There are three harness connections relative to remote start function, including
the heavy gauge and input and output harnesses.

➤ Heavy gauge remote start, (H3) 8-pin connector

H3/1
PINK
H3/2
RED/WHITE
H3/3
ORANGE
H3/4 VIOLET
H3/5 RED
H3/6 PINK/WHITE
H3/7 PINK/BLACK
H3/8 RED/BLACK

➤ Remote start input, 5-pin connector

1
BLACK/WHITE
2 VIOLET/WHITE
3 BROWN
4 GRAY
5 BLUE/WHITE
12
IGNITION 1 INPUT/OUTPUT
(+) FUSED (30A) IGNITION 2 / FLEX RELAY INPUT 87
ACCESSORY OUTPUT
STARTER OUTPUT
(+) FUSED (30A) IGNITION 1 INPUT
IGNITION 2 / FLEX RELAY OUTPUT 30
FLEX RELAY INPUT 87A key side (if required) of FLEX
RELAY
(+) FUSED (30A) ACCESSORY/STARTER INPUT
(-) NEUTRAL SAFETY SWITCH INPUT
TACHOMETER INPUT
(+) BRAKE SHUTDOWN INPUT
N/O or N/C (-) HOOD PIN SWITCH INPUT
(-) 200 mA 2ND STATUS/REAR DEFOGGER OUTPUT
