Operating Instructions - CTEK MUS 4.3 POLAR Manual

OPERATING INSTRUCTIONS

CHARGING WITH MULTI OPTIONS
1. Connect the charger to the battery.
2. Connect the charger to the wall socket.
3. Press the MODE-button to select charging program.
SMALL BATTERY
PROGRAM
Continue to press the MODE-button to combine charg-
ing program with charging options.
COLD
WEATHER
OPTION
Press the MODE-button several times until the desired
combination of charging program and options are lit.
4. Follow the 8-step display through the charging process.
The battery is ready to start the engine when STEP 4 is
lit.
The battery is fully charged when STEP 7 is lit.
5. Stop charging at any time by disconnecting the mains
cable from the wall socket.
20018878A MUS 4.3 Polar, Manual, Print file_001.indd 9
NORMAL
BATTERY
PROGRAM ERROR
LAMP
RECOND
OPTION
POWER
LAMP
MODE-
READY
BUTTON TO USE
MODE
RECOND
SMALL NORMAL COLD
BATTERY BATTERY WEATHER
PROGRAM PROGRAM OPTION
FULLY
CHARGED
MUS
RECOND
OPTION
EN • 9
2013-01-15 16:29:17
