1.4 Ports

I
NSTALLATION AND
tem can be fast and easy and can eliminate the need to pull
cable through walls and ceilings. Wireless technology allows the
network to go where wires cannot go - even outside the home or
office.
I S
NEXPENSIVE OLUTION
petitively priced as conventional Ethernet network devices.
S - WLANs can be configured in a variety of ways to
CALABILITY
meet the needs of specific applications and installations. Configu-
rations are easily changed and range from Peer-to-Peer networks
suitable for a small number of users to larger infrastructure
networks to accommodate hundreds or thousands of users, de-
pending on the number of wireless devices deployed.
1.4 Ports

1.4.1 Analog

The HorstBox provides two ports for analog devices and one port
for the telephone line.
Note: For an analog telephone line connect the socket with the
port "a/b" on the HorstBox.

1.4.2 ISDN

The HorstBox provides one port for an ISDN device (internal S
Bus) and a port for an ISDN telephone line. To connect 2 or
more ISDN devices, use an ISDN distributor (ISDN hub). You may
connect a total of 8 ISDN devices to the internal S
HorstBox administrates up to 20 different ISDN devices.
1
If you want to connect more than 4 devices, the additional devices will need
their own power supply.
N E
ETWORK XPANSION
- Wireless network devices are as com-
- Installing a WLAN sys-
-Bus.
