6. TECHNICAL INFORMATION

Global Distribution GmbH did not test the following manufacturers' specifications for plausibility
and accuracy:
6.1 Input/Output Impedance & Sensitivity (EQ Flat, Max. Gain, FX Off, Load = 100 kOhm):
Input Impedance & Reference Level:
CD, AUX: .................................................................. 10 kOhm / -14 dBV +/-0.1 dB (200 mV)
Line: .......................................................................... 47 kOhm / -14 dBV +/- 0.1 dB (200 mV)
Phono: ...................................................................... 47 kOhm / -50 dBV +/- 0.1 dB (3.16 mV)
Mic: ........................................................................... 10 kOhm / -50 dBV +/- 0.1 dB (3.16 mV)
Return: ..................................................................... 10 kOhm / -14 dBV +/- 0.1 dB (200 mV)
Master Through: ..................................................... 22 kOhm / 0 dBV +/- 0.1 dB (1 V)
Output Impedance & Level:
Send: ........................................................................ 1 kOhm / -14 dBV (200 mV) +/- 2 dB
Rec: ........................................................................... 1 kOhm / -10 dBV (316 mV) +/- 2 dB
Master Unbalanced: ............................................... 300 Ohm / 0 dB (1 V) +/- 2 dB
Master Balanced (Load = 600 Ohm): ................. 600 Ohm / + 2.22 dBm (1 V) +/-2 dBm
Phones (Load = 32 Ohm): ..................................... 10 Ohm / 0 dBV (1 V) +2 /-3 dB
6.2 Frequency Response (EQ Flat, Max. Gain, FX Off, Master Output, Load = 100 kOhm):
Line, CD, AUX: ......................................................... 20 Hz – 20 kHz +2/-3 dB
Phono: ...................................................................... 20 Hz – 20 kHz +2/-3 dB (RIAA)
Mic: ........................................................................... 20 Hz – 20 kHz +2/-3 dB
Master Through: ..................................................... 20 Hz – 20 kHz +2/-3 dB
6.3 THD + N (EQ Flat, Max. Gain, FX Off, with 20 kHz LPF, A-weighted, Master Output: 1 V Load = 100 kOhm):
Line, CD, AUX: ......................................................... < 0.085% 20 Hz – 20 kHz
Phono: ...................................................................... < 0.085% @ 1 kHz
Mic: ........................................................................... < 0.085% @ 1 kHz
Master Through: ..................................................... < 0.085% 20 Hz – 20 kHz
6.4 Max. Input (1 kHz, Master Output, THD = 1%, EQ Flat, FX Off, Gain @ 12 o'clock)
Line, CD, AUX: ......................................................... > +6 dBV
Phono: ...................................................................... > -30 dBV
Mic: ........................................................................... > -30 dBV
Return: ..................................................................... > +2 dBV
6.5 Max. Output (EQ Flat, Max. Gain, FX Off, THD = 1%, Load = 100 kOhm):
Send: ........................................................................ > + 3 dBV (1.42 V)
Master: ..................................................................... > +16 dBV (6.31 V)
Rec: ........................................................................... > + 8dBV (2.52 V)
Phones: .................................................................... > +3 dBV (1.42 V) Load = 32 Ohm
6.6 S/N Ratio (Max. Gain, EQ Flat, with 20 kHz LPF, A-weighted, FX Off, Master Output: 1 V):
Line, CD, AUX: ......................................................... > 85 dB
Phono: ...................................................................... > 85 dB
Mic: ........................................................................... > 85 dB
6.7 Crosstalk (Max. Gain, EQ Flat, FX Off, with 20 kHz LPF, A-weighted, Master Output: 1 V):
Line, CD, AUX, Phono: ........................................... > 63 dB @ 1 kHz between left and right channel
6.8 EQ:
Mic: ........................................................................... 12 +/-2 dB, -12 +/-2 dB @ 100 Hz
Channel: ................................................................... 10 +/-2 dB, below -28 dB @ 70 Hz
6.9 Channel Balance
Within 3 dB from 0 to -40 dB
6.10 Fader kill
> 85 dB @ 1 kHz for Channel Fader and Crossfader (Master Output: 1 V)
6.11 Mic Talkover
-14 +/-2 dB
44
...................................................
.............................................................................
.......................................................................
........................................................................
> 85 dB @ 1 kHz between channels
12 +/-2 dB, -12 +/-2 dB @ 10 kHz
10 +/-2 dB, below -35 dB @ 1 kHz
10 +/-2 dB, below -28 dB @ 13 kHz
