Section 10. Parts List and Exploded View

10.1 Jandy JS60-SM Sand Filter Parts List

Key
No.
Description
1
Lid, Sand Filter
2
Lid Seal, Sand Filter
3
Gauge/Air Release Assembly
4
Pressure Gauge
5
Tank Adapter with O-Ring and Union
6
Diffuser, JS60-SM
7
Air Relief Assembly
8
Inlet Piping Kit JS60-SM
9
Outlet Piping Kit JS60-SM
10
Nuts, Slip Rings and Inner Spacers JS60
11
Hub Assembly with 24" Laterals JS60
12
Screw, #10 x 3/4" SS (Qty 6)
13
Sand Filter Drain Fitting Assembly
14
Drain Screen Assembly
15
Drain Fitting Seals Kit
16*
O-Ring and Hardware Kit
17
Outlet Fitting, Complete JS60
18
Inlet Fitting, Complete JS60
19*
Sweep Elbow
* Not Shown

10.2 Jandy JS100-SM Sand Filter Parts List

Key
No.
Description
1
Lid, Sand Filter
2
Lid Seal, Sand Filter
3
Gauge/Air Release Assembly
4
Pressure Gauge
5
Tank Adapter with O-Ring and Union
6
Diffuser
7
Air Relief Assembly
8
Inlet Piping Kit JS100-SM
9
Outlet Piping Kit JS100-SM
10
Nuts, Slip Rings and Inner Spacers JS100
11
Hub Assembly with 30" Laterals JS100
12
Screw, #10 x 3/4" SS (Qty 6)
13
Sand Filter Drain Fitting Assembly
14
Drain Screen Assembly
15
Drain Fitting Seals Kit
16*
O-Ring and Hardware Kit
17
Outlet Fitting, Complete JS100
18
Inlet Fitting, Complete JS100
19*
Sweep Elbow
* Not Shown
Trademarks used herein are the property of their respective owners.
JS Series Sidemount Sand Filters
Part No.
R0487300
R0487400
R0357200
R0359600
R0552000
R0487501
R0487600
R0519901
R0520001
R0520100
R0520200
R0488100
R0488200
R0488300
R0488400
R0488500
R0520300
R0520400
SEFL 1002
Part No.
R0487300
R0487400
R0357200
R0359600
R0552000
R0487500
R0487600
R0487700
R0487800
R0487900
R0488000
R0488100
R0488200
R0488300
R0488400
R0488500
R0488600
R0488700
SEFL 1002
