Depending on the effect, the time parameter's type and interval and the adjustments according to
the beat assignment buttons -24-, will differ.
> ECHO = echo effect
Continuously repeats a certain interval of the signal.
Time parameter value:
Direct bar assignment:
By turning the X parameter knob -25- the value will be changed in steps of 1. Push, hold and turn the
X parameter knob -25- and the value will be changed in steps of 100.
Y parameter dry/wet value: 0 - 100%
> AUTO PAN = panorama effect
Produces the signal's continuous fading of the signal from the left to the right channel and back
again.
Time parameter value:
Direct bar assignment:
By turning the X parameter knob -25- the value will be changed in steps of 1. Push, hold and turn the
X parameter knob -25- and the value will be changed in steps of 100.
Y parameter dry/wet value: 0 - 100%
> FLANGER = flanger effect
Doubles the signal and shifts it by a marginal value.
Time parameter value: 100 – 65000 msec
Direct bar assignment: 500/1000/2000/4000/8000/16000
By turning the X parameter knob -25- the value will be changed in steps of 1. Push, hold and turn the
X parameter knob -25- and the value will be changed in steps of 100.
Y parameter dry/wet value: 0 – 100%
> MANUAL FILTER = HiPass/LowPass filter effect
With this effect you can manually control a Hipass and LowPass filter effect respectively.
Time parameter value:
Direct bar assignment:
By turning the Xparameter knob -25- the value will be changed in steps from 0.2 – 0.4. Push, hold
and turn the Xparameter button -25- and the value will be changed in steps of 0.1.
> AUTO FILTER = HiPass/LowPass filter effect
Filters high and low frequencies alternately according to the adjusted bar value.
Time parameter value:
Direct bar assignment:
By turning the X parameter knob -25- the value will be changed in steps of 10. Push, hold and turn
the X parameter knob -25- and the value will be changed in steps of 100.
Y parameter dry/wet value: 0 – 100%
> REVERB = reverb effect
Simulates reflecting sound waves in a naturally restricted area.
Time parameter value:
Direct bar assignment:
By turning the X parameter knob -25 the value will be changed in steps of 1. Push, hold and turn the
X parameter knob -25- and the value will change in steps of 10.
Y parameter dry/wet value: 0 – 100%
> TRANS = transformer effect
Creates the signal's chopping by fading in and out, similar to fast cutting with the crossfader.
Time parameter value:
Direct bar assignment:
By turning the X parameter knob -25- the value changes in steps of 1. Push, hold and turn the X pa-
rameter knob -25- and the value will change in steps of 100.
Y parameter dry/wet value: 0 - 100%
> Pitchshifter = pitchshifter effect
Raises or lowers the signal's tone pitch.
Time parameter value:
Direct bar assignment:
By turning the X parameter knob -25- the value changes in steps of 1. Push, hold and turn the X pa-
rameter knob -25- and the value will change in steps of 10.
Y parameter dry/wet value: 0 - 100%
2 – 2000 msec
Intervals adjustable from 125 – 2000
30 – 65000 msec
500/1000/2000/4000/8000/16000 msec
LowPass 0.05 – 20.2 kHz / HiPass 0.13 – 21.1 kHz
LowPass 0.45/2.27/7.13/18.4 kHz – HiPass 1.63/5.73 kHz
100 – 65000 msec
500/1000/2000/4000/8000/16000 msec
0 – 100%
0/20/40/60/80/100%
25 – 65000 msec.
500/1000/2000/4000/8000/16000 msec.
-100 – 100%
-100/-50/-33/0/50/100%
