Driving Safety ................................................................................................................................... 2-1

Fuel and Propane Gas ....................................................................................................................... 2-1

LP Gas Leaks .................................................................................................................................... 2-2

Propane Gas Leak Detector .............................................................................................................. 2-2

Carbon Monoxide Warning .............................................................................................................. 2-3

Carbon Monoxide Alarm .................................................................................................................. 2-3

Smoke Alarm .................................................................................................................................... 2-4

Fire Extinguisher ............................................................................................................................... 2-4

Electrical ........................................................................................................................................... 2-5

Loading ............................................................................................................................................. 2-5

Maintenance ...................................................................................................................................... 2-5

Emergency Exits ............................................................................................................................... 2-5

Formaldehyde Information ............................................................................................................... 2-6

Mold, Moisture, and Your Motor Home ........................................................................................... 2-6

Roadside Emergency ........................................................................................................................ 2-7

Jump Starting .................................................................................................................................... 2-8

Engine Overheat ............................................................................................................................... 2-8

3 - DRIVING YOUR MOTOR HOME

Seats - Driver/Co-Pilot ..................................................................................................................... 3-1

Passenger Footrest ............................................................................................................................ 3-2

Seat Belts .......................................................................................................................................... 3-3

Child Restraints ................................................................................................................................. 3-4

KeyOne™ Lock System ................................................................................................................... 3-5

Power Door Locks ............................................................................................................................ 3-5

Mirrors - Power Electric ................................................................................................................... 3-6

Rev. 0917090914

Part No. 161500-09-019

Table of Contents

Summary of Contents for Winnebago Journey

Page 1: Table Of Contents
Passenger Footrest ..........................3-2 Seat Belts ............................3-3 Child Restraints ..........................3-4 KeyOne™ Lock System ........................3-5 Power Door Locks ..........................3-5 Mirrors – Power Electric ........................3-6 Rev. 0917090914 Part No. 161500-09-019 Copyright 2008 Winnebago Industries, Inc. All rights reserved.
Page 2 Table Of Contents Rearview Monitor System ........................ 3-7 Rearview Monitor System ........................ 3-8 Power Sunvisors ..........................3-9 GP-go™ Portable Navigation System ....................3-9 Parking Brake ..........................3-10 Exhaust Restriction Braking System ....................3-10 Hazard Warning Flashers ........................ 3-11 Signal Lever/Headlight Hi/Lo Beam ....................3-12 Map Light Switch ...........................
Page 3 Table Of Contents MotorAid Water Heater ........................4-8 Propane Gas Furnace ........................4-9 Electronic Thermostat ........................4-9 Furnace-A/C Thermostat Operation Chart ..................4-11 Central Air Conditioner ........................4-11 Air Conditioner Filter ........................4-12 Washer/Dryer ..........................4-12 5 – PROPANE GAS Propane Gas Supply ..........................
Page 4 Table Of Contents Water System Drain Valve Locations ..................... 7-18 8 – ENTERTAINMENT Video Selection System ........................8-1 Audio-Video System Basic Operation ....................8-2 Compact Disc Changer ........................8-5 TV Antenna ............................8-6 TV Signal Amplifier ......................... 8-6 Cable TV and Satellite Hook-Ups ....................8-7 TV Digital Satellite System Wiring ....................
Page 5 Table Of Contents Exterior Lights ..........................11-5 Interior Soft Goods ......................... 11-5 Cabinetry – Cleaning ........................11-6 Solid Surface Countertop – Corian® ....................11-7 Tables and Countertops ........................11-7 Galley Sink ............................. 11-7 Range and Refrigerator ........................11-8 Bathroom ............................11-8 Doors and Windows ........................
Page 7: Introduction
DANGER indicates a directly hazardous are intended as a guide, and in no way situation which, if not avoided, will result extend the responsibilities of Winnebago in death or serious personal injury. Industries beyond the standard written warranty as presented in this manual.
Page 8: Pre-Delivery Inspection
National Highway Traffic Safety Administration a feature item. (NHTSA) in addition to notifying Winnebago Industries, Inc. PRE-DELIVERY INSPECTION If NHTSA receives similar complaints, it may...
Page 9: Occupant And Cargo Carrying Capacity Label
SECTION 1 – INTRODUCTION OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to or near the Vehicle Certification Label. It contains vehicle occupant and cargo carrying capacity along with the number of seat belt positions in the vehicle.
Page 10: Vehicle Certification Label
These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.
Page 11: Specifications And Capacitites
SECTION 1 – INTRODUCTION SPECIFICATIONS AND CAPACITITES Model Length 34' 7" 37' 5" 39' 1" Exterior Height 12' 2" 12' 2" 12' 2" Exterior Width 8' 5" 8' 5" 8' 5" Exterior Storage (cu. ft.) 65.6 131.7 132.1 Awning Length 19' 6"...
Page 12 SECTION 1 – INTRODUCTION Specifications and Capacities Notes: ® ® Freightliner Chassis, Cummins ISB XT 6.7L turbo-charged diesel, 350-hp, rear radiator, Allison 6-speed electronic ® 3000 MH transmission, NeWay front & rear air suspension, 160-amp. alternator, exhaust brake, 4-wheel ABS, Wheels: Stylized Aluminum.
Page 13: Owner And Vehicle Information
Motor Home Serial Number __________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...
Page 14: 2009 New Vehicle Limited Warranty
ITEMS NOT SUBJECT TO WARRANTY COVERAGE Winnebago Industries, Inc. of Forest City, Iowa, warrants each new Chassis, drivetrain and related components* Winnebago and Itasca motor home to the owner for recreational use Wheels* in the U.S.A. and Canada as follows:...
Page 15 If you are touring or have moved, contact any unresolved warranty disputes for recreational vehicles. This dispute Winnebago Industries motor home dealer in the United States or resolution program reviews eligible product and service related Canada for warranty service.
Page 17: Safety And Precautions
SECTION 2 – SAFETY AND PRECAUTIONS • Use care when accelerating or decelerating on GENERAL WARNINGS a slippery surface. Abrupt speed changes can cause skidding and loss of control. • Only seats equipped with seat belts are to be occupied while the vehicle is moving. •...
Page 18: Lp Gas Leaks
SECTION 2 – SAFETY AND PRECAUTIONS • Never use an open flame to test for LP gas LP GAS LEAKS leaks. Replace all protective covers and caps on LP system after filling. Make sure valve is The following procedures are located in the closed and the door is latched securely.
Page 19: Carbon Monoxide Warning
SECTION 2 – SAFETY AND PRECAUTIONS The best protection against carbon monoxide entry into the vehicle body is a properly WARNING maintained engine exhaust and ventilation system. It is recommended that the exhaust system and body be inspected by a qualified EXPLOSION HAZARD: DO NOT use an motor home service center: open flame to test for gas leaks.
Page 20: Smoke Alarm
InfoCase for further instructions. may not be recommended for RV application. Replacement We recommend obtaining a replacement from ® your Winnebago Industries dealer. When replacing this alarm, we recommend replacing only with a similar model. Other brands Further Information may not be recommended for RV application.
Page 21: Electrical
We recommend obtaining a MAINTENANCE replacement only from your Winnebago ® Industries dealer or a reliable RV parts supplier. •...
Page 22: Formaldehyde Information
SECTION 2 – SAFETY AND PRECAUTIONS asthma-like symptoms, including shortness of breath have been reported as a result of formaldehyde exposure. Reaction to formaldehyde exposure may vary among individuals. Elderly persons and young children, as well as anyone with a history of asthma, allergies, or lung problems may be at greater risk.
Page 23: Roadside Emergency
SAFETY AND PRECAUTIONS How Can I Avoid Mold? coverage provided by Winnebago Industries. Winnebago Industries, however, will not assume To reduce the ability for mold to grow, you responsibility for mold deemed to be a result of a must reduce what constitutes its growth motor home users lack of timely and appropriate environment.
Page 24: Jump Starting
We recommend that you ask for an underlift (wheel lift or frame lift) type towing assembly for safe towing. ® CAUTION Winnebago Industries does not assume responsibility for damage incurred while towing this vehicle. Do not attempt to push start this vehicle.
Page 25 SECTION 2 – SAFETY AND PRECAUTIONS For information on what to do in case of overheating, consult your chassis manual.
Page 27: Driving Your Motor Home
SECTION 3 – DRIVING YOUR MOTOR HOME The information in this section refers only to Front Seats features installed or adapted to the dash and –Standard driver compartment area by Winnebago ® Industries . It also includes passenger seating in the living area of the coach.
Page 28: Passenger Footrest
SECTION 3 – DRIVING YOUR MOTOR HOME • Reverse the procedure to face the seat forward. Armrest Adjustment The armrests may be swung upward out of the way for easy exit or access to the front seats. A roller on the underside of the front of the armrest also lets you adjust the resting angle for personal comfort, whether the seat is upright or reclined.
Page 29: Seat Belts
SECTION 3 – DRIVING YOUR MOTOR HOME To Fasten Be sure belt is not twisted. Grasp each part of Recline Lever the belt assembly and push tongue into buckle. Adjust to a snug fit by pulling the loose end away from the tongue.
Page 30: Child Restraints
SECTION 3 – DRIVING YOUR MOTOR HOME 3. Be certain that it is appropriate for the child's height, weight, and development. The WARNING instructions and/or the regulation label attached to the restraint typically provides this information. Never wear the shoulder belt in any 4.
Page 31: Keyone™ Lock System
The key number for your coach is registered in our factory database, so if you ever lose your ® keys, any Winnebago Industries dealership can Keyless Remote Unit order a new key for you.
Page 32: Mirrors - Power Electric
SECTION 3 – DRIVING YOUR MOTOR HOME Further Information Move Selector Switch L or R to select mirror. Please read the Keyless Entry System Center “neutral” position disables arrows information in your InfoCase for complete to avoid unintentionally moving a mirror operating information as well as a full description of all of the system’s features and programming instructions.
Page 33: Rearview Monitor System
SECTION 3 – DRIVING YOUR MOTOR HOME Allen Head Set Screw* Carefully pry out plug on underside (Torque screw to 75-100 in./lbs.) of mirror base to access pivot bolt *Set screws may be located on the opposite side of the mirror arm. Passenger and Driver side mirrors are similar.
Page 34: Rearview Monitor System
SECTION 3 – DRIVING YOUR MOTOR HOME A microphone built into the rear camera lets REARVIEW MONITOR SYSTEM you hear warning sounds or verbal directions from an assistant. –If Equipped Basic Operating Instructions Power - Turn ON to activate monitor for rear viewing while driving or parked.
Page 35: Power Sunvisors
SECTION 3 – DRIVING YOUR MOTOR HOME Sideview Cameras* (if equipped) it from the dash in your RV, or remove it and take it with you in another vehicle (separate docking The optional sideview cameras activate with the station included). corresponding turn signals and replace the rear To install the GPS unit, open the cradle by camera view on the monitor until the turn is...
Page 36: Parking Brake
SECTION 3 – DRIVING YOUR MOTOR HOME NOTE: Pressing the Aux Input button and PARKING BRAKE turning up the volume on the rearview monitor also increases the sound ® Freightliner Chassis capacity of the voice commands when driving. The rearview monitor speaker is used to supplement the primary navigation monitor speaker.
Page 37: Hazard Warning Flashers
SECTION 3 – DRIVING YOUR MOTOR HOME The increased back pressure would normally HAZARD WARNING FLASHERS stop the engine except the forward momentum of the vehicle keeps the drivetrain and the engine The hazard warning flashers provide turning. additional safety when the vehicle must be This controlled back pressure helps to regulate stopped on the side of the roadway and presents a a vehicle’s downhill speed, such as on...
Page 38: Signal Lever/Headlight Hi/Lo Beam
SECTION 3 – DRIVING YOUR MOTOR HOME Further Information SIGNAL LEVER/HEADLIGHT See your chassis manual in your InfoCase for HI/LO BEAM further information on this switch. The signal lever controls the turn signals and STEERING COLUMN high/low beam changing. ADJUSTMENT The tilt/telescope adjustment pedal is located on the floor to the left of the steering column as shown.
Page 39: Air Conditioner/Heater - Automotive (Dash)
SECTION 3 – DRIVING YOUR MOTOR HOME Press and hold in the ON position while DEFROST FANS turning ignition key for emergency starting power. – If Equipped The two-speed auxiliary fans are intended to NOTE: The Aux. Battery Disconnect switch near assist the automotive windshield defroster the entrance door must be ON and house system in clearing fog and frost in cold weather...
Page 40: Radio Power Switch
SECTION 3 – DRIVING YOUR MOTOR HOME NOTE: If your Sirius tuner is not activated, follow the instructions in the radio owners manual in your InfoCase for the phone number to call and procedure to access the Sirius Tuner ID Number (ESN).
Page 41: Sirius Plug And Play Satellite Radio
SECTION 3 – DRIVING YOUR MOTOR HOME To install the satellite unit, place your Sirius Dash Radio Sound through Home radio into the docking station, aligning the tabs at Theater Speakers the edges of the the radio adapter with the grooves in your radio.
Page 42: Air Horns
SECTION 3 – DRIVING YOUR MOTOR HOME have the vehicle towed into a heated facility to allow the fuel to warm up and become fully liquid again. During winter time, most truck stops and reputable filling stations have winter blend diesel fuels available that are less susceptible to waxing.
Page 43: Engine Block Heater - Diesel Engine
SECTION 3 – DRIVING YOUR MOTOR HOME Idling Diesel Engine CAUTION Do not operate engine at low idle for long periods with engine coolant temperature below the minimum specification in your diesel engine manual. This can result in the following: •...
Page 44: Engine Access Grille - Rear
SECTION 3 – DRIVING YOUR MOTOR HOME • Engine Coolant Reservoir • Transmission Dipstick/Fill Tube • Air Filter Restriction Indicator • Engine Diagnostic Connector Hood Locks Transmission Fluid Fill/ Dipstick To close the hood, pull downward and swing Engine inward. Press top edge of hood panel inward firmly with palms of your hands while turning Dipstick lock key to ensure proper latching.
Page 45: Engine Top Access Covers - Rear
SECTION 3 – DRIVING YOUR MOTOR HOME • Lift the hinged bed board upward against ENGINE TOP ACCESS COVERS wall. Support the bed board with a suitable – REAR prop item as shown (if bed is not equipped with struts). These covers are only removed if a complete view of the engine is needed for inspection, or for replacement or adjustment of upper engine parts.
Page 46: Fuel/Water Separator - Diesel Engine
SECTION 3 – DRIVING YOUR MOTOR HOME Propping the Bed Board The fuel/water separator is located at the forward right side of the engine beneath the rear of the chassis. Aluminum Tube Diesel Fuel/Water Transmission Engine Oil Filter Separator Filter Fluid Filter (Typical) (Typical)
Page 47: Chassis Battery Disconnect Switch
SECTION 3 – DRIVING YOUR MOTOR HOME NOTE: Your chassis engine cooling system is filled with special extended-life coolant that is not the same as common anti- freeze available at retail outlets. The coolant system MUST be refilled or topped up with the same type of coolant as equipped to maintain the special long- life properties.
Page 48: Windshield Washers And Wipers
SECTION 3 – DRIVING YOUR MOTOR HOME 12-Volt Automotive Fuse Panel Fuse Diagram (inside of cover) Further Information 12-Volt Automotive Breaker Panel See your chassis manual in your InfoCase for further information about chassis supplied fuses and relays. WINDSHIELD WASHERS AND WIPERS The windshield washer fluid reservoir is located in the front of the coach behind the hood...
Page 49: Tires
SECTION 3 – DRIVING YOUR MOTOR HOME Further Information TIRES See the chassis manual in your InfoCase for Improper tire pressure can result in tire further information. overloading and abnormal wear and also affects handling, ride characteristics, and fuel economy. LIGHTS All exterior lights should be checked for proper operation each time the vehicle is...
Page 51: Appliances And Systems
SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motor home are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. REFRIGERATOR The refrigerator in your coach can operate Bubble must be at least 1/2 inside circle from either of two energy sources available to the motor home:...
Page 52: Ice Maker
SECTION 4 – APPLIANCES AND SYSTEMS To Open: operate on 120-VAC household current if the shoreline is connected or the auxiliary 1. Use a screwdriver or coin to turn the latch generator is running. knobs to the vertical position as shown. AU (Automatic Mode) - Refrigerator will automatically start operating on 120-VAC household current if the shoreline is...
Page 53: Range Top
SECTION 4 – APPLIANCES AND SYSTEMS Unlike homes, the amount of oxygen supply is Microwave/Range Hood - Typical limited due to the size of the recreational vehicle, (brand, model, and appearance shown may vary from your model) and proper ventilation when using the cooking appliances avoids dangers of asphyxiation.
Page 54: Generator Hourmeter
SECTION 4 – APPLIANCES AND SYSTEMS Water and Holding Tank Levels Press and Hold the appropriate button to show approximate tank level on the monitor lights The approximate fluid levels are measured by OnePlace Monitor Panel sets of electronic sensors (detector cells) on the sides of the tanks.
Page 55: Solar Charger Panel
SECTION 4 – APPLIANCES AND SYSTEMS Gray Waste Tank Selector (Model Battery Voltage Meter 39Z only) Press the “House Battery” switch position to check the level of charge (voltage) in the 12-volt This model has two gray water tanks. Because house batteries.
Page 56: Energy Management System (Ems)
SECTION 4 – APPLIANCES AND SYSTEMS ENERGY MANAGEMENT SYSTEM (EMS) The Energy Management System (EMS) monitors the electrical usage of the appliances and equipment in the coach and distributes the electrical loads to avoid nuisance tripping of the shoreline circuit breaker. This system works together with the energy efficient central air conditioner to allow you to run both compressors Solar Charging Indicator...
Page 57: Pressure-Temperature Relief Valve
SECTION 4 – APPLIANCES AND SYSTEMS Read the Water Heater Operation Manual for complete Safety Warnings, Operating Instructions and Maintenance Information before operating the water heater. Be sure the water heater is filled with water before starting either electric or propane gas operation.
Page 58: Motoraid Water Heater
SECTION 4 – APPLIANCES AND SYSTEMS Lift handle straight out to open P-T valve when water heater is cold* Water Heater Exterior Service Access 4. Let the handle of the P-T valve snap shut. Normally there is an air gap at the top of the water heater tank, which acts as a pressure buffer.
Page 59: Propane Gas Furnace
SECTION 4 – APPLIANCES AND SYSTEMS Turn thermostat off for 3-5 minutes, check to be sure propane gas tank valve CAUTION is open and tank is not empty, then try steps 2-4 again. If the furnace will not light after three Any leak in the heat exchanger or its attempts, go to Shut Down steps and supply or return lines could cause loss of...
Page 60 SECTION 4 – APPLIANCES AND SYSTEMS changing the temperature setpoint. A few Temperature Selector seconds after you release the temperature selector button, the display will return to showing the current room temperature. Cooling (A/C): • Slide the thermostat switch to Cool position. •...
Page 61: Furnace-A/C Thermostat Operation Chart
SECTION 4 – APPLIANCES AND SYSTEMS FURNACE-A/C THERMOSTAT OPERATION CHART The following chart shows the system functions with the “Heat/Cool” thermostat. Disregard references to heat functions when using the “Cool Only” thermostat in the rear bedroom. X = Switch Position O = Switch position does not matter or is inactive for this feature FAN MODE FAN SPEED...
Page 62: Air Conditioner Filter
SECTION 4 – APPLIANCES AND SYSTEMS cleaning or service. Remove the screws under the NOTE:Do not block the filter in any way, such as lower edge of the panel and swing it upward for by setting packages or newspapers, etc. access to the condenser.
Page 63 SECTION 4 – APPLIANCES AND SYSTEMS 2. When the “Status/Door Lock” LED blinks SLOWLY (takes 1-2 minutes), you can open the door. IMPORTANT! Once a wash cycle is underway, the washer/dryer door will LOCK for the duration of the cycle and will STAY LOCKED for up to 2 minutes after the cycle ends.
Page 65: Propane Gas
SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY WARNING The propane gas system supplies fuel for the gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and Do not alter or remove propane tank handled properly, this system is safe and gauge at any time.
Page 66: Safe Use Of The Propane Gas System
SECTION 5 – PROPANE GAS phone directory yellow pages for locations of local propane gas refilling stations or bulk DAN GE R dealerships. NOTE: If you travel outside the U.S. with your DO NOT FILL CONTAINER TO MORE motor home, you may find butane or THAN 80 PERCENT OF CAPACITY.
Page 67: Propane Gas Warnings And Precautions
SECTION 5 – PROPANE GAS • Exercise caution at all times. Be familiar with PROPANE GAS WARNINGS the distinctive odor of propane gas. If a leak is AND PRECAUTIONS suspected, turn off the supply valve immediately. Have the propane gas system It is illegal for vehicles equipped with propane checked by your dealer or other qualified tanks to travel on certain roadways or through...
Page 68: Propane Gas Pressure Regulator
SECTION 5 – PROPANE GAS WARNING WARNING Propane cylinders shall not be placed or Visually inspect the pressure regulator stored inside the vehicle. vent periodically for blockage by Propane cylinders are equipped with accumulated debris or insect nests, etc. safety devices that relieve pressure by Vent obstruction could result in excessive discharging propane to the atmosphere.
Page 69: Propane Vaporization In Cold Weather
SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.
Page 70 NOTES...
Page 71: Electrical
SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motor home that is •...
Page 72: Connecting The Power Cord
SECTION 6 – ELECTRICAL Connecting The Power Cord To connect to an external source, remove the cord from the utility compartment and plug it into a suitable 50-amp power receptacle to provide external power to the coach and converter/ charger system. NOTE: Some parks do not have 50-amp service available, so you will need to connect to a standard 30-amp service pole using an...
Page 73: Inverter/Charger Unit - 2000W
SECTION 6 – ELECTRICAL Park Fuses or Breakers Most campgrounds are equipped with a fuse or circuit breaker at the receptacle. This protects the park’s wiring, as well as the power cord on your vehicle, from electrical damage. If electrical power fails, contact the park attendants and have them check the fuse or breaker for your supply receptacle.
Page 74: Power Center
SECTION 6 – ELECTRICAL If your battery does not charge as described refrigerator is in ELECTRIC or AUTO above, it is possible the battery is defective. mode, it will continue to draw from house batteries through the inverter If the batteries are extremely discharged, the when the shoreline is unplugged unless charger unit will not activate to charge batteries the inverter is turned OFF.
Page 75: Circuit Breakers - House 120-Volt Ac
SECTION 6 – ELECTRICAL Charging Section component itself. When an overload or short develops, the breaker will open preventing The converter charges house batteries while damage to the system. 120-volt external power is connected. The Shut off the equipment (example: roof air converter will automatically “sense”...
Page 76: Electrical Generator
SECTION 6 – ELECTRICAL severe electrical shock if a ground fault develops. ELECTRICAL GENERATOR If such a condition occurs, the GFCI will break the circuit by turning off the power to the –If Equipped protected outlets. Should this occur, unplug all the appliances on that circuit and press the reset button on the GFCI equipped outlet.
Page 77: Electrical System - House 12-Volt Dc
SECTION 6 – ELECTRICAL To Stop the Generator 2. Do not open windows or vents on the end or side of the vehicle where exhaust pipe of the Press and Hold the Generator switch in STOP generator is located. position until you hear the generator come to a full stop, then release.
Page 78: Circuit Breakers - House 12-Volt
SECTION 6 – ELECTRICAL House Batteries House batteries are “deep-cycle” type batteries specially designed for recreational vehicle use. They will provide longer lasting power than standard automotive starting batteries and will withstand the frequent drain-and- recharge cycles that occur under the demanding conditions of a camping outing.
Page 79: Battery Access
SECTION 6 – ELECTRICAL BATTERY CARE Lead-acid type batteries are electro-chemical devices for storing and releasing electrical charge. As such, they are simply an electrical reservoir, not an electrical source. As soon as energy is removed from the battery, it should be replaced by the engine alternator or the RV converter system.
Page 80 SECTION 6 – ELECTRICAL can lose electrolytic fluids and become • Clean and tighten battery terminals and have damaged from continuous charging the specific gravity checked at least once a without periodic use or maintenance. year. We recommend following regular battery •...
Page 81: Plumbing
SECTION 7 – PLUMBING FRESH WATER SYSTEM The fresh water system provides water to the galley sink, shower, bathroom lavatory, toilet, and water heater. Water may be supplied by either of two sources: • a fresh water tank and water pump located within the motor home;...
Page 82: Utility Light
SECTION 7 – PLUMBING 2. Turn Fresh Water Valve to Normal position Water pressure regulators are commonly and turn the water pump switches OFF. available at any well stocked RV dealership and many large retail discount or home supply centers. UTILITY LIGHT A light is located up on the left sidewall to illuminate the utility hook-up area when needed.
Page 83: Filtered Water Faucet
SECTION 7 – PLUMBING Pump Strainer While the switch is “ON”, the pump will automatically supply water as it is needed. The pump is equipped with a cleanable We recommend that you turn the water pump strainer to capture any possible tank-borne switch off whenever you will be away from the particles that could damage pump components.
Page 84: Full-Coach Water Filtration System
SECTION 7 – PLUMBING • Purge a new filter cartridge before using for Filtered Water Faucet drinking. Run a few gallons of water through the filter and discard the water (or use for watering plants) to avoid ingesting carbon dust or particles that may have been present in the new filter cartridge.
Page 85: Disinfecting Your Fresh Water System
SECTION 7 – PLUMBING • Remove the large O-ring seal from the canister. Check seal for damage, wipe clean and set aside. Discard the used filter cartridge. • Wash the inside of the canister with dish soap and warm water using a nonabrasive sponge or cloth.
Page 86 SECTION 7 – PLUMBING Coaches with Full-Coach Water 10. Water system is now disinfected. Filtration System (in Water Center) 1. Open a faucet to relieve any waterline WARNING pressure, then remove the filter canister from the filter base. Chlorine is poisonous. Recap bottle and 2.
Page 87: Shower Hose Vacuum Breaker
SECTION 7 – PLUMBING • Add 1 teaspoon of chlorine bleach (sodium hypochlorite) to your tank for each 10 gallons of tank capacity. When you fill the tank, this will result in a 6.7 ppm level of chlorine, which should kill harmful bacteria and slime- forming organisms.
Page 88: Waste Water System
SECTION 7 – PLUMBING See winterizing instructions at the end of this section to prepare the toilet for storage in freezing conditions. Further Information See the toilet manufacturer’s operation information in your InfoCase for complete operating, care, and maintenance information. WASTE WATER SYSTEM (Holding Tanks) Holding Tank Dump Valves (Typical)
Page 89: Waterline And Tank Drain Valves
SECTION 7 – PLUMBING Flushing your Black Water Holding When using a sewer hook-up, keep the dump valves closed until a tank becomes full or when Tank preparing to leave the site. This keeps the solids The black water holding tank is equipped with in suspension, allowing them to be carried out an internal spray head that allows you to rinse the with the liquids when the dump valve is opened.
Page 90: Water Heater Bypass Winterization Valve
SECTION 7 – PLUMBING Turn the handle as shown to either Bypass or Normal flow through the water heater. Waterline Drains Water Tank Drain Valve (remove caps and turn (pull T-handle to drain valves to drain lines) fresh water tank) -Typical View CAUTION The fresh water tank drain valve is cable-...
Page 91 SECTION 7 – PLUMBING 3. Drain Exterior Shower/Wash Station. 5. Remove Full-Coach Water Filter (if Open exterior shower knobs and lay shower equipped). Remove the filter canister from head on ground as shown to drain any water the full-coach water filtration system in the left in the shower line.
Page 92 This fills the drain trap pipes the system. A blow-out plug can be purchased to prevent holding tank odors from entering ® ® at any Winnebago or Itasca dealer. the coach during storage. NOTE: It is not necessary to add antifreeze to...
Page 93 SECTION 7 – PLUMBING 21. Close dump valves and refit the dust cap onto the drain outlet. WARNING This will inhibit rust formation on valve shafts and prevent entry and contamination by airborne debris, insects, and rodents. NEVER use automotive antifreeze/ Your drainage and fresh water systems are now coolant in your RV water system.
Page 94 SECTION 7 – PLUMBING next numbered step.) After removing filter, remount the empty canister onto the filter assembly and continue the antifreeze fill procedure. Set Up Winterization Valves 3. Turn Winterization Valve 1 to “Water Heater Bypass” position to avoid filling water heater with antifreeze.
Page 95: Winterizing Optional Appliances
SECTION 7 – PLUMBING 15. Pour about one cup of RV antifreeze down each drain for the galley sink, lavatory sink, and shower/tub. This fills the drain trap pipes to prevent holding tank odors from entering the coach during storage. Dump and Clean Holding Tanks 16.
Page 96 SECTION 7 – PLUMBING 4. Press ON/OFF Button (OUT). Unplug the washer/dryer from the electrical outlet (or disconnect power). 5. Turn the water supply faucets OFF. Disconnect the inlet hoses from the faucets. Drain any remaining water from the hoses. 6.
Page 97 SECTION 7 – PLUMBING To use Washer/Dryer again: To use Dishwasher again: Flush antifreeze from the waterlines, then Flush antifreeze from the waterlines, then 1. Reconnect the water inlet hoses to the 1. Set the dishwasher controls to the start of the corresponding HOT/COLD faucets.
Page 98: Water System Drain Valve Locations
SECTION 7 – PLUMBING WATER SYSTEM DRAIN VALVE LOCATIONS System Drain Valve Locations Waterline Drain Valves • Valves and drain hoses are located in the water service center on the driver side of the coach. Remove caps from hose ends, turn Fresh Water Valve to TANK FILL position, then turn hose valves to drain waterlines.
Page 99: Entertainment
SECTION 8 – ENTERTAINMENT To Watch DVD VIDEO SELECTION SYSTEM • See “Audio-Video System Basic Operation” elsewhere in this section for basic DVD and home theater setup. To Watch VCR (if self-installed) • Press VCR button on MAIN TV section of video selection box.
Page 100: Audio-Video System Basic Operation
SECTION 8 – ENTERTAINMENT To Watch DVD AUDIO-VIDEO SYSTEM BASIC • Power “ON” TV and the high definition video OPERATION selection box. • Power “ON” the DVD player. NOTE: For your convenience, we have also included a handy, tear-out version of this •...
Page 101 SECTION 8 – ENTERTAINMENT Set TV Video Input • Volume is adjusted with the DVD remote (or volume control on DVD player). (If equipped with one main TV) TV Sound through Home Theater • Turn On both TV and Speakers DVD player.
Page 102: Exterior Entertainment Center
SECTION 8 – ENTERTAINMENT • The DVD may load directly to the main title/ CD/DVD PLAYER - BEDROOM menu screen or it may begin to play previews. You may be able to skip previews if desired by (& Stereo Radio Alarm Clock) pressing the NEXT button until you see the –If Equipped main menu screen.
Page 103: Compact Disc Changer
SECTION 8 – ENTERTAINMENT Video Programming from the Video The exterior entertainment center TV is connected to the exterior DVD player, video Selection Box selection box, the rooftop antenna, and the park -If Equipped cable input. • Turn On video selection box and Play DVD select desired input...
Page 104: Tv Antenna
SECTION 8 – ENTERTAINMENT Further Information See the Compact Disc Changer System operating guide in your InfoCase for complete instructions on how to load CD’s, operate the changer with your radio and troubleshoot basic problems. Lowering Antenna to Travel Position TV ANTENNA Rotate antenna until pointer on directional handle aligns with pointer on ceiling plate.
Page 105: Cable Tv And Satellite Hook-Ups
TV degraded (snowy). When you turn the switch (if equipped.) back on, the picture should again be sharp. ® See your authorized Winnebago Industries dealer for proper installation and sealing of roof CABLE TV AND SATELLITE mounted components. HOOK-UPS...
Page 106: Tv Digital Satellite System - Automatic
SECTION 8 – ENTERTAINMENT • Press the SAT switch on the HD Video Selection System to view the satellite signal. See HD Video Selection System for additional information. High Definition Accessory Connection Cables (Located in cabinet near TV) TV DIGITAL SATELLITE Automatic Satellite Dish Control SYSTEM –...
Page 107: Exterior Entertainment Center
SECTION 8 – ENTERTAINMENT NOTE: These electronic devices and speakers are not designed to be waterproof. Please take measures to prevent rain or other precipitation from entering the entertainment center by closing the compartment door or ensuring that an awning will prevent entrance of precipitation.
Page 109: Furniture And Softgoods
SECTION 9 – FURNITURE AND SOFTGOODS LOUNGE CHAIR BASE CLAMP TABLE AND CHAIRS –If Equipped While the vehicle is in motion, the base of the lounge chair must be fastened into position with Dinette Chairs a clamp on the floor as shown. The dinette chairs are free-standing to allow greater freedom of movement than typical booth style dinettes or pedestal seats.
Page 110 SECTION 9 – FURNITURE AND SOFTGOODS Buffet Chairs 2. Hook the strap to the mounting brackets 1. Push Buffet Table chairs against opposite (located on each side of the lounge cabinet) sides of table. for security. 2. Bind Chairs together with the provided strap in the circular pattern shown above, ensuring the strap goes through the ring located in the bottom side of the table.
Page 111: Sleeping Facilities
SECTION 9 – FURNITURE AND SOFTGOODS WARNING Be sure all free-standing chairs and furniture items, and all other loose items are secured or stored properly while the vehicle is in motion. Possible overlooked items such as canned goods or small appliances on the countertop, cooking pans on the range can also become dangerous projectiles during a sudden...
Page 112: Sofa/Bed Conversion
SECTION 9 – FURNITURE AND SOFTGOODS SOFA/BED CONVERSION Sofa to Bed Lift the front edge of the sofa seat upward and pull outward from the wall while gently pushing downward on the backrest until the cushions lie flat. The bed is now ready for use. Bed to Sofa Push the front edge of the seat toward the wall while lifting upward on the backrest until the sofa...
Page 113 SECTION 9 – FURNITURE AND SOFTGOODS NOTE: The footrest “drawer” will latch when pulled out completely and must be unlatched to push back in when stowing the footrest. To Extend Pull-Out Footrest Section 1. Squeeze latch behind opening at top of lounge face panel and pull footrest trundle section out until it locks in the fully extended position.
Page 114: Theater Seating/Bed Conversion
SECTION 9 – FURNITURE AND SOFTGOODS THEATER SEATING/BED CONVERSION –If Equipped CAUTION Do not recline the lounge completely flat unless the footrest trundle section is CAUTION extended. Do not occupy the lounge when elevating the seat back from the flat bed position to upright lounge position.
Page 115 SECTION 9 – FURNITURE AND SOFTGOODS To Extend Pull-Out Footrest Section 1. Squeeze latch behind opening at top of lounge face panel and pull footrest trundle section out until it locks in the fully extended position. Tip for “power users” •...
Page 116: Sleep Number® Bed
SECTION 9 – FURNITURE AND SOFTGOODS NOTE: The Sleep Number bed operates on 120- volt AC household current only, so you CAUTION must have the shoreline plugged in or the generator running to adjust the air pressure settings in this bed. Do not recline the lounge completely flat unless the footrest trundle section is Further Information...
Page 117: Wood Furniture And Cabinetry
CABINETRY –If Equipped People are drawn to the natural beauty of ® wood. At Winnebago Industries , our craftsmen work with the art found in each piece of wood to create cabinets of superior quality, backed by the Winnebago Industries warranty.
Page 118 SECTION 9 – FURNITURE AND SOFTGOODS light. Color differences or changes in wood can also be caused by exposure to harsh chemicals, extreme heat, or other contributing external conditions. Any color change that occurs in both the finish and the wood is considered part of the natural aging process and is not to be considered defect or damage.
Page 119: Slideout Rooms And Leveling
SECTION 10 – SLIDEOUT ROOMS AND LEVELING To Release SLIDEOUT ROOM TRAVEL • Press and hold the “unlock” side of the LOCKS Slideout Lock switch for about 7 seconds. (You may be able to hear the lock motor sound –If Equipped stop).
Page 120: Slideout Room Operation - Electric
SECTION 10 – SLIDEOUT ROOMS AND LEVELING NOTE: We recommend that you KEEP THE SLIDEOUT ROOM OPERATION ENGINE RUNNING WHILE – ELECTRIC EXTENDING OR RETRACTING SLIDEOUT ROOMS so the engine alternator can provide maximum power for proper operation of the slideout WARNING mechanisms.
Page 121: Slideout Room - Extreme Weather Precaution
SECTION 10 – SLIDEOUT ROOMS AND LEVELING Extend Procedure: If it has rained recently before you retract the slideout room, we recommend using the See “Before Extending!” before proceeding. hydraulic leveling system (if equipped) to lean • Start the engine so the alternator can provide the coach and drain off any excess water possibly maximum power for proper operation of remaining on the roof before retracting.
Page 122: Slideout Room Troubleshooting - Electric
SECTION 10 – SLIDEOUT ROOMS AND LEVELING slideout room cover-awning (if equipped) or reduce effectiveness of the slideout room weather Light will flash fault Light will flash if code if system seals. park brake not set malfunctions Slideout Cover-Awning Also, freezing rain and snow can prevent the Low Voltage slideout cover-awning (if equipped) from closing Indicator...
Page 123 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Both methods listed below are intended as a means to retract the room to prepare the coach for Light will flash fault Light will flash if code if system travel to the nearest authorized service center. park brake not set malfunctions Manual Mode...
Page 124: Slideout Emergency Retraction - Electric
SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Use a 3/4” socket and ratchet wrench on the SLIDEOUT EMERGENCY motor gearbox shaft to crank the room in or RETRACTION - ELECTRIC out as needed. Crank both sides of the room alternately and equally to avoid wedging the (Front Slideout Room) room.
Page 125: General Slideout Care
SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Locate the small, round access hole in the bed • Crank the ratchet wrench clockwise to retract base at the foot of the bed. the room. The tool will extend nearly a foot out of the bed base at first, but will be drawn into the bed base as the room is retracted.
Page 126: Leveling System
SECTION 10 – SLIDEOUT ROOMS AND LEVELING LEVELING SYSTEM –If Equipped The hydraulic leveling system makes selecting a parking site easier and faster by reducing the effect of uneven ground. Hydraulic jacks raise the affected low corners of the coach to make leveling “set up” faster and easier for you.
Page 127 Auto Level Switch recommended that you take your RV into an (Located in Service Center compartment) ® authorized Winnebago Industries dealership for a complete leveling system inspection before using again. Jacks Down Light The “Jacks Down”...
Page 128: Checking Hydraulic Oil Level
SECTION 10 – SLIDEOUT ROOMS AND LEVELING If your leveling system reservoir is not equipped with a dipstick, always keep the hydraulic fluid level full (to the bottom of the fill port). NOTE: Always clean away any dirt and debris from the top of the reservoir before removing the breather cap to avoid entry of debris and contamination of hydraulic...
Page 129: Maintenance And Storage
• Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.
Page 130: Exterior Automotive Paint Finish
SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
Page 131 SECTION 11 – MAINTENANCE AND STORAGE Bug Removal to clean heavy road films on semi trailers and are often dirty. They are not • Rinse the loose debris off with water and designed for custom painted RV’s and allow the remaining residues to soak and they will scratch the clearcoat finish.
Page 132: Care Of Appliques And Decals
SECTION 11 – MAINTENANCE AND STORAGE is subjected to various twisting and flexing forces • Fuel or antifreeze spilled on appliques or caused by routine cornering and turning, and by decals should be rinsed off immediately with uneven road surfaces, such as bumps, potholes, water.
Page 133: Exterior Lights
SECTION 11 – MAINTENANCE AND STORAGE EXTERIOR LIGHTS CAUTION ® Most Winnebago Industries vehicles have polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical Do not use citrus-based cleaners on solvents and cleaners. polycarbonate finishes.
Page 134: Cabinetry - Cleaning
SECTION 11 – MAINTENANCE AND STORAGE shades should be closed when the motor home is parked for an extended period of UltraLeather Cleaning Chart time. Detergent/ Cleaner/ Type of Stain Water Degreaser Coffee, Tea WARNING Red Wine, Liquor Cola, Soft Drinks Milk When cleaning upholstery and fabric, do not use lacquer thinner, nail polish...
Page 135: Solid Surface Countertop - Corian
SECTION 11 – MAINTENANCE AND STORAGE NOTE: Many cabinetry and furniture items surface using the same cleaning material and throughout this motor home are scrubbing method to maintain a uniform constructed either partially or appearance. completely of real hardwoods. Because If you prefer a glossier look, follow up with of natural variations in woodgrain a good quality furniture polish or a liquid...
Page 136: Range And Refrigerator
SECTION 11 – MAINTENANCE AND STORAGE Lavatory Sink – ABS Plastic • For stubborn stains, use a mild abrasive ® ® cleanser like Soft Scrub , Comet , etc. Work General Cleaning. Clean often with hot water in the direction of the “grain” of the brushed and soap.
Page 137: Vehicle Storage - Removal
SECTION 11 – MAINTENANCE AND STORAGE Clean and Prep Coach for Storage materials and compounds can be purchased from your dealer. Badly damaged weather 1. Turn off the propane gas tank. seals may need to be replaced by your dealer. 2.
Page 138: Chassis Service And Maintenance
SECTION 11 – MAINTENANCE AND STORAGE NOTE: Always purge a new filter with clean CHASSIS SERVICE AND running water before using. See filter MAINTENANCE manufacturer’s directions included with the filter cartridge. Consult the appropriate sections in your 10. Check the toilet for proper operation. chassis manual for specific information regarding operating safety, service 11.
Page 139 SECTION 11 – MAINTENANCE AND STORAGE Fuse Diagram (inside of cover) See the chassis manufacturer’s fuse allocation chart on the inside of the fuse block cover. Towing Fuses The fuses for the chassis supplied towing package are located behind the air conditioner Remove 3 screws from front edge of condenser grille panel in locations shown.
Page 140: Chassis Diagnostic Connectors
SECTION 11 – MAINTENANCE AND STORAGE Towing package fuses are on this fuse block. See chassis manufacturer’s information on inside of cover. Diagnostic plug on rear engine compartment shroud -Typical View CHASSIS DIAGNOSTIC CONNECTORS The chassis diagnostic connectors are located in on the steering column support plate beneath the dash and in the rear engine compartment as shown in the following photos.
Page 141: Coach Maintenance Chart
SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System Have propane gas system checked for leaks.
Page 142 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items Headlights, Taillights and Marker Lights Turn Signals...
Page 143 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants Inspect (see “Sealants”...
Page 144: Sealants - Recommended Application
SECTION 11 – MAINTENANCE AND STORAGE SEALANTS – RECOMMENDED APPLICATION 11-16...
Page 145: Miscellaneous
SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motor home’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available CAUTION space when loading your motor home.
Page 146 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motor home is to weigh each “corner”...
Page 147: Car Or Trailer Towing
SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction section exceed 6,000 lbs. for information on gross weight ratings.
Page 148: Trailer Wiring Connector
SECTION 12 – MISCELLANEOUS Before descending a steep or long grade when TRAILER WIRING towing a trailer, reduce speed and shift into a CONNECTOR lower gear to control vehicle speed. Avoid prolonged or frequent application of brakes Your coach is pre-wired for trailer or car which could cause overheating and brake failure.
Page 149: Entry Step - Electric
SECTION 12 – MISCELLANEOUS Gross Combination Weight Rating Ford’s towing guide (if equipped with such chassis) suggests 10 to 15 percent for trailers over (GCWR) 2,000 lbs. Within GCWR, a Class 3 hitch allows This is the maximum allowable weight of the “dingy”...
Page 150 SECTION 12 – MISCELLANEOUS Red Activation Lever Entry Step Switch - Typical The red Activation Lever located on the (Located near the entrance door) entry step switch must be depressed in order The step has several automatic extend/retract to put the step switch in the ON position. functions that are controlled by the position of a Stationary Extended Mode - Step sensor mounted on the inner edge (hinge side) of...
Page 151: Tool And Ladder Storage
SECTION 12 – MISCELLANEOUS Further Information become slippery. Do not step onto the rungs if the rungs are wet, or if your shoes are wet or For additional information on the step, see the carry mud or debris that could result in a loss manufacturer’s operators manual included in of footing.
Page 152: Power Awning
SECTION 12 – MISCELLANEOUS Low requires the least amount of motion POWER AWNING before automatically closing the awning. High requires more motion before the system –If Equipped automatically closes the awning. You may want The awning control switches are on the switch to experiment first to find the setting that best panel just inside the entrance door.
Page 153: Stepwell Cover
SECTION 12 – MISCELLANEOUS Using the Key FOB Remote Control NOTE: As a safety feature, the awning will not extend if the ignition key is on. Further Information For complete operating instructions, refer to the manufacturer’s information provided in your Function InfoCase.
Page 154: Windows
SECTION 12 – MISCELLANEOUS CAUTION Stay clear of the entrance step area when the step cover is being extended or retracted. Loose clothing may also catch on components of the mechanism when entering or exiting the coach. Personal injury and/or property damage may result.
Page 155: Power Roof Ventilator
SECTION 12 – MISCELLANEOUS Vertical Window Catches If the window will not open after three or more full turns of the knob, the glass may be stuck to POWER ROOF VENTILATOR the sealing gasket. Go to the outside of the coach and gently free the glass with your fingers.
Page 156: Air Hose Connector
SECTION 12 – MISCELLANEOUS 2. The turbine fan will start automatically as the vent dome is raised and stop as the vent dome is lowered and closed. (Fan Speed knob up on the ventilator frame must be in a position other than 0-Off).
Page 157 SECTION 12 – MISCELLANEOUS Ventilate with outside air Partially open one or more windows and a roof vent to circulate outside air through the coach. In cold weather, this ventilation may increase use of the furnace, but it will greatly reduce the condensation inside the coach.
Page 159 INDEX 2009 New Vehicle Limited Warranty ..1-8 Effects of Prolonged Occupancy ..... 12-12 About this Manual ........1-1 Electrical ............2-5 Air Conditioner Filter ........ 4-12 Electrical Cautions ........6-1 Air Conditioner/Heater – Electrical Generator ........6-6 Automotive (Dash) ......... 3-13 Electrical Outlets –...
Page 160 Index GP-go™ Portable Navigation System ..3-9 Range and Refrigerator ......11-8 Ground Fault Circuit Interrupter ....6-5 Range Top ............ 4-3 Hazard Warning Flashers ......3-11 Rearview Monitor System ......3-7 Ice Maker ............. 4-2 Rearview Monitor System ......3-8 Interior Soft Goods ........
Page 161 Index Table and Chairs .......... 9-1 Tables and Countertops ......11-7 Theater Seating/Bed Conversion ....9-6 Tires ............3-23 Toilet ............7-7 Tool and Ladder Storage ......12-7 Towing Guidelines ........12-4 Trailer Wiring Connector ......12-4 TV Antenna ..........8-6 TV Digital Satellite Dish –...

This manual is also suitable for:

Meridian itasca Journey 34y Journey 37h Journey 39z

Winnebago Journey User Manual

1 Introduction

2 Safety and Precautions

3 Driving Your Motor Home

4 Appliances and Systems

5 Propane Gas

6 Electrical

7 Plumbing

8 Entertainment

9 Furniture and Softgoods

10 Slideout Rooms and Leveling

11 Maintenance and Storage

12 Miscellaneous

Quick Links

TABLE OF CONTENTS

Related Manuals for Winnebago Journey

Summary of Contents for Winnebago Journey

This manual is also suitable for:

Table of Contents
