component itself. When an overload or short develops, the breaker will open preventing The converter charges house batteries while damage to the system. 120-volt external power is connected. The Shut off the equipment (example: roof air converter will automatically “sense”...

  • Page 70: Electrical Generator

    SECTION 6 – ELECTRICAL shock if a ground fault develops. If such a ELECTRICAL GENERATOR condition occurs, the GFCI will break the circuit by turning off the power to the protected outlets. –If Equipped Should this occur, unplug all the appliances on that circuit and press the reset button on the GFCI equipped outlet.

  • Page 71: Operation Warnings And Cautions

    SECTION 6 – ELECTRICAL To Stop the Generator 1. Do not simultaneously operate the generator engine and a ventilator which could draw Press and Hold the Generator switch in STOP exhaust gases into the vehicle. position until you hear the generator come to a full stop, then release.

  • Page 72: Circuit Breakers - House 12-Volt

    SECTION 6 – ELECTRICAL House Batteries House batteries are “deep-cycle” type batteries specially designed for recreational vehicle use. They will provide longer lasting power than standard automotive starting batteries, and will withstand the frequent drain- and-recharge cycles that occur under the demanding conditions of a camping outing.

  • Page 73: Battery Access

    SECTION 6 – ELECTRICAL energy is removed from the battery, it should be replaced by the engine alternator or the RV converter system. If a battery sits unused for 30 days or more, especially during warm weather, it can develop a deposit of sulfate crystals on the metal plates inside the battery.
  • Page 74 SECTION 6 – ELECTRICAL Further precautions are: NOT OVERFILL. If fluid is added during freezing weather, the motor home should be • Remove the battery from the coach. driven several miles to mix water and • Store it in a cool place on a wooden or rubber electrolyte to prevent freezing.

  • Page 75: Plumbing

    SECTION 7 – PLUMBING FRESH WATER SYSTEM The fresh water system provides water to the galley sink, shower, bathroom lavatory, toilet and water heater. Water may be supplied by either of two sources: • a fresh water tank and water pump located within the motor home, or •...

  • Page 76: Utility Light

    SECTION 7 – PLUMBING 2. Turn Fresh Water Valve to Normal position Water pressure regulators are commonly and turn the water pump switches OFF. available at any well stocked RV dealership and many large retail discount or home supply centers. UTILITY LIGHT A light is located up on the left sidewall to illuminate the utility hook-up area when needed.

  • Page 77: Filtered Water Faucet

    SECTION 7 – PLUMBING Pump Strainer While the switch is “ON”, the pump will automatically supply water as it is needed. The pump is equipped with a cleanable We recommend that you turn the water pump strainer to capture any possible tank borne switch off whenever you will be away from the particles that could damage pump components.

  • Page 78: Full-Coach Water Filtration System

    SECTION 7 – PLUMBING • Purge a new filter cartridge before using for Filtered Water Faucet drinking. Run a few gallons of water through the filter and discard the water (or use for watering plants) to avoid ingesting carbon dust or particles that may have been present in the new filter cartridge.

  • Page 79: Disinfecting Your Fresh Water System

    SECTION 7 – PLUMBING • Remove the large O-ring seal from the canister. Check seal for damage, wipe clean and set aside. Discard the used filter cartridge. • Wash the inside of the canister with dish soap and warm water using a nonabrasive sponge or cloth.
  • Page 80 SECTION 7 – PLUMBING Coaches with Full-Coach Water Filtration System (in Water Center) WARNING 1. Open a faucet to relieve any water line pressure, then remove the filter canister from Chlorine is poisonous. Recap bottle and the filter base. clean all utensils after use. 2.

  • Page 81: Shower Hose Vacuum Breaker

    SECTION 7 – PLUMBING • Add 1 teaspoon of chlorine bleach (sodium hypochlorite) to your tank for each 10 gallons of tank capacity. When you fill the tank, this will result in a 6.7 ppm level of chlorine, which should kill harmful bacteria and slime- forming organisms.

  • Page 82: Waste Water System

    SECTION 7 – PLUMBING See winterizing instructions at the end of this section to prepare the toilet for storage in freezing conditions. Further Information See the toilet manufacturer’s operation information in your InfoCase for complete operating, care and maintenance information. WASTE WATER SYSTEM (Holding Tanks) Holding Tank Dump Valves (Typical)

  • Page 83: Water Line And Tank Drain Valves

    SECTION 7 – PLUMBING Flushing your Black Water Holding When using a sewer hook-up, keep the dump valves closed until a tank becomes full or when Tank preparing to leave the site. This keeps the solids The black water holding tank is equipped with in suspension, allowing them to be carried out an internal spray head that allows you to rinse the with the liquids when the dump valve is opened.

  • Page 84: Water Heater Bypass Winterization Valve

    SECTION 7 – PLUMBING The fresh water tank drain valve is cable- operated by pulling on a T-handle located in the water service center. CAUTION Water Heater Drain Plug Leave bypass valve handle in NORMAL The water heater drain plug is located on the FLOW position if draining water and outside of the coach behind the water heater blowing out water lines.
  • Page 85 SECTION 7 – PLUMBING After emptying the canister, remount it onto the filter assembly and continue the blow-out procedure. 6. Open Faucets. Turn on the water pump and open all sink faucets and shower head knobs. Leave open after water stops flowing. 7.
  • Page 86 This fills the drain trap pipes the system. (A ‘blow-out’ plug can be to prevent holding tank odors from entering purchased at any Winnebago or Itasca dealer. the coach during storage. P/N 701705-01-000.) NOTE: It is not necessary to add antifreeze to the toilet since the flush valve will be closed.
  • Page 87 SECTION 7 – PLUMBING 21. Close dump valves and refit the dust cap onto the drain outlet. WARNING This will inhibit rust formation on valve shafts and prevent entry and contamination by airborne debris, insects and rodents. NEVER use automotive antifreeze/ Your drainage and fresh water systems are now coolant in your RV water system.
  • Page 88 SECTION 7 – PLUMBING next numbered step.) After removing filter, remount the empty canister onto the filter assembly and continue the antifreeze fill procedure. Set Up Winterization Valves 3. Turn Winterization Valve 1 to ‘Water Heater Bypass’ position to avoid filling water heater with antifreeze.

  • Page 89: Winterizing Optional Appliances

    SECTION 7 – PLUMBING 15. Pour about one cup of RV antifreeze down each drain for the galley sink, lavatory sink, and shower/tub. This fills the drain trap pipes to prevent holding tank odors from entering the coach during storage. Dump and Clean Holding Tanks 16.
  • Page 90 SECTION 7 – PLUMBING 4. Press ON/OFF Button (OUT). Unplug the washer-dryer from the electrical outlet (or disconnect power) 5. Turn the water supply faucets OFF. Disconnect the inlet hoses from the faucets. Drain any remaining water from the hoses. 6.
  • Page 91 SECTION 7 – PLUMBING To use Washer-Dryer again: To use Dishwasher again: Flush antifreeze from the water lines, then Flush antifreeze from the water lines, then 1. Reconnect the water inlet hoses to the 1. Set the dishwasher controls to the start of the corresponding HOT/COLD faucets.

  • Page 92: Water System Drain Valve Locations

    SECTION 7 – PLUMBING WATER SYSTEM DRAIN VALVE LOCATIONS System Drain Valve Locations Water Line Drain Valves: Valves and drain hoses are located in the water service center on the driver side of the coach. Remove caps from hose ends, turn Fresh Water Valve to TANK FILL position, then turn hose valves to drain water lines.

  • Page 93: Entertainment

    SECTION 8 – ENTERTAINMENT To Watch VCR (if self-installed) VIDEO SELECTION SYSTEM • Press VCR button on MAIN TV section of –If Equipped Video Selection System panel. To Watch Rear/Bedroom TV (if equipped) • Video selection for the rear TV is similar to front TV viewing except all selections are made with buttons in the TV2 grouping.
  • Page 94 SECTION 8 – ENTERTAINMENT Connect Theater • Volume is adjusted with the DVD remote (or volume control on DVD player). Speakers • Press the SPEAKERS TV Sound through Home Theater switch on the dash to Speakers TV position to connect When watching TV programs (broadcast, the theater speakers to the Home Theater cable or satellite), the TV normally plays sound...

  • Page 95: Compact Disc Changer

    SECTION 8 – ENTERTAINMENT The TV operates from 120-volt AC household Enter current only, so you must have either the shoreline connected, the generator running, or the ENTER inverter turned on (if equipped). Play/Pause The DVD player is connected to the TV and plays through the TV stereo speakers.

  • Page 96: Tv Signal Amplifier

    SECTION 8 – ENTERTAINMENT See the antenna manufacturer’s operation, Turn elevating crank (counterclockwise) in care and maintenance information in your “DOWN” direction until resistance is noted InfoCase. (about 13 turns). Antenna is now locked in travel position. Turn amplifier power switch “OFF”. WARNING CAUTION Never allow the antenna to touch...

  • Page 97: Cable Tv, Satellite And Phone Hook-Ups

    A second connection may be included in an overhead cabinet in the bedroom for the rear TV, if equipped. See your authorized Winnebago Industries dealer for proper installation and sealing of roof mounted components.

  • Page 98: Tv Digital Satellite Dish - In-Motion

    SECTION 8 – ENTERTAINMENT • Satellite seeking time can be reduced by setting the region code for your current location. Codes are shown in the manufacturer’s operating information. Automatic Satellite Dish Control • See the In-Motion Satellite System owner’s manual in your InfoCase for for complete •...

  • Page 99: Furniture And Softgoods

    SECTION 9 – FURNITURE AND SOFTGOODS LOUNGE CHAIR BASE CLAMP TABLE AND CHAIRS –If Equipped While the vehicle is in motion, the base of the lounge chair must be fastened into position with Dinette Chairs a clamp on the floor as shown. The dinette chairs are free-standing to allow greater freedom of movement than typical booth style dinettes or pedestal seats.

  • Page 100: Sleeping Facilities

    SECTION 9 – FURNITURE AND SOFTGOODS Buffet Chairs WARNING Be sure all free-standing chairs and furniture items, and all other loose items are secured or stored properly while the vehicle is in motion. Possible overlooked items such as canned goods or small appliances on the countertop, cooking pans on the range can also become dangerous projectiles during a sudden...
  • Page 101 SECTION 9 – FURNITURE AND SOFTGOODS 2. Release the catch on the table leg brace and fold the leg up against the bottom of the table. Bed to Dinette: 3. Remove the table from the wall support 1. Reattach the table onto the wall support and bracket by lifting the end of the table.

  • Page 102: Sofa/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS REST EASY MULTI-POSITION LOUNGE –If Equipped 3. Refit the seat support ‘bumpers’ onto the seat frame. CAUTION Do not recline the lounge completely flat unless the footrest section is extended. To Recline 1. Press the switch on the front of the armrest. SOFA/BED CONVERSION Press ‘down’...
  • Page 103 SECTION 9 – FURNITURE AND SOFTGOODS Tip for “power users” • If you have the footrest section unlatched and positioned against the seat cushion, it will move out with the lounge when you press the recline switch. • When you return to upright position, you can hook your heels over the front edge of the footrest section and pull it back with you.

  • Page 104: Sleep Number® Bed

    SECTION 9 – FURNITURE AND SOFTGOODS Sun Filter The lower section is a translucent white shade WARNING that can be lowered for privacy without darkening the inside of the coach. It can also filter out harsh direct sunlight to help keep the inside of To avoid injury to young children, do not the coach cool in summer or to disperse light for allow them to operate the sofa, or to play...

  • Page 105: Wood Furniture And Cabinetry

    People are drawn to the natural beauty of and the wood is considered part of the natural wood. At Winnebago Industries, our craftsmen aging process and is not to be considered defect work with the art found in each piece of wood to or damage.

  • Page 107: Slideout Rooms And Leveling

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING To Release: SLIDEOUT ROOM TRAVEL • Press and hold the ‘unlock’ side of the LOCKS Slideout Lock switch for about 7 seconds. (You may be able to hear the lock motor sound –If Equipped stop.) Some models are equipped with electric To Lock:...

  • Page 108: Slideout Room Operation - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING alternator can provide maximum power SLIDEOUT ROOM OPERATION for proper operation of the slideout – ELECTRIC mechanisms. WARNING WARNING Keep all persons clear of the slideout Your motor home may have more than room and moving parts while extending or one slideout room.

  • Page 109: Slideout Room - Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Insert the Safety Lock key and turn to activate by raising both right side jacks to let excess water slideout room control switch flow away from the rooftop weather seal and toward the outside of the slide-out roof. Retract •...

  • Page 110: Slideout Room Troubleshooting - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Green light will flash error code if system malfunctions* Slideout Cover-Awning Also, freezing rain and snow can prevent the slideout cover-awning (if equipped) from closing and may cause damage to the cover-awning, slideout room, weather seals and mechanisms. Diagnostics Red light will flash if Reset Button*...

  • Page 111: Slideout Emergency Retraction

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING While in the Manual Mode each of the two, If an error is detected, the green LED on the room slide arms are activated by pressing and left side of the control panel will blink an error holding the IN and OUT buttons.

  • Page 112: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Disengage the motor brakes, which appear as • Fasten slideout room travel latching device–if a flat ‘square’ protrusion on the protective equipped–inside the coach before driving the boot at the end of each motor. Move the brake vehicle.

  • Page 113: Leveling System

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING LEVELING SYSTEM –If Equipped The hydraulic leveling system makes selecting a parking site easier and faster by reducing the effect of uneven ground. Hydraulic jacks raise the affected low corners of the coach to make leveling “set up” faster and easier for you.
  • Page 114 Auto Level Switch recommended that you take your RV into an (Located in Service Center compartment) ® authorized Winnebago Industries dealership for a complete leveling system inspection before using again. Jacks Down Light The “Jacks Down”...

  • Page 115: Checking Hydraulic Oil Level

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING CHECKING HYDRAULIC OIL LEVEL See your Leveling System Operators Manual for complete maintenance instructions and information. All maintenance should be done as part of the normal servicing of the coach. The hydraulic oil level should be checked when the vehicle is first purchased and then once every two years–...
  • Page 116 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Hydraulic Fluid Recommendation Universal multipurpose hydraulic oil is recommended for use in this system. DO NOT USE brake fluid or hydraulic jack oil, which can damage the seals and cause leaks. NOTE: In an emergency, Dexron type automatic transmission fluid can be used.

  • Page 117: Maintenance And Storage

    • Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.

  • Page 118: Exterior Automotive Paint Finish

    SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
  • Page 119 SECTION 11 – MAINTENANCE AND STORAGE Bug Removal to clean heavy road films on semi trailers and are often dirty. They are not • Rinse the loose debris off with water and designed for custom painted RV’s and allow the remaining residues to soak and they will scratch the clearcoat finish.

  • Page 120: Care Of Appliques And Decals

    SECTION 11 – MAINTENANCE AND STORAGE is subjected to various twisting and flexing forces • Fuel or antifreeze spilled on appliques or caused by routine cornering and turning, and by decals should be rinsed off immediately with uneven road surfaces, such as bumps, potholes, water.

  • Page 121: Exterior Lights

    SECTION 11 – MAINTENANCE AND STORAGE EXTERIOR LIGHTS CAUTION Most Winnebago Industries vehicles have polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical DO NOT use citrus based cleaners on solvents and cleaners. polycarbonate finishes.

  • Page 122: Cabinetry - Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE shades should be closed when the motor home is parked for an extended period of UltraLeather HP™ Cleaning Chart time. Detergent/ Cleaner/ Type of Stain Water Degreaser Coffee, Tea WARNING Red Wine, Liquor Cola, Soft Drinks Milk When cleaning upholstery and fabric, do not use lacquer thinner, nail polish...

  • Page 123: Solid Surface Countertop - Corian

    SECTION 11 – MAINTENANCE AND STORAGE NOTE: Many cabinetry and furniture items surface using the same cleaning material and throughout this motor home are scrubbing method to maintain a uniform constructed either partially or appearance. completely of real hardwoods. Because If you prefer a glossier look, follow up with of natural variations in woodgrain a good quality furniture polish or a liquid...

  • Page 124: Galley Sink

    SECTION 11 – MAINTENANCE AND STORAGE Restoration BATHROOM Clean first, then apply non-toxic mineral oil to restore board’s natural beauty. Toilet For instructions on the care of your toilet, refer to the information in your InfoCase. GALLEY SINK Tub and Shower Walls Stainless Steel The tub and shower walls in the bathroom Care &...

  • Page 125: Vehicle Storage - Preparation

    SECTION 11 – MAINTENANCE AND STORAGE Use care when removing ice or frost from the maintenance especially in cold weather. windows. Always use a plastic ice scraper, never See “Battery Care” in the Electrical one made of metal. Use care when removing ice section.

  • Page 126: Chassis Service And Maintenance

    SECTION 11 – MAINTENANCE AND STORAGE 5. Close all faucets and drain valves that are See Sealants – Recommended Application open. page at the end of this section. Also inspect weather seals around doors, etc., 6. Add a few gallons of water to the fresh water and if necessary, have a dealer replace tank and turn on the water pump to check for immediately.

  • Page 127: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System Have propane gas system checked for leaks.
  • Page 128 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items Headlights, Taillights and Marker Lights Turn Signals...
  • Page 129 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants Inspect (see “Sealants”...

  • Page 130: Sealants - Recommended Application

    SECTION 11 – MAINTENANCE AND STORAGE SEALANTS – RECOMMENDED APPLICATION 11-14...

  • Page 131: Miscellaneous

    SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motor home’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available CAUTION space when loading your motor home.
  • Page 132 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motorhome is to weigh each ‘corner’...

  • Page 133: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction Section exceed 6,000 lbs. for information on gross weight ratings.

  • Page 134: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS Before descending a steep or long grade when TRAILER WIRING towing a trailer, reduce speed and shift into a CONNECTOR lower gear to control vehicle speed. Avoid prolonged or frequent application of brakes Your coach is pre-wired for trailer or car which could cause overheating and brake failure.

  • Page 135: Entry Step - Electric

    GCWR is typically specified NOTE: Some Winnebago Industries models based on durability and performance of the tow equipped with a Class 3 hitch may have a...

  • Page 136: Stepwell Cover - Electric

    SECTION 12 – MISCELLANEOUS Automatic Mode - Entry Step Switch ON (Step Operates with Door) With the Step switch in the ON position the step is in Automatic Mode. This means it will extend and retract automatically whenever the screen door is opened or closed. Stationary Extended Mode - Step Switch OFF (Step Remains Extended)

  • Page 137: Tool And Ladder Storage

    SECTION 12 – MISCELLANEOUS CAUTION Do not use Emergency Retract feature unless necessary for emergency. Operation of the Emergency Retract feature will cause the step cover to become non-functional until the cable mechanism is reconnected by your dealer. An emergency cable release is connected to a Pull chain to release step mechanism black plastic snap-in plate labeled “Emergency and manually slide step cover back.

  • Page 138: Storage Compartment Doors

    SECTION 12 – MISCELLANEOUS The ladder on your motor home is provided STORAGE COMPARTMENT for limited access to the roof. DOORS Walking or working on the roof should be left to qualified service personnel using proper safety The high-density gaskets used on the exterior equipment in a safe environment.

  • Page 139: Windows

    SECTION 12 – MISCELLANEOUS The Wind Sensor is preset to retract the WINDOWS awning at 18 mph, but you can adjust this setting to your preference in several increments from 12 Crank-Out Windows to 24 mph. You can also turn the Wind Sensor Turn the crank-out knob clockwise to open off at your own discretion, if you wish.

  • Page 140: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS Vertical Slider Windows To Operate Ceiling Ventilator Vertical windows have spring-loaded catches 1. Turn the Dome Crank Knob to raise the dome on both sides of the window that pop out to hold about 3" or more to allow the turbine fan to the window in its fully raised position.

  • Page 141: Effects Of Prolonged Occupancy

    SECTION 12 – MISCELLANEOUS Ventilate with outside air: Partially open one or more windows and a roof vent to circulate outside air through the coach. In cold weather, this ventilation may increase use of the furnace, but it will greatly reduce the condensation inside the coach.
  • Page 143 INDEX 2008 New Vehicle Limited Warranty ..1-7 Electrical Cautions ........6-1 About this Manual ........1-1 Electrical Generator ........6-6 Air Conditioner Filter ........ 4-12 Electrical Outlets – House 120-Volt AC ..6-5 Air Conditioner/Heater – Electrical System – House 120-Volt AC ..6-1 Automotive (Dash) ........
  • Page 144 Index Interior Soft Goods ........11-5 Rest Easy Multi-Position Lounge ....9-4 Inverter/Charger Unit – 2000W ....6-3 Roadside Emergency ........2-8 Jump Starting ..........2-9 Roof ............11-1 Key One Lock System ......... 3-4 Roof Ladder ..........12-7 Leveling System ........10-7 Safe Use of the Propane Gas System ...
  • Page 145 Index TV Digital Satellite System – Automatic ..8-5 TV Digital Satellite System Wiring ..... 8-5 TV Signal Amplifier ........8-4 Undercarriage ..........11-1 Utility Light ..........7-2 Vehicle Certification Label ......1-3 Vehicle Storage – Preparation ....11-9 Vehicle Storage – Removal ....... 11-9 Video Selection System .......

This manual is also suitable for:

Journey

Table of Contents

Save PDF
