JV3 Series
Operation Manual - 清洗墨水管路( 噴頭)
抽墨幫浦墨管(Pump Pipe)清洗 [Disway WASH] .................................... 2
休眠狀態自動清洗功能 [SLEEP clean] ..................................................... 4
機器長時間閒置未使用,清洗墨水管路及噴墨頭 [CUSTODYwash] ...... 5
刮板(Wiper) 參數設定 [INT.WIPING] ................................................... 7
Table of contents
MIMAKI ENGINEERING Co., Ltd. 2003
Phone: (03) 493-6095
E-mail : vancolor@seed.net.tw
VanColor Tech. Inc. - 汎彩編譯
Fax: (03) 493-6609
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MIMAKI JV3 Series
Summary of Contents for MIMAKI JV3 Series
- Page 1 Table of contents 抽墨幫浦墨管(Pump Pipe)清洗 [Disway WASH] ........2 休眠狀態自動清洗功能 [SLEEP clean] ............. 4 機器長時間閒置未使用,清洗墨水管路及噴墨頭 [CUSTODYwash] ..5 刮板(Wiper) 參數設定 [INT.WIPING] ........... 7 MIMAKI ENGINEERING Co., Ltd. 2003 Phone: (03) 493-6095 Fax: (03) 493-6609 E-mail : vancolor@seed.net.tw VanColor Tech. Inc. - 汎彩編譯...
-
Page 2: 抽墨幫浦墨管(Pump Pipe)清洗 [Disway Wash]
抽墨幫浦墨管清洗(Pump Pipe)[Disway WASH] The ink discharge way may become clogged by coagulated ink. It must be cleaned at regular intervals to avoid clogging. Ink discharge way: Tubing between the cap and the waste ink tank • When cleaning the ink station and head, be sure to wear the supplied goggle and gloves since you may get ink in your eyes. - Page 3 7. 打開機器前方保護蓋. 8. 打開清潔液,用滴管將清潔液吸滿. 使用滴管將清潔液滴入噴頭蓋(S-Cap), 勿將清潔液 溢出噴頭蓋(S-Cap).重覆其他噴頭蓋(S-Cap). 9. 蓋下機器前方保護蓋 , 然 後按下 [ENTER] STATION COMPLETED : ent 鍵 . 當抽墨幫浦連續抽30秒後機器LCD會停在"LOCAL"模式 INITIALIZING PLEASE WAIT < LOCAL >...
-
Page 4: 休眠狀態自動清洗功能 [Sleep Clean]
休眠狀態自動清洗功能 [SLEEP clean] To prevent clogging while the power switch has been turned off, ink is ejected from the head at regular intervals. The head itself must be cleaned also at regular intervals which are set as shown below. STEP 1. -
Page 5: 機器長時間閒置未使用,清洗墨水管路及噴墨頭 [Custodywash]
機器長時間閒置未使用,清洗墨水管路及噴墨頭 [CUSTODYwash] 當機器長時間閒置未使用,超過一週以上 使用 “CUSTODYwash” 功能來清洗 頭 及抽墨管路(Pump Pipe) . 噴 需 確實做完此功能, 才 能正常存放機器. Cleaning tools • leaning solution Pipette RS (SPC-0336), • Glove, Goggle STEP 1. 按 下 [FUNCTION] 鍵 . FUNCTION SET UP < ENT > 2. 按 上下鍵 [ ] and [ ] 一直到 FUNCTION LCD顯示... - Page 6 9. 按上下 [ ] and [ ] 鍵 , 選擇欲泡清潔液 STATION 時間. (1-99 分 鐘 : 1 分鐘為單位) LEAVING : 1 min 一 般設設訂1分鐘. 10. 蓋上機器前方保護蓋 , 然 後按[ENTER] INITIALIZING PLEASE WAIT 開 始清洗噴墨頭. 11. 當 噴墨頭清洗完畢,噴墨座會移出至列印工作平台. STATION 打開機器前方保護. COMPLETED : ent 12.
-
Page 7: 刮板(Wiper) 參數設定 [Int.wiping]
In case of setting for heaters at high temperature, or setting too much amount of ink per unit (high concentration, render set, etc.) on the JV3 series, “spray”, “mass of ink”, or “nozzle-out” phenomena may happen due to evaporation of the solvent medium that may condense on a print-head surface resulting inferior image quality. - Page 8 8. 按下 [ENTER] 鍵 . INT.WIPING [SCAN COUNT] LCD顯示 . SCAN COUNT < ent > 9. 按上下鍵 [ ] or [ ] 一直到LCD顯示 INT.WIPING [TEMP.DIFF.]. TEMP.DIFF. < ent > 10. 按下 [ENTER] 鍵 . INT.WIPING TEMP.DIFF. = 20 ° C 11.
- Page 9 Function Flowchart Correcting the medium feed rate FUNCTION FEED COMP. * REMOTE * FEED COMP. TYPEx x.xxm ENTER FEED COMP. SAVE :ent ENTER * REMOTE * TYPEx+ x.xxm FUNCTION Key : FUNCTION FUNCTION ENTER ENTER MAINTENANCE MAINTENANCE PRINTadjust <ent> HEAD HEIGHT :LOW LOW.
- Page 10 D200865-1.20-10092003 © MIMAKI ENGINEERING Co., Ltd. 2003...
