Device overview
4.3 Bluetooth Module Overview
Position Description
A
"MODE" rotary switch
B
"NetID" rotary switch
Bluetooth LED (blue)
C
D
Connection display (not used)
4.3.1 Bluetooth Module LED Overview
Status
Bluetooth LED (blue)
glows
Off
4.4 Overview of the LEDs on the Network Connection
Position LED
A
Speed
B
Link / Activity On
16
SWebBox20-IEN110711
Meaning
Bluetooth is switched on.
Bluetooth is switched off.
Condition
On
Off
Flashing
Off
Meaning
100 MBit connection speed
10 MBit connection speed
Connection (link) established
The Sunny WebBox is currently transmitting or
receiving data (activity).
No connection established
SMA Solar Technology AG
Installation Guide
