- Page 1 USER GUIDE & INSTALLATION INSTRUCTIONS Mercury 1082 Induction...
- Page 2 SLOW BAKED LEG OF LAMB METHOD 1. Preheat the oven to 220 ¡C (for a conventional oven), 200 ¡C (for a fan oven) or gas mark 7. 2. Pull the small sprigs off the rosemary branches and set aside with the garlic. 2.
-
Page 3: Table Of Contents
Contents Before You Start... Troubleshooting Installation and Maintenance Installation Peculiar Smells Dear Installer Ventilation Safety Requirements and Regulations Personal Safety Provision of Ventilation Hob Care Location of Cooker Cooker Care Positioning the Cooker Cleaning Moving the Cooker Cooker Overview Fitting the Flue and Vent The Hob Fitting the Side Panel and Obscuring Trims... -
Page 5: Before You Start
1. Before You Start... DocNo.015-0306 - Introduction - Induction - Single cavity Personal Safety Thank you for buying a this cooker. It should give you many years of trouble-free cooking if installed and operated Important information for pacemaker and implanted correctly. -
Page 6: Hob Care
Cooking high moisture DO NOT use water on grease res and never pick up a aming pan. Turn o the controls and then content foods can create smother a aming pan on a surface unit by covering a ‘steam burst’ when the oven door is opened. -
Page 7: Cooker Overview
2. Cooker Overview DocAUS.020-0004 - Overview - 110DF - Elan Fig.2-1 The 1082 induction cooker (Fig.2-1) has the following Fig.2-2 features: 5 induction cooking zones A control panel A glide-out grill Main multi-function oven Tall fan oven The Hob Use only pans that are suitable for induction hobs. We recommend stainless steel, enamelled steel pans or cast iron pans with enamelled bases. - Page 8 The very best pans have bases that are very slightly curved Fig.2-3 up when cold (Fig.2-3). If you hold a ruler across the bottom you will see a small gap in the middle. When they heat up the metal expands and lies at on the cooking surface. Make sure that the base of the pan is clean and dry to prevent any residue burning onto the hob panel.
-
Page 9: Child Lock
Automatic Heat-up, A Auomatic Heat-up Time at Power level 100% (min:sec) This function is available on all of the cooking zones. It allows rapid heating up of the element to bring the selected 0:48 cooking zone up to temperature. Once the zone is at the 2:24 required cooking temperature the power level will reduce automatically to the preset level. - Page 10 increase the heat, just turn the control knob to the required Fig.2-8 level. A & B linked D & E linked Power Boost Setting, P All of the induction cooking zones have Power Boost available, activated by turning the control knob clockwise until [ P ] is shown on the hob control display.
- Page 11 The Glide-out Grill Fig.2-9 CAUTION: Accessible parts may be hot when the grill is in use. Young children should be kept away. CAUTION: This appliance is for cooking purposes only. It must not be used for other purposes, for example room heating. Open the door and pull the grill pan carriage forward using the handle (Fig.2-9).
-
Page 12: The Ovens
The Ovens Fan oven cooking is particularly suitable for baking on several shelves at one time and is a good ‘all-round’ function. It may References to ‘left-hand’ and ‘right-hand’ ovens apply as viewed be necessary to reduce the temperature by approximately from the front of the appliance. -
Page 13: Operating The Ovens
Browning Element Function This function uses the element in the top of the oven To thaw small items in the oven without Defrost only. It is a useful function for the browning or heat nishing of pasta dishes, vegetables in sauce, A full cooking function, even heat shepherds pie and lasagne, the item to be browned being Fan oven... -
Page 14: Accessories
Accessories Fig.2-16 Fig.2-17 Oven Shelves The cooker is supplied with the following: Left-hand Oven 1 standard shelf (Fig.2-16) 1 drop shelf (Fig.2-17) 1 telescopic shelf with runners (Fig.2-18) 1 set of side supports (Fig.2-19) Fig.2-18 Fig.2-19 Right-hand Oven 4 at cooking shelves (Fig.2-20) 1 plate warming shelf (Fig.2-21) 1 set of side supports (Fig.2-22) To Remove and Re t the Shelves... -
Page 15: Cooking Tips
3. Cooking Tips Cooking with a Multi-function Oven General Oven Tips Remember: not all modes are suitable for all food types. The The wire shelves should always be pushed rmly to the back oven cooking times given are intended for a guide only. of the oven. -
Page 16: Cooking Table
4. Cooking Table DocNo.031-0004 - Cooking table - electric & fan single cavity The oven control settings and cooking times given in the table below are intended to be used Top (T) AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a preferred result. -
Page 17: Cleaning Your Cooker
5. Cleaning Your Cooker Isolate the electricity supply before carrying out any major Fig.5-1 cleaning. Allow the cooker to cool. Never use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. Do not mix di erent cleaning products – they may react together with hazardous results. -
Page 18: Glide-Out Grill
Glide-out Grill Fig.5-2 Before you remove any of the grill parts for cleaning. make sure that they are cool, or use oven gloves. The grill pan and grill tray assembly can be easily removed for cleaning. Wash the grill pan and trivet washed in hot soapy water, or using our recommended Rangemaster cleaning solution. -
Page 19: Ovens
Ovens Fig.5-6 Fig.5-7 Base Tray The ovens have a removable base tray, which can be easily removed for cleaning. Wash the base tray with a proprietary enamel cleaner, or using our recommended Rangemaster cleaning solution. Alternatively, wash the base tray in a dishwasher. ‘Cook &... -
Page 20: Cleaning Table
Cleaning Table Cleaners listed (Table 5-1) are available from supermarkets or electrical retailers as stated. For enamelled surfaces use a cleaner that is approved for use on vitreous enamel. Regular cleaning is recommended. For easier cleaning, wipe up any spillages immediately. Hotplate Part Finish... -
Page 21: Troubleshooting
6. Troubleshooting DocNo.053-0003 - Troubleshooting - In G5 Interference with and repairs to the hob MUST NOT The induction hob is noisy be carried out by unquali ed persons. Do not try When using the induction hob there may be some to repair the hob as this may result in injury and ‘noise’... - Page 22 If there is an installation problem and I don’t get my The oven is not cooking evenly original installer to come back to fix it, who pays? Do not use a baking tray with dimensions larger than You do. Service organisations will charge for their call- those specified in the section on ‘General Oven Tips’...
-
Page 23: Installation
INSTALLATION Check the appliance is electrically safe when you have nished. 7. Installation You will need the following equipment to complete the Dear Installer cooker installation satisfactorily: Before you start your installation, please complete the details • Multimeter (for electrical checks). below, so that, if your customer has a problem relating to your installation, they will be able to contact you easily. -
Page 24: Positioning The Cooker
INSTALLATION Check the appliance is electrically safe when you have nished. Positioning the Cooker Fig.7-1 Fig.7-1 and Fig.7-2 show the minimum recommended distance from the cooker to nearby surfaces. The cooker 33 mm 33 mm 800 mm should not be placed on a base. Above hotplate surround should be level with, or above, any adjacent work surface. -
Page 25: Completing The Move
INSTALLATION Check the appliance is electrically safe when you have nished. Lowering the Two Rear Rollers Fig.7-5 To adjust the height of the rear of the cooker, rst t a 13 mm spanner or socket wrench onto the hexagonal adjusting nut (Fig.7-5). -
Page 26: Fitting The Side Panel And Obscuring Trims
INSTALLATION Check the appliance is electrically safe when you have nished. Fitting the Side Panel and Obscuring Fig.7-9 Trims IMPORTANT: Before tting the side panels you must rst remove the transit brackets. Loosen the two screws in the underside of the transit bracket (Fig.7-9). Slide the bracket forwards and remove. -
Page 27: Repositioning The Cooker Following Connection
INSTALLATION Check the appliance is electrically safe when you have nished. Repositioning the Cooker Following Connection If you need to move the cooker once it has been connected then you need to unplug it and, having gripped under the fascia panel and lifted the front of the cooker slightly (Fig.7-6), you need to check behind the cooker to make sure that the electricity cable is not caught. -
Page 28: Electrical Connection
INSTALLATION Check the appliance is electrically safe when you have nished. Electrical Connection Fig.7-15 This appliance must be installed by a suitably quali ed electrician to comply with the relevant electrical regulations, and also the local electricity supply company requirements. Current Operated Earth Leakage Breakers The combined use of your cooker and other domestic 10 mm²... -
Page 29: Final Fitting
INSTALLATION Check the appliance is electrically safe when you have nished. Final Fitting Fig.7-17 Fitting the Bottom Panel Open the ovens doors. On the front of the cooker base there are two mounting plates. Remove the three xing screws from each plate. Fit the retaining brackets to the mounting plates and re t the screws (Fig.7-17). -
Page 30: Circuit Diagrams
8. Circuit Diagrams Circuit Diagram: Hob Cooling fan activation lead Earth Induction unit Hob display ArtNo.083-0013 - IN 1200 - Circuit diagram - Mercury L(1) L(2) L(3) N4 w/br Interface w/br w/br board w/br w/br Code Description Code Colour w/br White or brown Left-hand front element Left-hand back element Right-hand back element... -
Page 31: Circuit Diagram: Ovens
Circuit Diagram: Ovens P095199 P095199 P095199 P028728 The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Description Code Description Code Colour Left-hand MF oven control Right-hand fan oven control switch Blue Left-hand MF oven control switch Right-hand fan oven thermostat... -
Page 32: Technical Data
9. Technical Data DocNo.103-0014 - Technical data - IN 1200 - Mercury INSTALLER: Please leave these instructions with the User. DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening. COUNTRY OF DESTINATION: GB, IE, FR, NL, BE, DE, AT, SE, CH. Connections Electric 230 / 400 V 50 Hz... - Page 36 Clarence Street, Royal Leamington Spa, Warwickshire, CV31 2AD, England. Tel: +44 (0) 1926 457400 Fax: +44 (0) 1926 450526 E-mail: consumers@falconappliances.co.uk...
