OEM Lip Mount Camera with Harness and OnStar Mirror for GM
Vehicles with 16-pin Mirror Connector
(Kit part number 9002-8722)
Items Included in the Kit:
Bubble bag containing:
Camera with Mount
Mirror
Mirror Harness
Chassis Harness
Zip lock bag containing:
12 Zip Ties
2 Rubber Well Nuts
2 Bolts
2 sets of T-taps
Zip lock bag containing:
These Instructions
Self-adhesive Template
ATTENTION:
vehicles that are equipped with the 16-pin Mirror Connector illustrated on Page 4. Some
GM vehicles with OnStar are equipped with a 10-pin connector. For these applications,
purchase a 10-pin mirror kit BrandMotion part number 9002-8723
For a current list of GM vehicles equipped with a 10 pin connector,
download the latest application guide at www.brandmotion.com/docs2/rvsappguide.pdf
Safety Precautions:
Work in a well ventilated area that is clear of obstructions.
•
Secure vehicle with tire chucks in both front and rear of tires.
•
Turn vehicle accessories OFF and ensure ignition key is in OFF position.
•
Wear safety goggles and snug fitting clothes.
•
Use tools only for their intended purpose and which are in good repair.
•
Only perform this task if confidence, skill, and physical ability permit.
•
NOTE: We strive to provide accurate and up-to-date installation instructions.
For the latest full color instructions, please visit www.brandmotion.com
8722 Instructions 2-9-15.doc
Please read thoroughly before starting installation
and check that kit contents are complete.
16 Pin Mirror Connector required
INSTALLATION
I NSTRUCTIONS
Tools & Supplies Needed:
Phillips Screwdriver
5/16" Drill Bits
7/8" or 22mm Center Hole Saw
Power Drill
Deburring Tool or Round File
Multi-meter or computer safe test light
Wire Crimper
Rust Inhibitor
Soldering Iron
Solder
(Recommended)
Plastic Trim Removal Tool
Page 1 of 6
(Recommended)
(Recommended)
- This kit only works on
Advertisement
Related Manuals for BrandMotion 9002-8722
Summary of Contents for BrandMotion 9002-8722
-
Page 1: Safety Precautions
16-pin Mirror Connector illustrated on Page 4. Some GM vehicles with OnStar are equipped with a 10-pin connector. For these applications, purchase a 10-pin mirror kit BrandMotion part number 9002-8723 For a current list of GM vehicles equipped with a 10 pin connector, download the latest application guide at www.brandmotion.com/docs2/rvsappguide.pdf... - Page 2 INSTALLATION I NSTRUCTIONS Step 3: Use a Center Punch to mark the centers of Step 1: Place Camera Mount in desired position to the required three holes and drill three pilot holes confirm fitment. (IMPORTANT: Some states using a 1/8” drill bit. NOTE: If your vehicle has a prohibit items blocking the vehicle license plate;...
- Page 3 INSTALLATION I NSTRUCTIONS Step 11: Route Chassis Harness forward. It may be necessary to remove sill plates, pillar covers, Step 9: Route Camera Harness towards the side of seat bases, side panels, etc. using a Plastic Trim the vehicle that supplies power. It may be Removal Tool.
- Page 4 !"#$%&&%$!'"(!"#$)*+$!'"#( Step 20: Connect the 6-pin connector of the supplied Mirror Harness to the supplied Chassis Harness. Step 14: Attach supplied Mirror to the windshield using a T20 Torx Driver. This Tuck any excess harness beneath the headliner mirror has a Wedge/ D-tab style mounting base. taking care not to bind the wires.
-
Page 5: Wire Color
INSTALLATION I NSTRUCTIONS Mirror Harness Pinouts 6-PIN 16-PIN Pin # Pin # WIRE COLOR WIRE COLOR FUNCTION 1 n/a 2 n/a 3 n/a 4 n/a 5 - Gray Exterior Auto Dimming (+) 1 -White 6 - White Video + 4 - Brown 7 - Brown Video -... - Page 6 INSTALLATION I NSTRUCTIONS Ignition & Reverse Locations and Wire Colors IGNITION CONNECTOR REVERSE CONNECTOR VEHICLE LOCATION WIRE COLOR & PIN WIRE COLOR & PIN BCM X7 BCM X6 Buick Enclave Driver side below IP Chevrolet cluster left Traverse of steering column GMC Acadia...
