Quick Installation Guide

Check Your Package Contents

DVG-G5402SP
VoIP Router
DVG-G5402SP
VoIP Router
CD-ROM
Phone Cord
X 2
which
includes
the User
Manual
Ether (CAT5
UTP) Cable
12VDC, 1A
Power Adapter
Using a
power
adapter with
a different
voltage rating
will damage
this product
and void the
warranty.

Advertisement

Table of Contents
loading

Related Manuals for D-Link DVG-G5402SP

Summary of Contents for D-Link DVG-G5402SP

  • Page 1: Quick Installation Guide

    Quick Installation Guide DVG-G5402SP VoIP Router Check Your Package Contents DVG-G5402SP CD-ROM Phone Cord Ether (CAT5 12VDC, 1A VoIP Router which UTP) Cable Power Adapter includes the User Using a Manual power adapter with a different voltage rating will damage...

  • Page 2: Hardware Overview

    WLAN：A steady light indicates a wireless connection. A blinking light indicates that DVG-G5402SP is receiving / transmitting from/to the wireless network LAN：When a connection is established the LED will light up solid on the appropriate port.

  • Page 3: Rear Panel

    Hardware Overview Rear Panel Antenna: Connect to a wireless network. Line: Connect to your original telephone line on the wall jack with RJ-11 cable. Phone Port (1-2): Connect to your phones using standard phone cabling (RJ-11). LAN: Connect to your Ethernet enabled computers using Ethernet cabling.

  • Page 4: Installing The Hardware

    Installing the Hardware A. Insert one end of the Ethernet cable into the Ethernet (LAN) port on the back panel of the DVG-G5402SP and the other end of the cable to an Ethernet Adapter or available Ethernet port on your computer.
  • Page 5 E. Connect the power adapter to the power input at the back panel of the DVG-G5402SP and then plug the other end of the power adapter to a wall outlet or power strip. On the front of the device, the Power LED will turn On to indicate proper operation.
  • Page 6 Installing the Hardware (continued) After the installations are completed, your network should look similar to the diagram below. Hardware configuration is complete! If your VoIP service is already activated, you can make phone calls now.
  • Page 7 Configuration To access the web-based configuration utility, open a web browser such as Internet Explorer and enter the IP address of the DVG-G5402SP. Open your Web browser and type http://192.168.8.254 into the URL address box. Press the Enter or Return Key.
  • Page 8 Configuration (continued) Click Next. The username of ADMIN and USER have been defined and locked by default. It is highly recommended to create a login password to keep your router secure. Click Next. Enter a NTP server or use the default server.
  • Page 9 Configuration (continued) Select your Internet connection type: DHCP – Most Cable ISPs or if you are connecting the DVG-G5402SP behind a router. Static IP – Select if your ISP supplied you with your IP settings. PPPoE – Most DSL ISPs.
  • Page 10 Select your wireless security modes: None, WEP, WPA-PSK, or WPA for your wireless network. Click Next Setup is finished. Check the summary of your settings. To make new settings effective, you must click on the Restart button to reboot the DVG-G5402SP. Click Restart.

  • Page 11: Technical Support

    Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers within United States: D-Link Technical Support over the Telephone: (800)326-1688 D-Link Technical Support over the Internet: http://support.dlink.com email:support@dlink.com Ver.1.10 (WW) 2009/08/26...
