TECHNICAL& SERVICE MANUAL
AWR508CL
AWR509CL
AFR509CL
AWR512CL
FCR512CL
SPLIT SYSTEM AIR CONDITIONER
Indoor Unit
AWR508CL
AWR509CL
AWR512CL
FCR512CL
Floor-Mounted
Ceiling-Mounted
+
AER508SCLA
+
AER509SCLA
+
AER509SCLA
+
AER512SCLA
+
AER512SCLA
0.8180.169.0
Outdoor Unit
02/2001
AER508SCLA
AER509SCLA
AER512SCLA
AFR509CL
