  • Page 1 Model 103T Owner's Guide...

  • Page 2: Limited Lifetime Consumer Warranty

    This warranty contains the entire agreement relating to warranty and supersedes all previous and contemporaneous representations or understandings, whether written or oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS CONTENTS. This warranty is void if the product has been damaged by accident, unreasonable use, neglect, improper service or other causes not arising out of defects in materials or construction.
  • Page 3 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD- ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM- MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU- SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.

  • Page 4: Table Of Contents

    Table of Contents Limited Lifetime Consumer Warranty What Is Included ..........2 Important Information .

  • Page 5: What Is Included

    What Is Included 103T Control Module 103T Keypad (see diagram below) with 4-Pin Keypad Harness 8618 Failsafe Starter Kill Relay 5-Pin Main Harness 2-Pin LED Interface Harness 3-Pin Data Interface Harness 2000 Directed Electronics, Inc. ©...

  • Page 6: Important Information

    Simply enter coded key sequences to control the starter kill func- tions. The 103T can also be used as a serial controller for any of DEI’s ESP systems. The ESP system LED can be plugged into the 103T’s key- pad port, so that the LED on the keypad functions as the main sys- tem LED.

  • Page 7: System Features

    System Features Keypad Illumination Pressing any button will illuminate the keypad. The illumination will time out 5 seconds after the last key is pressed. PIN Code Security A personalized PIN code must be established to operate the various functions of the 103T. A PIN code can range from 1 to 10 digits.

  • Page 8: Operation As A Stand-Alone Starter Kill

    Within 5 seconds, enter the new PIN code followed The LED will flash twice. Within 5 seconds, enter the new PIN code again followed by . The LED will light solidly for 1 second. The new PIN code has been programmed. The programming mode is exited if the ignition is turned off or if there is no activity for more than 5 seconds.

  • Page 9: Disarming

    Disarming The system may be disarmed whether the ignition is on or off. To disarm the system: Enter your personalized PIN code followed by pad is now disarmed. If the ignition is off, the unit will disarm, but the LED will flash rapidly to indicate that the system will rearm in 15 seconds.

  • Page 10: Panic Mode (Optional)

    Panic Mode (optional) If you are threatened in your vehicle, you can enter Panic Mode to attract attention. Panic Mode will trigger the system and honk the horn (if connected) for 30 seconds. The starter kill and state of the system (armed or disarmed) are not affected by the Panic Mode trigger sequence.

  • Page 11: Operation As An Esp Interface

    Operation as an ESP Interface When using the 103T as a serial interface for a DEI ESP security system, the 103T keypad can be used to control the ESP system’s basic functions, such as panic, Valet Mode and emergency override.

  • Page 12: Panic Mode

    If an error is made during the PIN code entry, simply press to cancel and start over. If the PIN code is not entered correctly after three tries, your system’s trigger sequence will begin. Panic Mode To enter Panic Mode from the keypad: Press Press (labeled PANIC on the keypad).

  • Page 13: Arming With Entry Delay

    Arming With Entry Delay NOTE: This feature may not currently be available with your ESP system. Please consult the Security and Convenience Expansions section of your ESP model owner’s guide to determine if this feature is compatible with your system. To arm your ESP system with a 15-second entry and exit delay: 1.

  • Page 14: Quick Reference Guide (Removable)

    2. Press (labeled on the keypad). NOTE: When using the 103T as a serial interface for a DEI ESP system, this feature may not currently be available. Please consult the Security and Convenience Expansions section of your ESP model owner’s guide to determine if this feature is compatible with your system.
  • Page 15 The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world.
