ADVUNI300
6.2" Double DIN Multimedia Receiver
DVD / NAV / SiriusXM-Ready®/ Built-in Bluetooth / Pandora
Compatible with iPhone / Compatible with iPod / USB / Aux In

INSTALLATION GUIDE

What's in the Box
The following items are supplied with
the ADVUNI300:
•
ADVUNI300 Head Unit
•
Trim Ring
•
Hardware Bag
•
Power/Speaker Output Harness
•
Remote Control
•
External Microphone
•
GPS Antenna
•
Owners Manual & Warranty Card
•
Installation Guide
WARNING! Never install this unit where operation and viewing could interfere with
safe driving conditions.
Tools and Supplies
The following tools and supplies are
needed to install the ADVUNI300:
at-head and Philips
screwdrivers
Wire cutters and strippers
Tools to remove existing radio (screw
driver, socket wrench set or other
tools)
Electrical tape
Crimping tool
Volt meter/test light
Crimp connections
18 gauge wire for power connections
16 – 18 gauge speaker wire
