Technical Specifications - Intelix NT-HD70-TXWP Quick Install Manual

Supported Audio and Video
Video Compliance
Input / Output Resolution Support
Embedded Audio
IR Carrier Frequency Range
HDBaseT Signal Characteristics
Maximum Distance
Cable Requirements
Bandwidth
Chassis and Environmental
Dimensions (H x W x D)
Product Weight
Operating Temperature
Storage Temperature
Operating Humidity (Environment)
ESD Protection
Surge Protection
Power
Maximum Power Consumption
Power Supply Input Voltage
Power Supply Output Voltage
Regulatory
Other
Standard Warranty
Included Items
Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and
electrical interference, and cable patches.

Technical Specifications

HDMI 2.0+, HDCP2.2, and CEC (Consumer Electronics Control)
Up to 4096x2160@60Hz (4:2:o chroma sub-sampling / 8 bit deep color)
Up to PCM 8 channel, Dolby Digital, DTS, TrueHD, DTS-HD Master Audio and
Dolby Atmos
30-50kHz at 5 volts
1080p: 70 meters / 231 feet
4K@60Hz 4:2:0 40 meters / 132 feet
Solid core shielded Category 6 F/UTP or greater with TIA/EIA-568B crimp
pattern
10.2 Gbps
103 mm x 50 mm x 50 mm (4.07 in x 1.9 in x 1.9 in)
180g / 0.39lbs
-5° to +55° C (+23° to +131° F)
-20°C to 70°C (-4°F to 158°F)
10% to 90%, Non-condensing
Human-body Model:
±8kV (Air-gap discharge)
±4kV (Contact discharge
Voltage: ±1 kV
9 watts
100-240V AC at 50-60 Hz
12V DC
CE, FCC, RoHS
5 Years
Quick Guide, (3) 2 pin Phoenix connectors, (1) 3 pin Phoenix connector, (2)
Mounting screws
INT-HD70-TXWP Quick Guide
