Horn Output; Printer Connection - Icom IC-F5122D Operating Manual

■ Horn output

The automatic honking function can be used when a horn is
connected to the transceiver through the optional ACC cable
OPC-1939 (D-Sub 15-pin) or OPC-2078 (D-Sub 25-pin).
When a status message is received, the transceiver sounds
the vehicle's horn for the specified time period to inform you
that a status message has being received.
This function is convenient when the operator is away from
the transceiver.
Ask your dealer or system operator, or refer to the IC-F5122D/
F6122D service manual for connection and setting details.

■ Printer connection

When the printer is connected to the transceiver through the
OPC-2078, the received SDM content and the called station
ID can be printed out. Ask your dealer or system operator for
connection details.
