Intelix DIGI-HD-IR3-WP Installation Manual

DIGI-HD-IR3-WP Installation
Manual
The Intelix DIGI-HD-IR3-WP transmits HDMI and IR up to 300'
over two twisted pair cables. In environments with high
electromagnetic interference (EMI), shielded twisted pair
cable should be used.
Built-in HDshāk® technology provides dynamic HDMI,
EDID/DDC and HDCP mode
performance and image quality. Plus, onboard HDMI
amplification and buffering allows multiple extenders to be
daisy-chained for greater distances.
The DIGI-HD-IR3-WP features electrostatic discharge (ESD)
protection circuitry which safegaurds the HDMI circuit against
static electricity and other destructive stray voltage.
Compatible Devices
Compatible Receivers: DIGI-HD-IR3-R, DIGI-HD-IR3-WP-R,
*DIGI-HD-IR2-R
Compatible Transmitters: DIGI-HD-IR3-S, DIGI-HD-IR3-WP-S,
*DIGI-HD-IR2-S, DIGI-HD-4X2, DIGI-HD-4X4, DIGI-HD-4X8,
DIGI-HD-8X8,
*when paired with 2-series extenders, bi-directional IR
is not supported; only source-to-display
Maximum Recommended Distances
1080p 1080i
Cat 6a 150' 300'
(shielded)
Cat 6 110' 220'
Cat 5e 100' 200'
selection, guaranteeing
720p 576i/p 480i/p
300' 300' 300'
220' 220' 220'
200' 200' 200'
