User's Manual

RS232 Port

PTZ cameras can be connected to the RS232 port. See Chapter 3
and the PTZ camera manufacturer's manual for configuring the RS232 connection.
Connector Pin Outs:
NOTE: Refer to the following for pin-out details for the 9-pin connector of the slave unit.
Female
Male

Power Cord Connector

Connect the connector from the adaptor to the DVR, and connect the AC power cord
to the adaptor and then to the wall outlet.
WARNING: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD.
MAKE CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY
FURNITURE. DO NOT INSTALL POWER CORDS UNDER RUGS OR CARPET.
THE POWER CORD HAS A GROUNDING PIN. IF YOUR POWER OUTLET DOES NOT
HAVE A GROUNDING PIN RECEPTACLE, DO NOT MODIFY THE PLUG. DO NOT
OVERLOAD THE CIRCUIT BY PLUGGING TOO MANY DEVICES IN TO ONE CIRCUIT .
CAUTION: Ensure the DVR is not near any heat source that could cause overheating.
CAUTION: The DVR does not have an internal fan so leave a clearance of at least 6
inches near ventilation hole areas on each side panel of the unit for proper ventilation.
Your DVR is now ready to operate. Refer to Chapter 3
6
Master Unit
RX To
TX To
GND To
Pin 2 RXD (Receive Data)
Pin 3
TXD (Transmit Data)
Pin 5 GND (Ground)
Slave Unit
TXD
RXD
GND
Configuration and Chapter 4
Configuration
Operation.
