➤ Remote start auxiliary output, 5-pin

1 PINK/WHITE
2 ORANGE
3 VIOLET
4 PINK
5 BLUE
Note: Wires 1 - 4 on the remote auxiliary outputs are wired to the (-) triggers for
the onboard remote start relays and are not diode isolated. If connecting these
wires directly to the vehicle you must place a 1-amp diode in line to prevent
feedback from the vehicle.

➤ Door lock harness, 3-pin connector

1
BLUE
2
EMPTY
3 GREEN
© 2008 Directed Electronics. All rights reserved.
(-) 200mA FLEX RELAY CONTROL OUTPUT
(-) 200mA ACCESSORY OUTPUT
(-) 200mA STARTER OUTPUT
(-) 200mA IGNITION 1 OUTPUT
(-) 200mA STATUS OUTPUT
(+) LOCK (-) UNLOCK OUTPUT
NOT USED
(-) LOCK (+) UNLOCK OUTPUT
