➤ Tach threshold On/Off
In most cases, this jumper can be left in the Off position. Some new vehicles use
less than 12 volts in their ignition systems. The unit may have trouble learning the
tach signal in these vehicles. Changing the jumper to the On setting changes
the trigger threshold of the digital tach circuit so that it will work with these type
vehicles.
D2D Jumper settings
The security system has the ability to work with a compatible module through
the D2D lines. There are two settings: one for using an internal docking module,
(p/n 400N) or an external module.
Jumpers
Jumper settings when using
an onboard D-2-D module
Jumper settings when using
an external D-2-D module
Jumpers
34
© 2008 Directed Electronics. All rights reserved.
