Troubleshooting - Intelix DIGI-HD-IR2 Installation Manual

Troubleshooting

Symptom
No signal
Status LED is off
No signal
Status LED is off
No signal
Unusual colors in
the video
No signal
Screen is
completely snowy
Speckling in the
video image
Occasional signal
dropouts
Video without
audio
Speckling in the
video image
Video without
audio
Probable Causes
Incorrect cable
termination
Incorrect cable
connection
Insufficient power
HDMI
synchronization
issues
Video signal exceeds
bandwidth of cabling
Unsupported video
resolution
Unsupported audio
codec
Possible Solutions
Verify that both ends of the twisted pair
cables use 568B crimp pattern.
Swap the twisted pair cables in the AV and
HDCP RJ45 inputs on the receive balun.
Verify the power supplies are connected to
both the send and receive baluns.
Verify the power LEDs on both the send
and receive units are brightly illuminated.
Power off the destination device and power
it back on to force renegotiation.
Unplug and re-plug the HDMI cable from
receive balun to force renegotiation.
Use shorter runs of twisted pair cabling.
Drop the HDMI signal to the next lower
resolution; i.e., decrease resolution from
1080p to 1080i, etc.
Replace the twisted pair cable with a
higher grade twisted pair cable; i.e.,
replace Cat 5e with Cat 6.
If the destination device is incapable of
displaying the video signal, alter the source
signal; i.e., decrease resolution from 1080p
to 1080i, etc.
Change source device to output PCM other
than Bitstream audio
Enable PCM down sampling if supported
by your source device
