Page 1 MOTOR HOME SERIAL NUMBER VEHICLE CHASSIS IDENTIFICATION NO. (VIN) DATE OF DELIVERY TO FIRST RETAIL PURCHASER VEHICLE MILEAGE AT TIME OF DELIVERY SELLING DEALER NAME AND ADDRESS EMERGENCY INFORMATION YOUR WINNEBAGO INDUSTRIES DEALER Name ____________________________________________________________________________ Address __________________________________________________________________________ _________________________________________________________________________________ Contact Person _____________________________________________________________________ Phone ____________________________________________________________________________...
Page 2 WINNEBAGO INDUSTRIES’ RESPONSIBILITY Winnebago Industries, Inc. of Forest City, Iowa warrants each new Winnebago Industries motor home to the owner for use in the U.S.A. Any part of the vehicle subject to warranty which is found to be and Canada as follows: defective in material or workmanship, will be repaired or replaced at Winnebago Industries’...
Page 3 CHANGES IN DESIGN Winnebago Industries, Inc. reserves the right to make changes in design and changes or improvements upon its products without imposing any obligation upon itself to install the same upon its products theretofore manufactured.
Page 4 TABLE OF CONTENTS Section One ....................Specifications Section Two ..................... Introduction Section Three.............. Getting to Know Your Motor Home Section Four ..................Roadside Emergency Section Five......................Dash/Auto Section Six................... Appliances & Equipment Section Seven ................Heating & Air Conditioning Section Eight ....................LP Gas System Section Nine .....................
Page 5 SECTION 1 SPECIFICATIONS TANK CAPACITIES Chassis Fuel Tank 22’ models only ....................37 gal. All models 24’ or longer ..................55 gal. LP Gas Tank All Models ................14 gal.* (18 gal. w.c.) Fresh Water Tank Models 322E & 322R ..................28 gal. Model 324F......................32 gal. Models 324V &...
Page 6 BODY & CHASSIS SPECIFICATIONS Model 322E 322R 324F 324V 326A 327L 329B 329K 331C 332G Length (Bumper to Bumper) 22’ 1” 22’ 1” 24’ 7” 24’ 7” 27’ 1” 27’ 11” 29’ 4” 29’ 4” 31’ 4” 32’ 1” Interior Width 8’...
Page 7: About This Manual
IMPORTANT: Before driving your vehicle, be ual are intended as a guide, and in no way extend sure you have read the entire operator’s manual the responsibilities of Winnebago Industries and that you understand your vehicle’s equip- beyond the standard written warranty as pre- ment completely and how to use the equipment sented in this manual.
Page 8: Options And Equipment
SECTION 2 INTRODUCTION maintenance instructions for the various appli- ances and components in your motor home. DANGER Warranty registration cards for these items should be filled out and mailed as soon as possi- DANGER indicates a directly hazard- ble after you take delivery of your motor home. ous situation which, if not avoided, If you do not have operating instructions for a will result in death or serious personal...
Page 9: Reporting Safety Defects
SECTION 2 INTRODUCTION brakes, driving a motor home is different from (NHTSA) in addition to notifying Winnebago In- driving a car. A motor home is larger and heavier dustries, Inc. than an automobile, so it requires more stopping If NHTSA receives similar complaints, it may...
Page 10: Vehicle Certification Label
(listed in pounds and kilograms). signifies a Multi-purpose Passenger Vehicle. 6. Suitable Tire Choice: Tires recommended to 13. Model: Lists the Winnebago product model meet handling and safety requirements. number of your vehicle. When replacing any of the tires on your 14.
Page 11: General Warnings
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME • Driving through water deep enough to wet Read and understand all instructions and pre- cautions in this manual before operating your the brakes may affect stopping distance or new motor home. cause the vehicle to pull to one side.
Page 12: Emergency Exits
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME The best protection against carbon monoxide Monthly Testing entry into the vehicle body is a properly main- Press the TEST button on the face of the alarm tained engine exhaust and ventilation system. It is at least monthly to check the function of the recommended that the exhaust system and body alarm and condition of the battery.
Page 13: Fire Extinguisher
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME We recommend that you become thoroughly familiar with the operating instructions displayed Lift latch handles upward to open. on the side of the fire extinguisher or in the infor- Escape Window mation supplied in your Owner InfoCase. We also recommend that you inspect the fire extinguisher for proper charge at least once a WARNING...
Page 14: Keyless Entry System
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME SEATS The driver and co-pilot seats may be indepen- dently adjusted to suit individual preference. To Recline the Seats Lift the reclining lever, lean back to desired incline and release the lever. To return to the up- right position, lift the lever and lean body for- ward.
Page 15: Seat Belts
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME WARNING SEAT BELTS Seats intended for occupancy while the vehi- cle is in motion are equipped with seat belts for Do not adjust driver’s seat while vehi- the protection of the driver and passengers. cle is in motion.
Page 16: Child Restraints
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME position and release the lever. A ratchet- ing mechanism will allow the belt to be WARNING pushed upward but not pulled down- ward. Snug and low belt positions are essential. This will ensure that the force exerted by the lap belt in a colli- sion is spread over the strong hip area and not across the abdomen, which...
Page 17: Loading The Vehicle
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME erly restrained in rear seating positions than in Side Mirror Head Adjustment front seating positions. While sitting properly in the driver seat and When purchasing a child restraint system: the mirror arms extended normally, have a helper grip the mirror head by opposite upper and lower 1.
Page 18 SECTION 3 GETTING TO KNOW YOUR MOTOR HOME right side weighs 2,700 lbs., at least 100 lbs. of front wheels onto the scale pad, then drive ahead the load should be shifted from the left side to the so that the whole vehicle is on the scale, then right side.) The GVWR is listed on the Vehicle finally pull off until just the rear wheels are on Certification Label.
Page 19: Roof Loading
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME Tires should be filled to the recommended Corner Weighing (Side-to-Side) air pressure for the highest loaded tire set on that Weighing each corner of the coach sepa- axle. For example, on the rear axle, if the left rately (single L/R front wheels or L/R rear dual side weighs more than the right, fill the left tires sets) is an accurate method to determine how to...
Page 20: Storage Compartment Doors
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME Tire Tools CAUTION Observe the engine temperature gauge more frequently than normal. If overheating occurs, pull off to the side of the road and allow the engine to thoroughly cool before refilling the radiator and restarting the engine.
Page 21: Preparing Vehicle For Storage
SECTION 3 GETTING TO KNOW YOUR MOTOR HOME 6. After charging batteries, turn the Aux. Bat- Ventilate with Outside Air tery Switch off to disconnect the batteries Partially open one or more windows and a and avoid parasitic* drain. roof vent to circulate outside air through the 7.
Page 22 SECTION 3 GETTING TO KNOW YOUR MOTOR HOME 3. Check window operation. 4. Check cabinet and door hinges. Lubricate with penetrating oil, if necessary. 5. Close all faucets and drain valves that are open. If necessary, reconnect toilet water line and close flush valve.
Page 23: Recovery Towing
SECTION 4 ROADSIDE EMERGENCY IF YOU GET A FLAT TIRE Spare Tire Storage When you experience a tire failure, it creates a side force that pulls the vehicle in the direction 22’ Models: of the failed tire. Unfortunately, many people The spare tire is fastened to a carrier bracket make the situation worse by slamming on the on the backwall of the coach.
Page 24: Jump Starting
(wheel lift or frame lift) type towing assembly for safe towing. ENGINE OVERHEAT Winnebago Industries does not assume re- If you see or hear steam escaping from the sponsibility for damage incurred while towing engine compartment or have any other reason to this vehicle.
Page 25: Instrument Panel Gauges And Controls
SECTION 5 DASH / AUTO INSTRUMENT PANEL GAUGES AND CONTROLS CRUISE CONTROL See your chassis owner's manual for detailed The electronic speed control (cruise) allows information on the instrument gauges, steering you to maintain a steady speed and relieve driv- column controls, brakes, and other chassis equip- ing strain while traveling long distances.
Page 26: Comfort Controls
SECTION 5 DASH / AUTO TEMP CONTROL - Blue = Cold / Red = Warm If your motor home is equipped with this Mode Selector Positions: optional system, refer to the Owner InfoCase for further instructions provided by manufacturer. Max A/C - Cab air is recirculated (and re-cooled) through air conditioner.
Page 27: Radio Power Switch
SECTION 5 DASH / AUTO An additional hand-held remote allows these same conveniences for the passenger. The hand- held radio remote is in your owner InfoCase. Radio Power Switch The radio power switch lets you connect the dash radio to the coach batteries with the ignition switch turned off for listening while parked.
Page 28 SECTION 6 APPLIANCES & EQUIPMENT NOTE: Some items described in this section may be optional and, therefore, may not be in your vehicle. The appliances installed in your motor home are manufactured by reputable RV appliance makers and have been tested by independent lab- oratories to meet all applicable standards and codes set for RV appliances.
Page 29: Operating Tips
SECTION 6 APPLIANCES & EQUIPMENT “Diagnostic” section of the “Refrigerator Opera- tor’s Guide” in your Owner InfoCase. Auto and Manual Modes - Gas Operation Only If the gas does not ignite within 30 seconds, which may occur on initial start-up, the refriger- ator’s gas valve will automatically close and the operating controls will select an alternate power source (AUTO Mode) or revert to a stand-by...
Page 30: Refrigerator Compartment
SECTION 6 APPLIANCES & EQUIPMENT • Use smaller containers for each item. (e.g. a To Close: half gallon container of milk instead of a half- 1. Replace the door into the opening. full gallon jug) 2. Push the latch knobs in while turning to the •...
Page 31 SECTION 6 APPLIANCES & EQUIPMENT WARNING Portable fuel-burning equipment including wood and charcoal grills and stoves, should not be used inside the recreational vehicle. The use of this equipment inside the recreational vehicle may cause fires or asphyxia- tion. WARNING Lighting Range Top Burners Do not turn burner control knob to 1.
Page 32: Operating Oven Control
SECTION 6 APPLIANCES & EQUIPMENT Lighting oven pilot (when pilot is located on left side of burner.) Operating Oven Control Push in and turn the oven control knob (coun- terclockwise) to the desired temperature setting. There is a delay of about 45 seconds before the main burner ignites.
Page 33: Section
SECTION 6 APPLIANCES & EQUIPMENT tional information on the water pump and initial Water And Holding Tank Levels start-up. (There is also a pump switch in the water Press and hold the “Levels Test” switch to system compartment on the outside of the coach.) show approximate level on the monitor lights.
Page 34 SECTION 6 APPLIANCES & EQUIPMENT valve. This is no cause for repair or replacement of the valve. 2. If “Pilot Out” light stays on longer than 15 Water Heater Exterior Service Access seconds, place switch in “Off” position and Normally there is an air gap at the top of the wait 5 minutes.
Page 35 SECTION 6 APPLIANCES & EQUIPMENT 4. Let the handle of the P-T valve snap shut. 5. Close the faucet and turn on the water supply before switching the water heater on. Manually operate the pressure temperature re- lief valve at least once a year. Water Heater By-Pass Valve Your coach may be equipped with a water heater by-pass valve for easier winterization of...
Page 36: Section
SECTION 7 HEATING & AIR CONDITIONING NOTE: Metal coatings used during manufacture LP GAS FURNACE of the furnace burner parts may smoke when the furnace is used for the first Start Up: time, which may also set off your smoke 1.
Page 37 SECTION 7 HEATING & AIR CONDITIONING OPERATION The following chart shows the system functions with the “Heat/Cool” thermostat. Disregard refer- ences to heat functions when using the “Cool Only” thermostat in the rear bedroom.
Page 38 SECTION 7 HEATING & AIR CONDITIONING the inside temperature falls five degrees below the set point, the furnace will assist HEAT PUMP - Optional the heat pump until the set point is reached. Your coach may be equipped with an air source heat pump built into the air conditioning If the furnace must assist the heat pump three system.
Page 39 SECTION 7 HEATING & AIR CONDITIONING Refer to the manufacturer’s information in your Owner InfoCase for complete operating instructions. NOTE: The ducted roof air conditioning system has ceiling registers that can be closed if necessary to force more cool air toward a specific area of the coach or to route cool air away from a specific area.
Page 40: How Lp Gas Works
SECTION 8 LP GAS SYSTEM LP GAS SUPPLY The LP gas system supplies fuel for the range, water heater, furnace and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel. How LP Gas Works LP (Liquified Petroleum) gas is a true gas compressed into liquid form for easy transporta-...
Page 41: Power Connection
SECTION 8 LP GAS SYSTEM on LP system after filling. Make sure valve is See the LP Gas Alarm manufacturer’s infor- closed and door latched securely. mation in your Owner InfoCase for complete in- • Never connect natural gas to the LP gas sys- structions.
Page 42: Safe Use Of The Lp Gas System
SECTION 8 LP GAS SYSTEM • Exercise caution at all times. Be familiar with draw is slight, it could drain the coach battery during storage periods when the house battery the distinctive odor of LP gas. If a leak is sus- will not be charged regularly by the engine or pected, turn off the supply valve immediate- shoreline.
Page 43: Refilling Lp Tank
SECTION 8 LP GAS SYSTEM yellow pages for locations of local LP gas refill- ing stations or bulk dealerships. WARNING NOTE: If you travel outside the U.S. with your motor home, you may find butane or pro- Make sure the filling attendant uses pane/butane mixtures available in addi- the 80% overflow valve when filling tion to propane.
Page 44: Travel With Lp Gas
SECTION 8 LP GAS SYSTEM WARNING TRAVEL WITH LP GAS It is illegal for vehicles equipped with LP DO NOT FILL CONTAINER TO tanks to travel on certain roadways or through MORE THAN 80 PERCENT OF certain tunnels in the U.S. To avoid inconve- CAPACITY.
Page 45 SECTION 8 LP GAS SYSTEM In very cold weather when a large volume of gas is being used for heating, it is possible to ex- perience a loss of gas pressure. At first, this prob- lem may appear to be caused by a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed.
Page 46: Electrical Cautions
SECTION 9 ELECTRICAL SYSTEMS Your coach is equipped with an electrical sys- current to 12-volt DC current. All equipment in tem consisting of two separate voltages; a 12-volt the motor home that is normally powered by the DC system and a 110-volt AC system. The 12- auxiliary batteries is then powered through the volt system consists of two internal power sourc- converter.
Page 47: Power Center (Converter)
SECTION 9 ELECTRICAL SYSTEMS your vehicle, from electrical damage. If electrical power fails, contact the park attendants and have them check the fuse or breaker for your supply receptacle. After disconnecting the power cord, neatly re- place it in the storage compartment. POWER CENTER (Converter) The power center changes 110-volt AC cur- rent from the auxiliary generator or the shoreline...
Page 48: Volt Circuit Breakers
SECTION 9 ELECTRICAL SYSTEMS NOTE: The converter will not change 12-volt DC current to 110-volt AC. WARNING 110-Volt Circuit Breakers The breaker panel protects all 110-volt com- Do not store anything around or on ponents in the motor home from either an over- top of the converter, or in front of the load on the circuit or a short in the wiring or cover.
Page 49: Ground Fault Circuit Interrupter
SECTION 9 ELECTRICAL SYSTEMS GROUND FAULT CIRCUIT AUXILIARY 110-VOLT INTERRUPTER GENERATOR Bath, galley and exterior outlets are connected Consult the information provided in your to a GFCI (Ground Fault Circuit Interrupter), Owner InfoCase for instructions on operation, which is an extremely sensitive circuit breaker troubleshooting and maintenance.
Page 50: Operation Warnings And Cautions
SECTION 9 ELECTRICAL SYSTEMS automotive battery, so the switch will operate whether the ignition switch is on or off. Approximate Power Requirements of Consult the generator owner’s manual in your Common Appliances Owner InfoCase for specific instructions on start- Appliance or Tool Approximate Power ing and stopping your generator.
Page 51: Volt Dc System
SECTION 9 ELECTRICAL SYSTEMS 3. Park the vehicle so that the wind will carry the frequent drain-and-recharge cycles that occur the exhaust away from the vehicle. Also, under the demanding conditions of a camping note the position of other vehicles to be sure outing.
Page 52: Volt House Fuses And Circuit Breakers
SECTION 9 ELECTRICAL SYSTEMS WARNING Refasten the retainer strap when returning the battery to the compart- ment. Auxiliary Battery (Aux. Batt) Switch The AUX BATT switch disconnects the aux- • The inverter must be switched on to operate. iliary (coach) batteries from the 12-volt system of •...
Page 53: Battery Storage And Maintenance
SECTION 9 ELECTRICAL SYSTEMS BATTERY STORAGE AND MAINTENANCE Lead -acid type batteries are electro-chemical devices for storing and releasing electrical charge. As such, they are simply an electrical reservoir, not an electrical source. As soon as energy is removed from the battery, it should be replaced by the engine alternator or the RV Chassis and House 12V Circuit Breakers behind cover converter system.
Page 54 SECTION 9 ELECTRICAL SYSTEMS NOTE: We do not recommend leaving the shore- line plugged in continuously during WARNING storage periods because the batteries can lose electrolytic fluids and become damaged from continuous charging Before removing any battery cables or without periodic use or maintenance. battery, make sure all 12-volt equip- ment in the motor home is off and the We recommend following regular bat-...
Page 55: Electric Entrance Step
SECTION 9 ELECTRICAL SYSTEMS WARNING To prevent wiring damage, it is essential when replacing the cables on the battery, or when using a “booster” battery, that the positive post and the positive cable be attached and the negative post and negative cable be attached.
Page 56 SECTION 9 ELECTRICAL SYSTEMS Switch is On or Off. This feature is intended to prevent injury or damage caused by an extended step when the vehicle is moving. WARNING Do not use step unless it is fully extended. Do Not Stand on step when vehicles ignition switch is turned to either the “On”...
Page 57: Fresh Water System
SECTION 10 PLUMBING SYSTEMS demand pump is designed to run only when you FRESH WATER SYSTEM are using water. This is what happens when you The fresh water system provides water to the turn a faucet on - the water line pressure drops galley sink, shower, bathroom lavatory, toilet and and the pump begins to run, and it will continue water heater.
Page 58 SECTION 10 PLUMBING SYSTEMS • Remove the bowl and pull the strainer screen one that may have become contaminated. This out of the bowl to tap out any particles and procedure is also recommended before long rinse clean. periods of storage such as over winter. •...
Page 59: Shower Hose Vacuum Breaker
SECTION 10 PLUMBING SYSTEMS To Disconnect From the External Source: EXTERNAL WATER 1. Turn the external source off. SUPPLY (“City Water”) 2. Open a faucet inside the vehicle to relieve line pressure. To Connect to an External Source: 3. Disconnect the hose from the vehicle and 1.
Page 60 SECTION 10 PLUMBING SYSTEMS way down and hold until desired amount has been added. Release pedal slowly. Please refer to the manufacturer’s information supplied with the toilet for further operating and maintenance instructions. Exterior Shower/Wash Station Models 322E & 329B/K Important “Don’ts”...
Page 61: Waste Water System
SECTION 10 PLUMBING SYSTEMS icone spray.Turn the water pump off and NOTE: Do not open the gray water valve until operate flush pedal to drain water from the the black water tank is drained and dump toilet bowl. Spray silicone lubricant onto valve closed to avoid sewage back-up flush valve inside bowl and operate flush into gray tank.
Page 62: Water Line & Tank Drain Valves
SECTION 10 PLUMBING SYSTEMS in suspension, allowing them to be carried out NOTE: The holding tank heater pads are electri- with the liquids when the dump valve is opened. cal resistance type heating elements. If the valve is left open, the liquids will drain off, This type of heating element typically leaving solids in the tank.
Page 63: Water System Drain Valve Locations
SECTION 10 PLUMBING SYSTEMS Water Tank Drain Valve Water Tank Drain Valve (Typical) Under Rear Bed or Couch WATER SYSTEM DRAIN VALVE LOCATIONS MODEL SYSTEM DRAIN VALVE LOCATIONS 322R Water Lines: Two (2) valves beneath front dinette seat. Lift seat board to access.
Page 64 SECTION 10 PLUMBING SYSTEMS WATER SYSTEM DRAIN VALVE LOCATIONS MODEL SYSTEM DRAIN VALVE LOCATIONS 322E Water Lines: Two (2) valves beneath the shower base. Remove access panel on the lower left front of the shower cabinet. Water Tank: One (1) valve beneath the rear of the couch. Lift couch to access.
Page 65 SECTION 10 PLUMBING SYSTEMS WATER SYSTEM DRAIN VALVE LOCATIONS MODEL SYSTEM DRAIN VALVE LOCATIONS 324V (with rear Water Lines: Two (2) valves beneath shower. Access through removable dinette) panel on lower front of shower cabinet. Water Tank: One (1) valve beneath the dinette cushion along the back- wall.
Page 66 SECTION 10 PLUMBING SYSTEMS WATER SYSTEM DRAIN VALVE LOCATIONS MODEL SYSTEM DRAIN VALVE LOCATIONS 327L Water Lines: Two (2) valves in exterior storage compartment ahead of left (driver) side rear wheels. Exterior Open exterior shower knobs and lay shower head on ground. Shower: NOTE: If coach is not equipped with exterior shower, there are two drain valves below the metal face panel on the left...
Page 67 SECTION 10 PLUMBING SYSTEMS WATER SYSTEM DRAIN VALVE LOCATIONS MODEL SYSTEM DRAIN VALVE LOCATIONS 331C Water Lines: Two (2) valves beneath the removable bottom panel in the bathroom lavatory cabinet. Two (2) valves beneath the queen bed or driver side twin bed.
Page 68: Winterizing Procedure
(A “blow-out” the filter cartridge and install the divert- plug can be purchased at any Winnebago or er plug supplied. The cartridge is located Itasca dealer. P/N 701705-01-000.) beneath the galley sink counter.
Page 69 SECTION 10 PLUMBING SYSTEMS waste holding tanks of any clean water that entered during “blow-out” procedure. Close dump valves to prevent valve shafts City Water Connection from rusting and to prevent entry by rodents and insects. Refit the dust cap onto the drain outlet.
Page 70 SECTION 10 PLUMBING SYSTEMS Winterization Valve Your coach is equipped with a manually CAUTION operated water line winterization system for your convenience in winterizing fresh water Leave by-pass valve handle in NOR- lines. MAL FLOW position if draining The system features a diverter valve and suc- water and blowing out water lines.
Page 71 SECTION 11 ENTERTAINMENT IN-DASH RV RADIO Components Each component has a set of buttons that lets See Section 5 you select which source you want to get the pic- ture signal from, whether cable TV, roof antenna, digital satellite dish, VCR/DVD or whatever SWING OUT TV MOUNTS equipment you have connected to the AUX input.
Page 72: Tv Antenna
SECTION 11 ENTERTAINMENT HOME THEATER SYSTEM - Optional The home theater system operates from 110V AC household current only, so you must have ei- ther the shoreline plugged in, or the generator running or the inverter turned on. The sound from this system emits from the five surround sound cube speakers located near the ceiling in the lounge area of the coach.
Page 73: Cable Tv Hook-Up
SECTION 11 ENTERTAINMENT To operate amplifier, turn on power switch. WARNING Never allow the antenna to touch electrical power lines or any other electrical wires. Rotating Antenna - Make sure antenna is in the “UP” position. Pull down on rotating knob until it disengages ceiling plate and rotate for best picture and sound on TV set.
Page 74 Hookup jacks are located in the left or right front overhead com- partment, depending on model. See your autho- rized Winnebago Industries dealer for proper installation and sealing of roof mounted compo- nents. Digital Satellite Dish Control...
Page 75: Exterior Entertainment Center
SECTION 11 ENTERTAINMENT Interior Connection for Satellite Dishes Exterior Entertainment Center TWO-WAY RADIOS - Optional If your coach is equipped with the available two-way radios, the charger/docking bay is locat- ed on a cabinet end near the entrance door - for easy access as you head out the door.
Page 76: Sleeping Facilities
SECTION 12 FURNITURE & SOFTGOODS SLEEPING FACILITIES WARNING Do not use sleeping facilities while vehicle is moving. Overhead Front Bunk (If equipped) The overhead front bunk is located above the Front Bunk Ladder driver’s compartment. The rear mattress section is stored on top of the front section when not in Shown hooked into mattress bracket use.
Page 77 SECTION 12 FURNITURE & SOFTGOODS U-Shaped Dinette/Bed Conversion - Optional (Model 327L only) 2. Remove the table from the wall support The round dinette can be converted into addi- bracket by lifting the end of the table. Then tional sleeping space when needed by lowering lower the table to rest on the cleats attached the table and moving a cushion into place as to each dinette bench.
Page 78: Day/Nighter Pleated Blinds
SECTION 12 FURNITURE & SOFTGOODS DAY/NIGHTER PLEATED BLINDS 6. Place large, rounded back cushion into place Your coach may feature two-stage pleated over the table to complete the bed cushion window blinds that can be used for daytime or conversion. nighttime privacy.
Page 79: Slideout Room
SECTION 13 SLIDEOUT ROOM while the vehicle is in motion. It is not designed SLIDEOUT ROOM to withstand the force exerted by the room exten- The slideout living room provides a spacious sion mechanism and will not prevent accidental living area at the p nush of a button. The slideout extension of the room.
Page 80 SECTION 13 SLIDEOUT ROOM • Flip buckle downward and press toward strap Before Retracting the Slideout Room: until it “snaps” snugly into place against the 1. Be sure the coach is level and the Parking strap. Brake is set. • If a strap is loose or too tight after closing the 2.
Page 81: Troubleshooting
SECTION 13 SLIDEOUT ROOM • When the room has retracted completely, it section to determine the problem. The error code will stop automatically. must be cleared prior to operating the room. To • After the room has been retracted, refasten clear the error, press the “RESET”...
Page 82 SECTION 13 SLIDEOUT ROOM In the event of a total system failure where Manual Mode cannot be used, two crank handles may be used to retract or extend the room. Crank-In Mode: If the room will not retract using the buttons and the mechanism is apparently malfunctioning, you may need to manually crank the room in to the travel position.
Page 83 SECTION 13 SLIDEOUT ROOM If an error is detected, the green LED on the left side of the control panel will blink an error code. If an error code appears, see the On Board diagnostics section to determine the problem. The error code must be cleared prior to operating the room.
Page 84 SECTION 13 SLIDEOUT ROOM See your dealer for service of the slideout ERROR CODES system before using again. #Flashes Problem Description Further Information (ran for 60 sec with- See the DigiSync Slideout Room operating Unit Timed Out out reaching end of guide included in your Owner InfoCase for fur- stroke) ther instructions and troubleshooting informa-...
Page 85 SECTION 13 SLIDEOUT ROOM 4. The slotted end of the tool must engage with Emergency Crank-In Mode: the pin in the endshaft on the slideout gear (Model 327L) assembly. See arrow in close-up detail. If the room will not retract using the buttons and the mechanism is apparently malfunctioning, you may need to manually crank the room in to the travel position.
Page 86: General Slideout Care
SECTION 13 SLIDEOUT ROOM See your dealer for service of the slideout system before using again. Further Information See the Slideout Room operating guide in- cluded in your Owner’s InfoCase for further in- structions and troubleshooting information. GENERAL SLIDEOUT CARE •...
Page 87 • Have the sealant replaced if you notice any Corrosive materials, such as those used for ice of the above. Your local Winnebago Indus- and snow removal and dust control, also accumu- tries dealer has the correct and necessary late on the underside of a vehicle. These materi-...
Page 88: Exterior Finish
Appropri- smear colors. • Do Not use lacquer thinner on paint or decals. ate compounds are sold at Winnebago and Itasca dealers, and the materials are quickly and easily Do Not overcoat decals with clear paint.
Page 89: Upholstery, Carpeting And Draperies
SECTION 14 CARE & MAINTENANCE ty and effectiveness of the lamp and may re- home to prevent an accumulation of dirt which quire replacement of the complete lamp can detract from the appearance and shorten the housing. life of carpet and fabrics. •...
Page 90: Vinyl Fabrics
SECTION 14 CARE & MAINTENANCE or stain and work inward to avoid spreading it. chart on following page.) These materials are Use a clean cloth or sponge and turn frequently to made from polypropylene or polyester synthetic an unused area of the cloth or sponge as you fibers, so they clean very well with virtually no clean.
Page 91: Water Stains
SECTION 14 CARE & MAINTENANCE Type of Stain Cleaning Agent How to Remove Mustard Dry-Clean Solvent Scrub-Soak-Blot Dry Ketchup* High Strength Detergent Scrub-Soak-Blot Dry Coffee* High Strength Detergent Scrub-Soak-Blot Dry Chocolate* Detergent Scrub-Soak-Blot Dry High Strength Detergent Scrub-Soak-Blot Dry Chewing Gum Dry-Clean Solvent Scrub-Soak-Blot Dry High Strength Detergent...
Page 92: Vinyl Wallboard
SECTION 14 CARE & MAINTENANCE Vinyl simulated wood (Plus-Wood) panels may be cleaned with a mild, water based cleaner and a soft cloth. Do not use solvents on vinyl wood panels. NOTE: Many cabinetry and furniture items throughout this motor home are con- structed either partially or completely of real hardwoods.
Page 93: Doors And Windows
SECTION 14 CARE & MAINTENANCE The bathroom lavatory is also a molded com- posite material and should be cleaned with a mild soap and water solution. Abrasive cleaners or harsh detergents should not be used. The bath- room lavatory cabinet sink is made of the same composite material as the galley sink.
Page 94: Coach Maintenance Chart
SECTION 14 CARE & MAINTENANCE Coach Maintenance Chart These recommendations apply for normal recreational use. Heavy duty or full-time use may require more fre- quent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items Headlights, Taillights and Marker Lights Turn Signals...
Page 95 SECTION 14 CARE & MAINTENANCE Coach Maintenance Chart These recommendations apply for normal recreational use. Heavy duty or full-time use may require more fre- quent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. LP System (See Section 8) Have LP system checked for leaks.
Page 96 SECTION 14 CARE & MAINTENANCE Coach Maintenance Chart These recommendations apply for normal recreational use. Heavy duty or full-time use may require more fre- quent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants (See Section 14) Inspect (see Sect 14 for proper inspection technique).
Page 97: Engine Access
SECTION 15 CHASSIS CHASSIS SERVICE & MAINTENANCE WARNING Consult the appropriate sections in your chassis operating guide for specific information Make sure all replacement tires are of regarding operating safety, service recommenda- the same size and ply rating as those tions and maintenance schedules for the chassis installed as original equipment.
Page 98: Windshield Washers And Wipers
SECTION 15 CHASSIS The headlight circuit is protected by a circuit breaker. An overload on the breaker will cause REAR AIR SPRINGS the lights to flicker on and off. Headlight wiring Optional - 29’ & 31’ models should be checked immediately anytime this con- Check and adjust the air bag pressure periodi- dition is apparent.
Page 99: Car Or Trailer Towing
This is the maximum allowable weight of the motor home and loaded trailer, including the NOTE: Some Winnebago Industries models items noted in GVWR above. The “trailer” can equipped with a Class 3 hitch may have...
Page 100: Trailer Wiring Connector
SECTION 15 CHASSIS sible to parallel with the ground when attached to you took delivery of the vehicle. the hitch ball. The diagram shows proper connection of Installation of a proper trailer brake system is trailer or tow vehicle wiring to the coach light recommended.
Page 101: Table Of Contents
INDEX 110-Volt AC System........9- 1 Engine Access..........15- 1 110-Volt Circuit Breakers......9- 3 Engine Cooling System ......15- 1 110-Volt Receptacles (Outlets)..... 9- 3 Engine Overheat ........... 4- 2 12-Volt DC System (Batteries)..... 9- 6 Exterior Entertainment Center ....11- 5 12-Volt House Fuses and Circuit Breakers...
Page 102 INDEX Mountain Driving ........3- 10 Toilet............10- 4 Tool Storage ..........3- 9 Towing Guidelines........15- 2 Options and Equipment ........ 2- 2 Towing, Car or Trailer ....... 15- 3 Owner Infocase ..........2- 2 Trailer Wiring Connector ......15- 4 Travel with LP Gas ........
