Reloop IQ2 MIDI Instruction Manual page 29

Rear Panel
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
50.
51.
Front Panel
37.
38.
39.
40.
41.
42.
43.
44.
45.
46.
47.
DESIGNATIONS LCD INFO DISPLAy -13-
I.
II.
III.
IV.
V.
28
Input for Mains Cord
ON/OFF Switch
Input for Fader Start Function
GND Grounding Screws
Phono/Line Assignment Channels A + B
Audio Input for Channels A + B (RCA)
Audio Input for Return Signal (RCA)
Audio Output for Send Signal (RCA)
Record Audio Output (RCA)
Master Audio Output Asymmetrical (RCA)
Master Audio Output Symmetrical (6.3 mm Jack)
USB Port (Audio/MIDI Interface)
Master Through (3.5 mm Jack)
XF MIDI ON/OFF Switch (Crossfader)
AUX Input (3.5 mm Jack)
Microphone Input (6.3 mm jack)
Fader Start Switch for Channels A + B
Crossfader Curve Switch
Linefader Curve Knob
Linefader Curve Switch
Headphones Input 1 (6.3 mm Jack)
Headphones Input 2 (3.5 mm Jack)
FX MIDI ON/OFF Switch (Effect Unit)
XF Reverse (Crossfader)
I
II
Channel assignment indicator
BPM indicator
X parameter indicator
Y parameter indicator
Effect selection indicator
V
III IV
