Owner's Manual
DEST
NAV
PWR-VOL
A / V
INPUT
What's in the Box
ADVUV630 Head Unit
External Microphone
Parking Brake Wire
Hardware Bag
Speaker Output Harness
Power Input Harness
2 x Accessory Harness
Installation Guide
WARNING! Never install this unit where operation and viewing could interfere with safe driving con-
ditions.
®
ADVUV630
Tools and Supplies
You will need these tools and supplies to
install your ADVUV630:
•
Torx type, fl at-head and Philips
screwdrivers
•
Wire cutters and strippers
•
Tools to remove existing radio (screw
driver, socket wrench set or other tools)
•
Electrical tape
•
Crimping tool
•
Volt meter/test light
•
Crimp connections
•
18 gauge wire for power connections
•
16 – 18 gauge speaker wire
1
Installation Guide
Advertisement
Related Manuals for Advent ADVUV630
Summary of Contents for Advent ADVUV630
- Page 1 DEST PWR-VOL A / V INPUT What’s in the Box Tools and Supplies You will need these tools and supplies to ADVUV630 Head Unit install your ADVUV630: External Microphone • Torx type, fl at-head and Philips Parking Brake Wire screwdrivers Hardware Bag •...
-
Page 2: Replacing The Fuse
To prevent a short circuit, be sure to turn off the ignition and remove the negative (-) battery cable prior to in- stallation. NOTE: If the ADVUV630 is to be installed in a car equipped with an on-board drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. Under these conditions, use extra caution during installation to avoid causing a short circuit.
