Vacon NX Quick Help page 3

Actual value special display
The Actual value special display
in a form more informative to the user.
The Actual value special display parameters are available in
Fan Control Application:
Par ID Parameter name
Actual value special display minimum
ID1033
Actual value special display maximum
ID1034
ID1035 Actual value special display decimals
Actual value special display unit
ID1036
Example:
The actual value signal sent from a sensor (in mA) represents the amount of waste water pumped
from a tank per second. The signal range is 0(4)...20mA. Instead of receiving the level of the actual
value signal (in mA) on the display, you wish to receive the amount of water pumped in m
then set a value for par. ID1033 to correspond to the minimum signal level (0/4 mA) and another
value for par. ID1034 to correspond to the maximum signal level (20 mA). The number of decimals
needed can be set with par. ID1035 and the unit (m
signal is then scaled between the set min and max values and displayed in the selected unit.
The following units can be selected (par. ID1036):
Value Unit
0 Not Used
1
2
3
4
5 mbar
6
7
8
9 m / s
10
11 l / min
12
13 m3 /s
14 m3 /min
NOTE: The maximum number of characters that can be shown on keypad is 4. This means that in
some cases the display of the unit on the keypad does not comply with the standards.
parameters are used to convert and display the actual value signal
On keypad
% %
°C °C
m m
bar bar
mbar
Pa Pa
kPa kPa
PSI PSI
m/s
l / s l/s
l/m
l / h l/h
m3/s
m3/m
PID Control Application
Parameter code in
PID ctrl applic.
2.2.46
2.2.47
2.2.48
2.2.49
3
/s) with par. ID1036. The level of the actual value
Value Unit
15 m3 /h
°F
16
17 ft
18 gal / s
19 gal / min
20 gal / h
21 ft3 / s
22 ft3 / min
23 ft3 / h
24 A
25 V
26 W
27 kW
28 Hp
Pump and
and
Parameter code in
Pump&Fan ctrl applic.
2.9.29
2.9.30
2.9.31
2.9.32
3
/s. You
On keypad
m3/h
°F
ft
GPS
GPM
GPH
CFS
CFM
CFH
A
V
W
kW
Hp
