Beep - Touch ON or OFF to turn the selection confir ation beep ON or OFF.
Wallpaper - Touch Engine Start, Blue Haze, Green Cubes, Red Swirl or Tribal to
select the TFT LCD wallpaper. Touch again to confir and set the wallpaper.
Calibration- The Touch Screen Calibration adjust ent is used to set the
para eters of the touch screen to ensure that when the screen is touched, it
corresponds to the feature desired.
Note: Never use a pen or sharp object to calibrate the touch screen as this will
damage the panel.
1. Touch the Calibrate icon and the first screen will appear with instructions.
2. Follow the instructions on the screen touching and o entaril holding
finger or a st lus to the center of the target for 2 seconds. Repeat as the target
oves to each corner of the screen and finall to the center.
3. The second screen will appear:
4. If the screen is touched, the new calibration para eters will be accepted. If
the screen is not touched within thirt seconds, the new para eters will be
disregarded.
24
Calibration Screen
Calibration Screen Confirmation
