MIMAKI Electric slicers Care Manual

Inkjet plotter is the precision machine that has highly delicate mechanism. Especially, little dust and paper
powder may have effect on a head nozzle, and may not perform normal printing.
To use the inkjet plotter in good condition, we recommend the following daily care.
1) JV3 is the plotter using the organic solvent ink. Wear supplied goggles and gloves during daily
care.
2) In case water or alcohol mixed into the organic solvent ink, flocculation occurs. Be sure to
adhere water or alcohol on the nozzle, near the head, the cap, and wiper.
3) When not using this plotter for a long time, it is necessary to flash little ink periodically to obtain
the ink flashing stability.
When not using for a long time, perform the [CUSTODY wash] function (Operation manual
Chapter5) and turn off the front power switch. The main power switch at rear should be on (The
"on" mark described as a vertical line " | " on the switch) and also keep the socket inserted.
•
•
•
•
•

1. Installation environment

• Use this plotter in clean (less dust) environment. The use of fan and ventilator might be a cause of dust brow up.
• To use the organic solvent ink, install this plotter in a well-ventilated area.
• This plotter should be used at 20 to 35
and humidity.
Inkjet plotter JV3 series
Request for daily care
CAUTION
Do not disassemble this plotter. It causes an electric shock, fire, and damages.
Be sure to not water into the inside of this plotter. If the inside gets wet, it causes
an electric shock, fire, and damages.
Before start the daily care, turn off the power supply, and disconnect an electric
cable.
It causes unexpected accident.
Do not use benzine, thinner, and the chemicals contained abrasives. The surface
of the cover may be deteriorated or deformed.
Do not apply lube oil on the inside of this plotter. The plotter mechanism may be
damaged.
o C and 35 to 65%Rh. Avoid using at lower or higher than this temperature
1
not
D201103-12
