- Page 1 AT-11MP Automatic Antenna Tuner Manual Version 2.3G LDG Electronics 1445 Parran Road, PO Box 48 St. Leonard MD 20685-2903 USA Phone: 410-586-2177 Fax: 410-586-8475 ldg@ldgelectronics.com www.ldgelectronics.com...
- Page 2 - 1 - Introduction: The AT-11MP is a full-featured auto or semi automatic antenna tuner designed for HF (1.8 to 30 MHz) transceivers using between 5 to 150 watts. The tuner uses a switched “L” configuration with 256 capacitor, 256 inductor and Hi/Lo-Z settings to provide over one hundred and thirty thousand tuning combinations.
- Page 3 Power and ground must still be provided through the AT-11 MP coaxial power jack. Also be sure to power the AT-11MP on first, then the radio to allow the radio to know that a remote tuner is present.
- Page 4 A 40-meter dipole (at 30 feet) would tune just about anywhere from 3.1 to 30 MHz! We had some problems at 19 and 28 MHz finding a 1.5 match. The AT-11MP usually found a 2.0, and then we had to use the manual switches to get below 1.5.
- Page 5 - 4 - Service: If you have a problem with your LDG Product, please call or e-mail us and we will gladly try to resolve the problem remotely. If we can identify the suspect component, and you are able to install it, we will ship the component directly to you at no charge for warranty repairs, cost plus shipping for non-warranty repairs.
