Technical Specifications
Video Amplifier Bandwidth
Supported Video Resolutions
Max Distance
(Cat 5e)
Max Distance
(Cat 6 – low skew recommended)
Supported IR Carrier Frequencies
Input Video Signal
Input DDC Signal
Input Unit Connectors
Output Unit Connectors
Cabling
Power
Power Connector
Dimensions
Temperature
Shipping Weight
Warranty
Regulatory
Intelix Part Number
Ordering Information
The Intelix DIGI-HD-IR2 conforms to HDMI and HDCP specifications. Intelix
does not guarantee operation with devices that do not conform to these
specifications. The Intelix DIGI-HD-IR2 passes HDCP signals and does not
manipulate them in any way.
Distances and picture quality may be affected by cable grade, cable quality, source
and destination equipment, RF and electrical interference, and cable patches. Intelix
specifications are based on straight-through cabling with standard-grade Cat 5e.
1.65 Gbps
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
1080p: 100'
1080i/720p: 200'
1080p: 150'
1080i/720p: 300'
36-40 kHz
1.2 volts p-p
5.0 volts p-p (TTL)
(1) Type A HDMI connector to (2) RJ45s
(1) 1/8" mini (3.5 mm) female IR connector
(2) RJ45s to (1) Type A HDMI connector
(1) 1/8" mini (3.5 mm) female IR connector
Two individual runs of Cat 5e or Cat 6
External 5 VDC
Powered on both ends
4.38" x 2.50" x 1.00"
Operating: 0° to 55°C
Storage: -20° to 85°C
Humidity: up to 95%
1 lb.
2 years
CE, RoHS
DIGI-HD-IR2
DIGI-HD-IR2 package includes one send unit, one
receive unit, one IR emitter, one IR receiver, and two
power supplies
