Configure Relays; Configure Relay #2 And Status #2 Input - Sentex Crown Jewel Programming Manual

Configure Relays

A relay is a device that reacts to an electric current to activate other devices. Allowing the Crown Jewel to lock or unlock a
gate, shut (bypass) alarm contacts, signal an alarm, or turn on a camera wired to a closed-circuit television (CCTV). The
relays can be programmed to 5 different modes.
MODES OF OPERATION
Strike Relay: A Strike Relay controls a door or gate by unlocking or opening it. It does not control any other
component associated with a system like alarms, CCTV, etc.
Shunt Relay: A Shunt Relay is normally wired to an alarm and works with strike relays to shunt (bypass) the alarm
when the door is opened with a valid access code. If the door is forced open, the system will not
shunt the alarm and the alarm will be triggered.
CCTV Relay: A CCTV relay activates the system's optional camera. The camera is wired to a closed-circuit
television (CCTV). A camera can be activated when an alarm condition occurs or when a resident
enters a valid access code.
Alarm Relay: The Alarm Relay will activate another device, such as a siren, when 3 conditions occur: A door is
opened without a valid access code, A door is open past the allotted time programmed in, or too
many invalid codes are tried. Any of these will trigger the alarm relay.
Control Relay: The Control Relay can control another device such as an outdoor or indoor light near the unit. For
example, you can configure the system to run an entry light through a darkened area after a resident
enters a valid access code. Then the light would turn off after a specified amount of time.

Configure Relay #2 and Status #2 Input - 26

Relay #2 can be configured as a Strike, Shunt, CCTV, Alarm or Control Relay. The Status 2 input can be used as an exit
request for the second gate or sensor to detect the closed position of the main gate/door.
FACTORY SETTING: 0 (Relay 2 = Control Type; Status 2 = Exit Request.)
NOTE: Relay #1 is configured as a Control Relay and cannot be changed.
1. Press
2. Enter Configuration Number:
O = Relay #2 = Control Type; Status 2 = Exit Request 2
(During a visitor call, Relay #2 will activate when the #5 is press from the resident phone,
or the relay will activate when the Exit Request Device has been activated.)
1 = Relay #2 = Shunt Type; Status 2 = Position Sense 1
(Relay #2 will activate whenever Relay #1 activates to bypass an alarm sensor.)
2 = Relay #2 = Alarm Type; Status 2 = Position Sense 1
(Relay #2 will activate upon an Alarm Condition.)
3 = Relay #2 = CCTV Type; Status 2 = Position Sense 1; Video On = Manual
(Closed-circuit TV will activate when the #5 is pressed from the resident phone,
however, the visitor call will not terminate until access is granted "#9" or call is terminated " ".
4 = Relay #2 = CCTV Type; Status 2 = Position Sense 1; Video On = Immediate
(Closed-circuit TV will activate when any key is press on the main keypad.)
5 = Relay #2 = Control Type; Status 2 = Position Sense 1
(During a visitor call, Relay #2 will ONLY activate when the "#5" is press from the
resident phone.)
3. Press to save the data
EXAMPLE:
1
Sets Relay #2 as an Alarm Type and Status 2 for Position Sense 1)
IMPORTANT NOTES: If you make an error during an entry, press the asterisk key ( ✱ ) to begin again.
The pound key (#) MUST be used to SAVE the data at the end of each programming step.
Time MUST be entered using a 24-Hour format (8:00 AM = 0800, 3:00 PM = 1500 etc.)
2 Short Beeps: Programming input is valid 1 Long Beep: Input is not valid.
2 3
PAGE 7
