Page 1 PACKAGE DCI R32 CASSETTE UNITS USER and INSTALLATION MANUAL OUTDOOR UNITS INDOOR UNITS AEG ECO 35PIH ASG ECO 35PH AEG ECO 50PIH ASG ECO 50PH AEG ECO 70PIH ASG ECO 70PH AEG ECO 85PIH ASG ECO 85PH AEG ECO 100PIH...
Page 2 To Users Thank you for selecting Argo product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and...
Page 3 2 Malfunction status (specify the situations before and after the error occurs). All the illustrations and information in the instruction manual are only for reference. In order to make the product better, we will continuously conduct improvement and innovation. We have the right to make necessary revision to the product from time to time due to the reason of sales or production, and reserve the right to revise the contents without further notice.
Page 4: Table Of Contents
Contents 1 Safety Notices (Please be sure to abide) ......1 2 Product Introduction ............. 5 2.1 Overall Layout ................5 2.2 Product Operating Range ............6 2.3 Standard Accessories .............6 3 Installation ................7 3.1 Installation Preparation ............7 3.2 Unit Installation ..............18 3.3 Electrical Installation ............
Page 5: Safety Notices (Please Be Sure To Abide)
DC Inverter Package R32 Cassette Type Unit 1 Safety Notices (Please be sure to abide) SPECIAL WARNING: Be sure to comply with national gas regulations. Do not pierce or burn. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
Page 6 DC Inverter U-match Series Cassette Type Unit Before installing the air conditioner, please read the instruction manual. Before repairing the air conditioner, please read the instruction manual. The figures in this manual may be different with the material objects, please refer to the material objects for reference. PROHIBITED (1) The air conditioner should be grounded to avoid electric shock.
Page 7 DC Inverter Package R32 Cassette Type Unit (6) Air conditioner should be stored with protective measures against mechanical damage caused by accident. (7) If the installation space for air conditioner pipe is too small, adopt a protective measure to prevent the pipe from physical damage. (8) During installation, use the specialized accessories and components, otherwise water leakage, electric shock or fire hazard may occur.
Page 8 DC Inverter Package R32 Cassette Type Unit NOTICE (1) Do not put a finger or other objects into the air inlet or air return grill. (2) Please adopt safety protection measures before touching the refrigerant pipe, otherwise your hands may be hurt. (3) Please arrange the drain pipe according to the instruction manual.
Page 9: Product Introduction
DC Inverter Package R32 Cassette Type Unit 2 Product Introduction 2.1 Overall Layout...
Page 10: Product Operating Range
DC Inverter Package R32 Cassette Type Unit 2.2 Product Operating Range Cooling DB Heating DB Outdoor temperature Indoor temperature 2.3 Standard Accessories Indoor Unit Accessories Name Appearance Q'ty Usage To connect with the Drain Hose hard PVC drain pipe To fix the hook on the Nut with Washer cabinet of the unit.
Page 11: Installation
DC Inverter Package R32 Cassette Type Unit Outdoor Unit Accessories Name Appearance Q'ty Usage To plug the unused Drain Plug 1or3 drain hole. To connect with the hard Drainage Connecter PVC drain pipe 3 Installation 3.1 Installation Preparation 3.1.1 Notice on Installation (1) Notice on Refrigerant Concentration before Installation.
Page 12 DC Inverter Package R32 Cassette Type Unit Ceiling type Wall mounted type Floor standing type Area Area Area Weight(kg) Weight(kg) Weight(kg) 2.07 3.09 27.8 2.55 3.81 34.3 3.09 4.61 41.5 3.68 5.49 49.4 4.31 6.44 58.0 5.00 7.47 67.3 5.74 8.58 77.2 6.54...
Page 13 DC Inverter Package R32 Cassette Type Unit charging, keep the refrigerant tank in an upright position. After charging, stick a label on the air conditioner saying no excessive charging. (4) The following tools will be used: 1) Liquid-level gauge; 2) Screwdriver; 3) Electric driven rotary hammer;...
Page 14 DC Inverter Package R32 Cassette Type Unit the following condition). (1) Noise and air flow produced by the outdoor unit will not disturb the neighbors. (2) Select a location that is safe and away from animals and plants. If not, please add safety fences to protect the unit.
Page 15 DC Inverter Package R32 Cassette Type Unit (1) Indoor unit Drain Pipe D (Suspension bolt pitch) Liquid Pipe C (Indoor unit) Gas Pipe B (Ceiling) A(Decoration panel) NOTICE Drilling of ceiling opening and installation of air conditioner must be performed by professionals! Unit: mm Dimensions...
Page 16 DC Inverter Package R32 Cassette Type Unit (2) Outdoor unit 35-70-85 100-140...
Page 17 DC Inverter Package R32 Cassette Type Unit Unit: mm Dimensions Model 1002 1345...
Page 18 DC Inverter Package R32 Cassette Type Unit 3.1.4 Diagram of Unit Installation Space and Location (1) Diagram of installation space and location for outdoor unit (Notice: for best performance of the outdoor unit, make sure its installation space conforms to the following installation dimensions).
Page 19 DC Inverter Package R32 Cassette Type Unit 2) When two or more outdoor units are to be installed side by side, (mm) A,B,C — 1000 A,B,C,E — 1000 1000 2000 — — 2000 1000 HB< HD > H 2000 1/2 H 2000 1/2 H H 2500...
Page 20 DC Inverter U-match Series Cassette Type Unit 3) When outdoor units are installed in rows, 2000 ≥400 ≥400 B(mm) 1/2 H b 250 1/2 H H b 300 Prohibited...
Page 21 DC Inverter Package R32 s Cassette Type Unit 4) When outdoor units are installed one above another. 2000 (2) Diagram of installation location and space for indoor unit (Notice: for the best performance of indoor unit, make sure its installation space conforms to the following installation dimensions).
Page 22: Unit Installation
DC Inverter Package R32 Cassette Type Unit Model H(mm) 3.2 Unit Installation 3.2.1 Indoor Unit Installation In order to make the front panel cover 20mm of the ceiling, the distance between the ceiling and the unit should be 35mm or less. If the distance between the ceiling and the unit is above 35mm, add some ceiling material to shorten the distance.
Page 23 DC Inverter Package R32 Cassette Type Unit (2) Installing the Main Body Unit. 1) Install the hoisting stand on the hoisting screw by using nuts and gaskets at both the upper and lower sides of the hoisting stand. To prevent the gasket from breaking off, a gasket anchor board can be helpful.
Page 24 DC Inverter Package R32 Cassette Type Unit 3.2.2 Outdoor Unit Installation (1) If the outdoor unit is installed on a solid ground such as concrete, use M10 screw bolts and nuts to secure the unit and make sure the unit stands erect and level.
Page 25 DC Inverter Package R32 Cassette Type Unit Installation method: Connect the connection pipes first to the indoor unit and then to the outdoor unit. When bending a connection pipe, be careful not to damage the pipe. Do not over-tighten the screw nut, otherwise leakage will occur. Besides, the outside of connection pipe should be added with a layer of insulating cotton to protect it from mechanical damage during installation, maintenance and transportation.
Page 26 DC Inverter Package R32 Cassette Type Unit Connection pipe should adopt water-proof insulating material. Its wall thickness should be 0.5-1.0mm and the pipe wall should be able to withstand 6.0MPa. The longer the connection pipe is, the worse cooling and heating performance it has. When the drop between indoor and outdoor units is larger than 10m, an oil return bend should be added every 6 meters.
Page 27 DC Inverter Package R32 Cassette Type Unit Non-return bend Outdoor unit System gas pipe Oil return bend Install an oil return bend every 6m Indoor unit Dimensions for the making of oil return bend are as follows: B(mm) C(mm) Ф12 Ф16 3.2.3.2 Pipe Flaring (1) Cut the connection pipe with a pipe cutter.
Page 28 DC Inverter Package R32 Cassette Type Unit (4) Check whether the flaring part has cracked. See the following figure. 90°±1° 3.2.3.3 Pipe Bending (1) The pipes are shaped by your hands. Be careful not to collapse them. (2) Do not bend the pipes in an angle more than 90°. (3) When pipes are repeatedly bent or stretched, the material will harden, making it difficult to bend or stretch them any more.
Page 29 DC Inverter U-match Series Cassette Type Unit Check whether gas leakage occurs to the connection pipe and then apply thermal insulation, as shown below. Wind sponge around the joint of gas pipe and heat insulation sheath of gas collecting pipe. Be sure to connect gas pipe after liquid pipe is connected.
Page 30 DC Inverter Package R32 Cassette Type Unit 3.2.3.5 Thermal Insulation of Pipe Joint (Only for Indoor Unit) Stick coupler heat insulation (large and small) to the place where connecting pipes. Coupler heat insulation Reference A (large) on the pipe Front outlet Reference A: Cover this portion with heat insulating material also without fail...
Page 31 DC Inverter Package R32 Cassette Type Unit (1) Remove the caps of the liquid valve, gas valve and also the service port. (2) Connect the hose at the low pressure side of the manifold valve assembly to the service port of the unit’s gas valve, and meanwhile the gas and liquid valves should be kept closed in case of refrigerant leak.
Page 32 DC Inverter Package R32 Cassette Type Unit gauge manifold Pressure gauge (Low-pressure) Pressure gauge (Hi-pressure) Switch (Low-pressure) Switch (Hi-pressure) Connection pipe Connection pipe (to indoor unit) Liquid valve Gas valve Service pipe Hose Service port Hose with the valve pin Vacuum pump Notice: For large-size units, there are maintenance ports for liquid valve and gas valve.
Page 33 DC Inverter Package R32Cassette Type Unit 3.2.5 Refrigerant Adding NOTICE Before and during operation, use an appropriate refrigerant leak detector to monitor the operation area and make sure the technicians can be well aware of any potential or actual leakage of inflammable gas. Make sure the leak detecting device is applicable to inflammable refrigerant.
Page 34 DC Inverter Package R32 Cassette Type Unit (5) In order to make sure the drain hose is straight, the hangers should keep a distance of 1~1.5m from one another. 1-1.5m √ Correct 1/100 or more gradient x (wrong) (6) Use the drain hose that is delivered together with the unit. (7) Insert the drain hose into the drain faucet.
Page 35 DC Inverter Package R32 Cassette Type Unit 1) Drain hose should be placed on the ground and its end should not be immersed into water. The whole pipeline should be supported and fixed onto the wall. 2) Wind the insulating tape from bottom to top. 3) The whole pipeline should be wound with insulating tape and fixed onto the wall with saddles.
Page 36 DC Inverter Package R32 Cassette Type Unit 3.2.6.3 Notice on Drain Lift Pipe (1) The drain lift pipe should be 1000mm or less away from ground, as shown below. (2) If multiple drain pipes are to be converged, please install according to the following process.
Page 37 DC Inverter Package R32 Cassette Type Unit 3) Install horizontal pipe as shown in the right figure. 3-way connection of Connection of drain elbow Drainage pipe joint Connection of horizontal pipe 3.2.6.4 Check Drainage After the pipeline work is finished, check whether the drainage can go smoothly.
Page 38 DC Inverter Package R32 Cassette Type Unit (2) See the following diagram for the method of water filling. Drain hose Above 100mm (3-7/8inch) 3.2.7 Installing the Front Panel As shown below, take off the 4 corner covers from the front panel and loose the hexagon screw bolts on the 4 fasteners to the maximum.
Page 39 DC Inverter Package R32 Cassette Type Unit Hook Latch Piping position Swing flap motor Indoor unit Ceiling Indoor unit 5~8mm(1/4~3/8inch) Panel Air outlet Notice Improper screw looseness will lead to the following problem. Gas leakage Gas leakage of ceiling Condensate Water drops After the screws are tightened, if there is still a gap between the ceiling and the decorative front panel, adjust the height of the unit again (as shown below).
Page 40: Electrical Installation
DC Inverter Package R32 Cassette Type Unit After installing the front panel, make sure there’s no gap between the unit and the front panel. Circuit of the decorative front panel. Connect the front panel to the main body through the corresponding slots. Match the slots according to their different size.
Page 41 DC Inverter Package R32 Cassette Type Unit . The electrical installation must be conducted by professionals in compliance with local laws and regulations and the instructions in this manual. Never extend the power cord. The electric circuit must be equipped with a circuit breaker and air switch both with sufficient capacity.
Page 42 DC Inverter Package R32 Cassette Type Unit 3.3.2 Electrical Parameters Min. Circuit Fuse sectional Power supply breaker capacity area of Model capacity power cord V/Ph/Hz 220-240V/50Hz/1ph Indoor unit 3.15 208-230V/60Hz/1ph Min. sectional Circuit breaker Power supply area of power capacity Model cord V/Ph/Hz...
Page 43 DC Inverter Package R32 Cassette Type Unit the working temperature is 40 . If working condition changes, please adjust the specifications according to national standards. . Adopt 2pc of 0.75mm² power cords to be the communication cords between indoor and outdoor units. The maximum length is 100m. Please select a proper length according to local conditions.
Page 44 DC Inverter Package R32 Cassette Type Unit How to connect the connection wire and power cord. Lead the connection wire and power cord through the insulation tube. Then fix the wires with wire clamps (as shown in the following figure). Warning Before working, please check whether the indoor and outdoor units are powered on.
Page 45 DC Inverter Package R32 Cassette Type Unit Wire between indoor and outdoor units. Single-phase unit: 35-50-70-85 Outdoor Unit Indoor Unit Wired Controller Breaker Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz Outdoor Unit Indoor Unit Wired Controller Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz 35 IU + 35 OU 50 IU + 50OU 70 IU + 70 OU Power cord 3×1.5mm²...
Page 46 DC Inverter Package R32 Cassette Type Unit Single-phase unit: 100-140. Outdoor Unit Indoor Unit Wired Controller Breaker Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz Outdoor Unit Indoor Unit Wired Controller Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz 100 UI + 100 OU 1PH 140 IU + 140 OU 1PH Power cord 3×6.0mm²...
Page 47 DC Inverter Package R32 Cassette Type Unit Three-phase unit:100-140-160 3PH Outdoor Unit Indoor Unit Wired Controller Breaker Breaker Power:220-240V~50HZ/208-230V~60Hz Power:380V~415V 3N ~ 50/60Hz Outdoor Unit Indoor Unit Wired Controller Breaker Power:220-240V~ 50Hz/208-230V~60HZ Power:380V~415V 3N ~ 50/60Hz 100 IU + 100 OU 3PH 140 IU + 140 OU 3PH Power cord 5×2.5mm²...
Page 48 DC Inverter Package R32 Cassette Type Unit Electrical wiring of indoor unit and Electrical wiring of outdoor unit. Warning High and low voltage wires should be led through different rubber rings of the electric box cover. Do not bundle up the connection wire and communication wire of wired control or lay them side by side, otherwise errors will occur.
Page 49 DC Inverter Package R32 Cassette Type Unit 2) Outdoor side. Remove the big handle/front panel of the outdoor unit and insert one end of the communication cord and the power cord to the terminal board. Single-phase: 35-50-70-85 Wire routing of separated power supply: Wire routing of unified power supply Single-phase 100-140 Wire routing of separated power supply for single phase.
Page 50 DC Inverter Package R32 Cassette Type Unit The communication wire gets in from the upper hole The power cords of outdoor unit and indoor unit get in from the lower hole. Wire routing of unified power supply for single phase. The communication wire gets in from the upper hole The power cords of outdoor unit and...
Page 51 DC Inverter Package R32 Cassette Type Unit Three-phase: 100-140-160 Wire routing of separated power supply for three phase. Only for 160...
Page 52 DC Inverter Package R32 Cassette Type Unit Wire routing of unified power supply for three-phase. Only for 160 Power cord should be secured along with the right side plate and fixed to the hook with a wire clamp so as to avoid contacting the pipeline. The communication line between indoor and outdoor units should also be laid along with the right side plate but away from the power cord.
Page 53: Check After Installation
DC Inverter Package R32 Cassette Type Unit 3.4 Check after Installation Check Items after Installation Possible events due to improper Check items installation The unit may fall down, vibrate or Is the main body installed securely? produce noise. Cooling capacity may become Did you do water leakage test? unsatisfactory.
Page 54: Operation Specification
DC Inverter Package R32 Cassette Type Unit air conditioner immediately. Wait until the electric heating belt is heated enough, and then restart the air conditioner. (5) Feel the air flow of the indoor unit to see if it is normal. (6) Press the swing button or speed control button on remote control or wired control to see if the fan can run normally.
Page 55: Maintenance
DC Inverter Package R32 Cassette Type Unit 5 Maintenance 5.1 Failures Not Caused by Faults of the AC (1) If your air conditioner fails to function normally, please first check the following items before maintenance: Problem Cause Corrective measure If you turn off the unit and then immediately turn it on, in order to protect the compressor and avoid...
Page 56 DC Inverter Package R32 Cassette Type Unit (2) The following situations are not operation failures. Problem Time of occurrence Cause Mist comes If the unit is running under high from the air During operation. humidity, the wet air in the room conditioner.
Page 57: Error Code
DC Inverter Package R32 Cassette Type Unit Notice: Check the above items and adopt the corresponding corrective measures. If the air conditioner continues to function poorly, please stop the air conditioner immediately and contact Gree’s authorized local service center. Ask our professional service staff to check and repair the unit. 5.2 Error Code Warning If abnormal things (for example, awful smell) occur, please stop the unit...
Page 58 DC Inverter Package R32 Cassette Type Unit Error Number Error code Compressor overload protection Overload IPM protection DC fan error Driver out-of-step protection HC Pfc protection Startup failure Compressor phase-sequence protection Power protection IDU and ODU unmatched 4–way valve switch-over error Driver reset protection Over-current protection Master control and driver communication error...
Page 59: Unit Maintenance
DC Inverter Package R32 Cassette Type Unit code will be simultaneously shown on it. 5.3 Unit Maintenance Warning Only professionals are allowed to carry on daily maintenance. Before contacting any wire, make sure power is cut off. Do not let any inflammable objects near the unit. Do not use organic solvent to clean the air conditioner.
Page 60 DC Inverter Package R32 Cassette Type Unit 5.3.1 Clean Air Filter If the air conditioner is used at a dusty place, clean the air filter regularly. (Once every half a year) How to clean the air filter 1) Open the air intake grill. Push the clasps outward and then open the air intake grill.
Page 61 DC Inverter Package R32 Cassette Type Unit 5.3.2 Clean Air Intake Grill How to clean the air intake grill Same with step 1 in “Clean Air Filter”. 1) Open the air intake grill. 2) Take out the air filter. Same with step 2 in “Clean Air Filter”. 3) Take out the air intake grill.
Page 62: Notice On Maintenance
DC Inverter Package R32 Cassette Type Unit 5.3.5 Notices at the Beginning of the Using Season (1) Check if the air inlet/outlet of indoor/outdoor unit is blocked. (2) Check if the ground connection is reliable. (3) Check if the battery of remote controller is replaced. (4) Check if the air filter screen is properly installed.
Page 63 DC Inverter Package R32 Cassette Type Unit 5.4.1.2 Work Procedure Work shall be undertaken under a controlled procedure so as to minimize the risk of a flammable gas or vapour being present while the work is being performed. 5.4.1.3 General Work Area All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out.
Page 64 DC Inverter Package R32 Cassette Type Unit 5.4.1.7 Ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation s hall continue during the period that the work is carried out.
Page 65 DC Inverter Package R32 Cassette Type Unit used. This shall be reported to the owner of the equipment so all parties are advised. Initial safety checks shall include: (1) That capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking.
Page 66 DC Inverter Package R32 Cassette Type Unit 5.4.3 Repair to Intrinsically Safe Components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use. Intrinsically safe components are the only types that can be worked on while live in the presence of a flammable atmosphere.
Page 67 DC Inverter Package R32 Cassette Type Unit and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system. When the final OFN charge is used, the system shall be vented down to atmospheric pressure to enable work to take place.
Page 68 DC Inverter Package R32 Type Unit (3) Before attempting the procedure ensure that: 1) Mechanical handling equipment is available, if required, for handling refrigerant cylinders; 2) All personal protective equipment is available and being used correctly 3) The recovery process is supervised at all times by a competent person 4) Recovery equipment and cylinders conform to the appropriate standards.
Page 69: After-Sales Services
DC Inverter Package R32 Cassette Type Unit Cylinders shall be complete with pressure relief valve and associated shut-off valves in good working order. Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs. The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants.
Page 70 REGULATION (EU) No. 517/2014 - F-GAS The unit contains R32, a fluorinated greenhouse gas with global warming potential (GWP) = 675. Do not release R32 into the atmosphere. 35PH Kg. 0,78 = 0,53 Tonn CO 2 equiv. 50PH Kg. 1,0 = 0,68 Tonn CO 2 equiv. 70PH Kg.
Page 71 PACKAGE DCI R32 Duct Type Indoor Units User and installation manual Models: Indoor Unit : Outdoor Unit: ADG ECO 35PH AEG ECO 35PIH ADG ECO 50PH AEG ECO 50PIH ADG ECO 70PH ADG ECO 70PHB AEG ECO 70PIH ADG ECO 85PH...
Page 72 To Users Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve expected operating effect, we hereby instruct as below: (1) This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of...
Page 73 necessary revision to the product from time to time due to the reason of sales or production, and reserve the right to revise the contents without further notice. (7) Indoor unit must not be installed in a laundry. (8) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Page 74 Contents 1 Safety Notice (Please be sure to abide) ......1 2 Product Introduction ............5 2.1 Overall Layout ................5 2.2 Operating Range ..............6 2.3 Standard Accessories .............6 3 Installation ................7 3.1 Installation Preparation ............7 3.2 Unit Installation ..............19 3.3 Electrical Installation ............
Page 75: Safety Notice (Please Be Sure To Abide)
DC Inverter Package R32 Duct Type Unit 1 Safety Notice (Please be sure to abide) SPECIAL WARNING: (1) Be sure to comply with national gas regulations. (2) Do not pierce or burn. (3) Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
Page 76 DC Inverter Package R32 Duct Type Unit Before installing the air conditioner, please read the instruction manual. Before repairing the air conditioner, please read the instruction manual. The figures in this manual may be different with the material objects, please refer to the material objects for reference. PROHIBITED! (1) The air conditioner should be grounded to avoid electric shock.
Page 77 DC Inverter Package R32 Duct Type Unit WARNING! (8) During installation, use the specialized accessories and components, otherwise water leakage, electric shock or fire hazard may occur. (9) Please install the air conditioner in a secure place that can withstand the weight of air conditioner.
Page 78 DC Inverter Package R32 Duct Type Unit NOTES! (1) Do not put a finger or other objects into the air inlet or air return grill. (2) Please adopt safety protection measures before touching the refrigerant pipe; otherwise your hands may be hurt. (3) Please arrange the drain pipe according to the instruction manual.
Page 79: Product Introduction
DC Inverter Package R32 Duct Type Unit 2 Product Introduction 2.1 Overall Layout NOTES: The connection pipe, drain pipe, power cord, and duct for this unit should be prepared by the user. The unit is standard equipped with rectangular duct.
Page 80: Operating Range
DC Inverter Package R32 Duct Type Unit 2.2 Operating Range Cooling Heating Outdoor temperature DB(°C) -20~48 -20~24 Indoor temperature DB/WB(°C)(Maximum) 32/23 27/- 2.3 Standard Accessories Indoor Unit Accessories Name Appearance Q'ty Usage Wired To control the indoor unit. Controller Nut with To fix the hook on the cabinet of Washer the unit.
Page 81: Installation
DC Inverter Package R32 Duct Type Unit 3 Installation 3.1 Installation Preparation 3.1.1 Notice on Installation (1) Notice on Refrigerant Concentration before Installation. This air conditioner uses R32 refrigerant. The construction area for installation, operation and storage of the air conditioner must be larger than the minimum construction area.
Page 82 DC Inverter Package R32 Duct Type Unit Ceiling type Wall mounted type Floor standing type Weight(kg) Area (m Weight(kg) Area (m Weight (kg) Area (m 6.54 9.76 87.9 7.38 11.0 99.2 8.27 12.4 9.22 13.8 10.2 15.3 11.3 16.8 12.4 18.5 13.5 20.2...
Page 83 DC Inverter Package R32 Duct Type Unit stick a label on the air conditioner saying no excessive charging. (4) The following tools will be used: 1) Liquid-level gauge; 2) Screwdriver; 3) Electric driven rotary hammer; 4) Drill; 5) Pipe expander; 6) Torque wrench;...
Page 84 DC Inverter Package R32 Duct Type Unit interference or noise (Even at a distance of 1m, a very strong electric wave may still generate noise). Selection of Installation Location for Outdoor Unit (Select a location pursuant to the following condition). (1) Noise and air flow produced by the outdoor unit will not disturb the neighbors.
Page 85 DC Inverter Package R32 Duct Type Unit (1) Indoor unit ADG ECO 35PH,ADG ECO 50PH,ADG ECO 70PH ADG ECO 85 PH,ADG ECO 100PH-T, ADG ECO 140PH, ADG ECO 160PH Gas pipe Liquid pipe Electric Box Drain pipe ADG ECO 70PH, ADG ECO 70PHB, ADG ECO 85PH, ADG ECO 85PHB...
Page 86 DC Inverter Package R32 Duct Type Unit NOTE! Drilling of ceiling opening and installation of air conditioner must be performed by professionals! Unit: mm Dimensions Model ADG ECO 35PH ADG ECO 50PH 1060 1000 1068 ADG ECO 70PH 1360 1300 1368 ADG ECO 85PH ADG ECO 70PHB...
Page 87 DC Inverter Package R32 Duct Type Unit (2) Outdoor unit. AEG ECO 35 PIH, AEG ECO 50PIH, AEG ECO 50PIH, AEG ECO 85PIH. AEG ECO 100PIH, AEG ECO 140PIH, AEG ECO 100PIH3, AEG ECO 140PIH3...
Page 88 DC Inverter Package R32 Duct Type Unit AEG ECO 160PIH3. Unit: mm Dimensions Model AEG ECO 35PH AEG ECO 50PIH AEG ECO 70PIH AEG ECO 85PH 1002 AEG ECO 100PIH — AEG ECO 100PIH3 — AEG ECO 140PIH — AEG ECO 140PIH3 —...
Page 89 DC Inverter Package R32 Duct Type Unit 3.1.4 Diagram of Unit Installation Space and Location (1) Diagram of installation space and location for outdoor unit (Notice: for best performance of the outdoor unit, make sure its installation space conforms to the following installation dimensions). 1) When one outdoor unit is to be installed.
Page 90 DC Inverter Package R32 Duct Type Unit 2) When two or more outdoor units are to be installed side by side. Unit: mm (mm) ≥300 ≥300 ≥1000 A,B,C — — — ≥300 ≥300 ≥1000 ≥1000 A,B,C,E — — ≥2000 — —...
Page 91 DC Inverter Package R32 Duct Type Unit 3) When outdoor units are installed in rows. Unit: mm (mm) ≤1/2H b≥250 b≥300 ≤H 1/2H＜H ＞H Prohibited...
Page 92 DC Inverter Package R32 Duct Type Unit 4) When outdoor units are installed one above another. Unit: mm...
Page 93 DC Inverter Package R32 Duct Type Unit (2) Diagram of installation location and space for indoor unit (Notice: for the best performance of indoor unit, make sure its installation space conforms to the following installation dimensions). Unit: mm 3.2 Unit Installation 3.2.1 Indoor Unit Installation 3.2.1.1 Preparation for Installing the Indoor Unit NOTES!
Page 94 DC Inverter Package R32 Duct Type Unit (3) Install the hanger to the unit. See the following figure. (4) Pass the unit hangers over the bolts installed to the ceiling and install the unit with the special nut. See the following figure. 3.2.1.2 Leveling After installing the indoor unit, level detection of the unit shall be conducted.
Page 95 DC Inverter Package R32 Duct Type Unit 3.2.2 Outdoor Unit Installation (1) If the outdoor unit is installed on a solid ground such as concrete, use M10 screw bolts and nuts to secure the unit and make sure the unit stands erect and level.
Page 96 DC Inverter Package R32 Duct Type Unit 3.2.3 Connection Pipe Installation 3.2.3.1 Installation Notice and Requirement on Connection Pipe NOTES! (1) Indoor unit adopts special joints that can’t be disassembled. The installation method is the same as the unit with ordinary joints. However, because the joints can’t be removed, if the connection is not good and causes leakage, the joints need to be cut and welded again for replacement.
Page 97 DC Inverter Package R32 Duct Type Unit Size of Fitting Maximum Biggest drop between Item Pipe(inch) pipe indoor and outdoor Model length(m) units(m) Liquid pipe Gas pipe ADG ECO 35PH Ф3/8 Ф1/4 ADG ECO 50PH Ф1/2 ADG ECO 70PH ADG ECO 70PHB ADG ECO 85PH ADG ECO 85PHB Ф3/8...
Page 98 DC Inverter Package R32 Duct Type Unit The requirement on the adding of oil return bend is as below: (1) Outdoor unit is beneath the indoor unit. There’s no need to add non-return bend at the lowest or highest position of the vertical pipe, as shown below: (2) Outdoor unit is above the indoor unit.
Page 99 DC Inverter Package R32 Duct Type Unit Dimensions for the making of oil return bend are as follows: A(inch) B(mm) C(mm) Ф3/8 ≥20 ≤150 Ф1/2 ≥26 ≤150 Ф5/8 ≥33 ≤150 3.2.3.2 Pipe Flaring (1) Cut the connection pipe with a pipe cutter. (2) The mouth of connection pipe should face downward.
Page 100 DC Inverter Package R32 Duct Type Unit (2) Do not bend the pipes in an angle more than 90°. (3) If the pipe is repeatedly bent or extended, it will become hard and difficult to be bent or extended. So do not bend or extend the pipe for more than 3 times.
Page 101 DC Inverter Package R32 Duct Type Unit Pipe diameter (inch) Tightening torque (N·m) Ф1/4 15-30 Ф3/8 35-40 Ф1/2 45-50 Ф5/8 60-65 Ф3/4 70-75 Ф7/8 80-85 Screw on the flare nut of the flaring connecting pipe on the outdoor unit valve. The method of screwing the flare nut is the same with that for indoor unit.
Page 102 DC Inverter Package R32 Duct Type Unit 3.2.3.5 Thermal Insulation of Pipe Joint (Only for indoor unit) Stick coupler heat insulation (large and small) to the place where connecting pipes. 3.2.3.6 Sealing of the Knock-off Hole As for the built-in valve model, during the installation process for connection pipe, when the connection pipe is passing through the knock-off hole, conduct sealing with insulated cotton in the knock-off hole of outdoor unit to prevent small animals from entering.
Page 103 DC Inverter Package R32 Duct Type Unit 3.2.4 Connection Pipe Vacuum Pumping and Leak Detection 3.2.4.1 Vacuum Pumping NOTE! Make sure the outlet of vacuum pump is away from fire source and is well-ventilated. (1) Remove the caps of the liquid valve, gas valve and also the service port. (2) Connect the hose at the low pressure side of the manifold valve assembly to the service port of the unit’s gas valve, and meanwhile the gas and liquid valves should be kept closed in case of refrigerant leak.
Page 104 DC Inverter Package R32 Duct Type Unit Then, close the switch fully and then stop the vacuum pump. (6) Wait for 10min to see if the system pressure can remain unchanged. If the pressure increase, there may be leakage. (7) Slightly open the liquid valve and let some refrigerant go to the connection pipe to balance the pressure inside and outside of the connection pipe, so that air will not come into the connection pipe when removing the hose.
Page 105 Unnecessary Additional Item Standard Charge Pipe Refrigerant Amount Model Pipe Length Length for Extra Pipe AEG ECO 35PIH 16 g/m AEG ECO 50PIH AEG ECO 70PIH 25 g/m AEG ECO 85PIH 30 g/m ≤7.0m 5.0m AEG ECO 100PIH 35 g/m...
Page 106 DC Inverter Package R32 Duct Type Unit 3.2.6 Installation of Drain Pipe (1) It is not allowed to connect the condensate drain pipe into waste pipe or other pipelines which are likely to produce corrosive or peculiar smell to prevent the smell from entering indoors or corrupt the unit. (2) It is not allowed to connect the condensate drain pipe into rain pipe to prevent rain water from pouring in and cause property loss or personal injury.
Page 107 DC Inverter Package R32 Duct Type Unit (6) There is a drain port on both the left and right sides. Select the drain port to match the local conditions. See the following figure. (7) When the unit is shipped from the factory, the drain port is defaulted to be the one on the left side (electric box side).
Page 108 DC Inverter Package R32 Duct Type Unit 3.2.6.2 Outdoor Side Drain Pipe If the outdoor unit is underneath the indoor unit, arrange the pipeline according to the following diagram. 1) Drain hose should be placed on the ground and its end should not be immersed into water.
Page 109 DC Inverter Package R32 Duct Type Unit 3.2.6.3 Drain Riser with Pump Unit Considerations (1) For the unit with the condensate pump, only one drain port at the side close to the electric box is prepared and only through it the drain hose can be connected.
Page 110 DC Inverter Package R32 Duct Type Unit The vertical height of the drain hose should be 75mm or less so that it is unnecessary for the drain port to withstand additional force. When multiple drain hoses are used, their installation should be performed as shown in the figure below.
Page 111 DC Inverter Package R32 Duct Type Unit (4) Drain branch should be connected to the vertical or horizontal part of the main drain pipe. (5) Horizontal pipe should not be connected to the vertical pipe that is on the same level. It should be connected in the following way: 1) Attach the 3-way connection of the drainage pipe joint.
Page 112 DC Inverter Package R32 Duct Type Unit 3.2.7 Installation of the Duct 3.2.7.1 Dimensions of the Supply Air Outlet/Return Air Inlet Supply Air Outlet Return Air Inlet Unit: mm Supply Air Outlet Return Air Inlet Item Model ADG ECO 35PH ADG ECO 50PH 1000 ADG ECO 70PH...
Page 113 DC Inverter Package R32 Duct Type Unit Supply Air Outlet Return Air Inlet Item Model ADG ECO 140PH 1360 1150 ADG ECO 160PH 3.2.7.2 Return Air Method (1) The default ex-factory return air method is from the back. The return air cover shall be installed at the bottom of the unit, as is shown in the following figure.
Page 114 DC Inverter Package R32 Duct Type Unit 3.2.7.3 Installation of Supply Air Duct and Return Air Duct Installation method shall be selected by entirely considering the conditions of buildings, maintenance, etc.as is shown in the following figure. Name canvas duct return air duct supply air duct indoor unit...
Page 115 DC Inverter Package R32 Duct Type Unit NOTES: ①. The supply air duct, return air duct and fresh air duct shall have thermal insulation layer to prevent heat leakage and condensation. Stick the plastic nail to the air duct, then attach the heat preservation cotton with tinfoil and fix it with plastic nail cover, finally, seal the connection joint with tinfoil tape tightly;...
Page 116 DC Inverter Package R32 Duct Type Unit ④. The external power cord, connection wire of indoor and outdoor units and the communication cords must be effectively fixed. ⑤. The external power cord, connection wire of indoor and outdoor units and the communication cords can’t directly contact any hot objects.
Page 117 Circuit Min. sectional Power supply breaker area of power Model capacity cord V/Ph/Hz AEG ECO 35PIH AEG ECO 50PIH AEG ECO 70PIH 220-240V ~50Hz AEG ECO 85PIH 208-230V ~60Hz AEG ECO 100PIH AEG ECO 140PIH AEG ECO 100PIH3 AEG ECO 140PIH3...
Page 118 DC Inverter Package R32 Duct Type Unit proper length according to local conditions. Communication cords must not be twisted together. To be in compliance EN 55014, it is necessary to use 8 meters long wire. ⑦. Adopt 2pc of 0.75mm power cords to be the communication cords between wired control and indoor unit.
Page 119 DC Inverter Package R32 Duct Type Unit (3) How to connect the connection wire and power cord. Lead the connection wire and power cord through the insulation tube. Then fix the wires with wire clamps (as shown in the following figure). WARNING! (1) Before working, please check whether the indoor and outdoor units are powered on.
Page 120 DC Inverter Package R32 Duct Type Unit (4) Wire between indoor and outdoor units. Single-phase unit: AEG ECO 35PIH, AEG ECO 50PIH, AEG ECO 70PIH, AEG ECO 85PIH ADG ECO 35PH+AEG ECO 35PIH ADG ECO 50PH+AEG ECO 50PIH ①. Power cords 3×1.5mm ②.
Page 121 DC Inverter Package R32 Duct Type Unit ADG ECO 70PH+AEG ECO 70PIH ADG ECO 70PHB+AEG ECO 70PIH ADG ECO 85PH+AEG ECO 85PIH ADG ECO 85PHB+AEG ECO 85PIH ①. Power cords 3×2.5mm ②. Power cords 3×1.0mm ③. Communication cords 2×0.75mm ④. Communication cords 2×0.75mm Single-phase Unit: AEG ECO 100PIH, AEG ECO 140PIH.
Page 122 DC Inverter Package R32 Duct Type Unit ADG ECO 100PH+AEG ECO 100PIH ①. Power cords 3×4.0mm ②. Power cords 3×1.0mm ③. Communication cords 2×0.75mm ④. Communication cords 2×0.75mm ADG ECO 140PH+AEG ECO 140PIH ①. Power cords 3×6.0mm ②. Power cords 3×1.0mm ③.
Page 123 DC Inverter Package R32 Duct Type Unit Three-phase unit: AEG ECO 100PIH3,AEG ECO 140PIH3. ADG ECO 100PH+AEG ECO 100PIH3 ADG ECO 140PH+AEG ECO140PIH3 ①. Power cords 5×1.5mm ②. Power cords 3×1.0mm ③. Communication cords 2×0.75mm ④. Communication cords 2×0.75mm...
Page 124 DC Inverter Package R32 Duct Type Unit Three-phase unit: AEG ECO 160PIH3 ADG ECO 160PH+AEG ECO 160PIH3 ①. Power cords 5×1.5mm ②. Power cords 3×1.0mm ③. Communication cords 2×0.75mm ④. Communication cords 2×0.75mm...
Page 125 DC Inverter Package R32 Duct Type Unit (5) Electrical wiring of indoor unit and outdoor unit. WARNING! (1) High and low voltage wires should be led through different rubber rings of the electric box cover. (2) Do not bundle up the connection wire and communication wire of wired control or lay them side by side, otherwise errors will occur.
Page 126 Remove the big handle/front panel of the outdoor unit and insert one end of the communication cord and the power cord to the terminal board. Single-phase: AEG ECO 35PIH, AEG ECO 50PIH, AEG ECO 70PIH, AEG ECO 85PIH. A. Wire routing of separated power supply.
Page 127 DC Inverter Package R32 Duct Type Unit B. Wire routing of unified power supply. Single-phase: AEG ECO 100PIH, AEG ECO 140PIH A. Wire routing of separated power supply for single phase.
Page 128 DC Inverter Package R32 Duct Type Unit B. Wire routing of unified power supply for single phase.
Page 129 DC Inverter Package R32 Duct Type Unit Three-phase: AEG ECO 100PIH3, AEG ECO 140PIH, AEG ECO 160PIH3. A. Wire routing of separated power supply for three phase.
Page 130 DC Inverter Package R32 Duct Type Unit Only for AEG ECO 160PIH3:...
Page 131 DC Inverter Package R32 Duct Type Unit B. Wire routing of unified power supply for three-phase.
Page 132 DC Inverter Package R32 Duct Type Unit Only for AEG ECO 160PIH3:...
Page 133 DC Inverter Package R32 Duct Type Unit 3.4 Check after Installation Check Items after Installation. Check items Possible events due to improper installation Is the main body installed The unit may fall down, vibrate or produce securely? noise. Did you do water leakage test? Cooling capacity may become unsatisfactory.
Page 134 DC Inverter Package R32 Duct Type Unit (4) If there’s sound of liquid shock when the compressor is running, then stop the air conditioner immediately. Wait until the electric heating belt is heated enough, and then restart the air conditioner. (5) Feel the air flow of the indoor unit to see if it is normal.
Page 135 DC Inverter Package R32 Duct Type Unit 5 Maintenance 5.1 Failures Not Caused by Faults of the AC (1) If your air conditioner fails to function normally, please first check the following items before maintenance: Problem Cause Corrective measure If you turn off the unit and then immediately turn it on, in order to protect the compressor and Please wait for a while.
Page 136 DC Inverter Package R32 Duct Type Unit (2) The following situations are not operation failures. Problem Time of occurrence Cause If the unit is running under Mist comes from high humidity, the wet air in During operation. the air conditioner. the room will be quickly cooled down.
Page 137 DC Inverter Package R32 Duct Type Unit NOTE: Check the above items and adopt the corresponding corrective measures. If the air conditioner continues to function poorly, please stop the air conditioner immediately and contact ArgoClima authorized local service center. Ask our professional service staff to check and repair the unit. 5.2 Error Code WARNING! (1) If abnormal things (for example, awful smell) occur, please stop the unit...
Page 138 DC Inverter Package R32 Duct Type Unit Number Error code Error ODU memory chip error Electric box sensor error Compressor overload protection Overload IPM protection DC fan error Driver out-of-step protection Pfc protection Startup failure Compressor phase-sequence protection Power protection IDU and ODU unmatched 4–way valve switch-over error Driver reset protection...
Page 139 DC Inverter Package R32 Duct Type Unit Number Error code Error ODU jumper cap error Phase-loss and anti-phase protection ODU error, for specific error please see the status of ODU indicator Emergency Stop(Fire alarm) NOTE: When the unit is connected with the wired controller, the error code will be simultaneously shown on it.
Page 140 DC Inverter Package R32 Duct Type Unit 5.3.2 Heat Exchanger of Outdoor Unit Conduct cleaning for the heat exchanger of outdoor unit periodically, clean it once at least in every two months. Clean the dust and sundries on the surface of the heat exchanger with dust collector and nylon brush, if there’s compressed air source;...
Page 141 DC Inverter Package R32 Duct Type Unit 5.4 Notice on Maintenance 5.4.1 Information on Servicing The manual shall contain specific information for service personnel who shall be instructed to undertake the following when servicing an appliance that employs a flammable refrigerant. 5.4.1.1 Checks to the Area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimized.
Page 142 DC Inverter Package R32 Duct Type Unit explosion. All possible ignition sources, including cigarette smoking, should be kept sufficiently far away from the site of installation, repairing, removing and disposal, during which flammable refrigerant can possibly be released to the surrounding space.
Page 143 DC Inverter Package R32 Duct Type Unit 5.4.1.9 Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with.
Page 144 DC Inverter Package R32 Duct Type Unit 5.4.3 Repair to Intrinsically Safe Components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use. Intrinsically safe components are the only types that can be worked on while live in the presence of a flammable atmosphere.
Page 145 DC Inverter Package R32 Duct Type Unit this task. Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system.
Page 146 DC Inverter Package R32 Duct Type Unit (2) Isolate system electrically. (3) Before attempting the procedure ensure that: 1) Mechanical handling equipment is available, if required, for handling refrigerant cylinders. 2) All personal protective equipment is available and being used correctly.
Page 147 DC Inverter U-match Series Duct Type Unit 5.4.10 Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed.
Page 148 REGULATION (EU) No. 517/2014 - F-GAS The unit contains R32, a fluorinated greenhouse gas with global warming potential (GWP) = 675. Do not release R32 into the atmosphere. AEG ECO 35PIH Kg. 0,78 = 0,53 Tonn CO 2 equiv. AEG ECO 50PIH Kg.
Page 149 PACKAGE DCI R32 FLOOR CEILING UNITS USER and INSTALLATION MANUAL INDOOR UNITS OUTDOOR UNITS ACG ECO 70PH AEG ECO 35PIH ACG ECO 70PH AEG ECO 50PIH ACG ECO 85PH AEG ECO 70PIH ACG ECO 100PH AEG ECO 85PIH ADG ECO 140PH...
Page 150 To Users Thank you for selecting Argo product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product...
Page 151 improvement and innovation. We have the right to make necessary revision to the product from time to time due to the reason of sales or production, and reserve the right to revise the contents without further notice. (7) Indoor unit must not be installed in a laundry. (8) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Page 152 Contents 1 Safety Notices (Please be sure to abide) ........ 1 2 Product Introduction ..............5 2.1 Overall Layout ................. 5 2.2 Product Operating Range.............. 6 2.3 Standard Accessories ..............6 3 Installation ..................7 3.1 Installation Preparation ..............7 3.2 Unit Installation................
Page 153: Safety Notices (Please Be Sure To Abide)
DC Inverter Package R32 Floor Ceiling Type Unit 1 Safety Notices (Please be sure to abide) SPECIAL WARNING: Be sure to comply with national gas regulations. Do not pierce or burn. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
Page 154 DC Inverter Package R32 Floor Ceiling Type Unit Before installing the air conditioner, please read the instruction manual. Before repairing the air conditioner, please read the instruction manual. The figures in this manual may be different with the material objects, please refer to the material objects for reference.
Page 155 DC Inverter Package R32 Floor Ceiling Type Unit WARNING (8) During installation, use the specialized accessories and components, otherwise water leakage, electric shock or fire hazard may occur. (9) Please install the air conditioner in a secure place that can withstand the weight of air conditioner.
Page 156 DC Inverter Package R32 Floor Ceiling Type Unit NOTICE (6) Indoor unit can only be installed indoors while outdoor unit can be installed either indoors or outdoors. Never install the air conditioner in the following places: a) Places with oil smoke or volatile liquid: plastic parts may deteriorate and fall off or even cause water leakage.
Page 157: Product Introduction
DC Inverter Package R32 Floor Ceiling Type Unit 2 Product Introduction 2.1 Overall Layout...
Page 158: Product Operating Range
DC Inverter Package R32 Floor Ceiling Type Unit 2.2 Product Operating Range Cooling Heating Outdoor temperature DB(℃) -20〜48 -20〜24 Indoor temperature DB/WB(℃) 32/23 27/- （Maximum） 2.3 Standard Accessories Indoor Unit Accessories Name Appearance Q'ty Usage To fix the hook on the Nut with Washer cabinet of the unit.
Page 159: Installation Preparation
DC Inverter Package R32 Floor Ceiling Type Unit 3 Installation 3.1 Installation Preparation 3.1.1 Notice on Installation (1) Notice on Refrigerant Concentration before Installation. This air conditioner uses R32 refrigerant. The construction area for installation, operation and storage of the air conditioner must be larger than the minimum construction area.
Page 160 DC Inverter Package R32 Floor Ceiling Type Unit Ceiling type Wall mounted type Floor standing type Area Area Area Weight(kg) Weight(kg) Weight(kg) 10.2 15.3 11.3 16.8 12.4 18.5 13.5 20.2 14.7 22.0 16.0 23.8 17.3 25.8 18.6 27.8 20.0 29.9 21.5 32.1 23.0...
Page 161 DC Inverter Package R32 Floor Ceiling Type Unit 3.1.2 Selection of Installation Location WARNING If the outdoor unit will be exposed in strong wind, it must be securely located, ①. otherwise it may fall down. Install the air conditioner at a place where the inclination is less than 5°. ②.
Page 162 DC Inverter Package R32 Floor Ceiling Type Unit (4) The installation location should be able to withstand the weight and vibration of outdoor unit and allow the installation to be carried out safely. (5) Avoid installing at a place with leakage of inflammable gas, oil smoke or corrosive gas.
Page 163 DC Inverter Package R32 Floor Ceiling Type Unit NOTICE Drilling of ceiling opening and installation of air conditioner must be performed by professionals! Unit：mm Dimensions Model 1200 1142 1200 1142 1200 1142 1570 1512 1570 1512 1570 1512 (2) Outdoor Unit 35-50-70-85...
Page 164 DC Inverter Package R32 Floor Ceiling Type Unit 100-140...
Page 165 DC Inverter U-match Series Floor Ceiling Type Unit Unit: mm Dimensions Model 1002 100 1PH 100 3PH 140 1PH 140 3PH 160 3PH 1345 3.1.4 Diagram of Unit Installation Space and Location (1) Diagram of installation space and location for outdoor unit (Notice: for best performance of the outdoor unit, make sure its installation space conforms to the following installation dimensions).
Page 166 DC Inverter U-match Series Floor Ceiling Type Unit (mm) — ≥100 A,B,C, — ≥300 ≥100 ≥100 — ≥100 ≥1000 A,B,C,E — ≥300 ≥150 ≥150 ≥1000 — ≥1000 — ≥1000 ≥1000 > H ＜H ≥100 ≥1000 < H ＞H ≥100 ≥1000 ≤1/2 H ≥250 ≥2000...
Page 167 DC Inverter Package R32 Floor Ceiling Type Unit (mm) A,B,C — ≥300 ≥300 ≥1000 A,B,C,E — ≥300 ≥300 ≥1000 ≥1000 — ≥2000 — ≥2000 ≥1000 ＜H ＞H ≥300 ≥2000 ≤1/2 H ≥250 ≥2000 ＞H 1/2 H＜H ≤H ≥300 ≥2500 ≤1/2 H ≥300 ≥2000 ≥1000 ＜H...
Page 168 DC Inverter Package R32 Floor Ceiling Type Unit B(mm) ≤1/2 H b≥250 1/2 H＜H b≥300 ≤H Prohibited ＞H 4) When outdoor units are installed one above another. Unit: mm (2) Diagram of installation location and space for indoor unit (Notice: for the best performance of indoor unit, make sure its installation space conforms to the following installation dimensions).
Page 169: Unit Installation
DC Inverter Package R32 Floor Ceiling Type Unit Unit: mm Floor type Ceiling type 4) Install the unit where the drain pipe can be easily installed. 5) The space from the unit to the ceiling should be kept as much as possible so as for more convenient service.
Page 170 DC Inverter Package R32 Floor Ceiling Type Unit 3.2.1.2 Indoor Unit Installation (1) Determine the location of the hanger through the paper template, and then remove the paper template. (2) Insert the anchor bolts into the drilled holes, and drive the pins completely into the anchor bolts with a hammer.
Page 171 DC Inverter Package R32 Floor Ceiling Type Unit Ceiling type Unit: mm Hanger Left side panel Right side panel (6) Adjust the height of the unit to make the drain pipe slant slightly downward so that the drainage will become much smoother. 3.2.1.3 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below.
Page 172 DC Inverter Package R32 Floor Ceiling Type Unit 3.2.2 Outdoor Unit Installation (1) If the outdoor unit is installed on a solid ground such as concrete, use M10 screw bolts and nuts to secure the unit and make sure the unit stands erect and level.
Page 173 DC Inverter Package R32 Floor Ceiling Type Unit Installation method: Connect the connection pipes first to the indoor unit and then to the outdoor unit. When bending a connection pipe, be careful not to damage the pipe. Do not over-tighten the screw nut, otherwise leakage will occur. Besides, the outside of connection pipe should be added with a layer of insulating cotton to protect it from mechanical damage during installation, maintenance and transportation.
Page 174 DC Inverter Package R32 Floor Ceiling Type Unit longer the connection pipe is, the worse cooling and heating performance it has. When the drop between indoor and outdoor units is larger than 10m, an oil return bend should be added every 6 meters. The requirement on the adding of oil return bend is as below: (1) Outdoor unit is beneath the indoor unit.
Page 175 DC Inverter Package R32 Floor Ceiling Type Unit Dimensions for the making of oil return bend are as follows: B(mm) C(mm) Ф12 ≥26 ≤150 Ф16 ≥33 ≤150 3.2.3.2 Pipe Flaring (1). Cut the connection pipe with a pipe cutter. (2). The mouth of connection pipe should face downward. Remove burrs with the cut surface so that the chips do not enter the pipe.
Page 176 DC Inverter Package R32 Floor Ceiling Type Unit (4). When bending the pipe, do not bend it excessively, otherwise it will get broken. As shown beside, use a sharp cutter to cut the heat insulating pipe and bend it after the pipe is exposed.
Page 177 DC Inverter Package R32 Floor Ceiling Type Unit Pipe diameter (in.) Tightening torque (N·m) 15-30 35-40 45-50 60-65 70-75 80-85 Screw on the flare nut of the flaring connecting pipe on the outdoor unit valve. The method of screwing the flare nut is the same with that for indoor unit. 3.2.3.5 Thermal Insulation of Pipe Joint (Only for Indoor Unit) Stick coupler heat insulation (large and small) to the place where connecting pipes.
Page 178 DC Inverter Package R32 Floor Ceiling Type Unit sealing with insulated cotton in the knock-off hole of outdoor unit to prevent small animals from entering. See the following figure. Notice: Only for the 100 -140 OU 1PH - 3PH 3.2.4 Connection Pipe Vacuum Pumping and Leak Detection 3.2.4.1 Vacuum Pumping NOTICE...
Page 179 DC Inverter Package R32 Floor Ceiling Type Unit And verify if the pressure gauge at the low pressure side of the manifold valve assembly reads -1.0Mp (-75cmHg), if not, it indicates there is leak somewhere. Then, close the switch fully and then stop the vacuum pump. (6) Wait for 10min to see if the system pressure can remain unchanged.
Page 180 DC Inverter Package R32 Floor Ceiling Type Unit Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used. Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant employed and the appropriate percentage of gas (25 % maximum) is confirmed.
Page 181 DC Inverter Package R32 Floor Ceiling Type Unit 3.2.6 Installation of Drain Pipe 3.2.6.1 Indoor Side Drainage Pipe (1) Keep piping as short as possible and slope it downwards at a gradient of at least 1/100 so that air may not remain trapped inside the pipe. (2) Keep pipe size equal to or greater than that of the connecting pipe.
Page 182 DC Inverter Package R32 Floor Ceiling Type Unit Insulate the pipe clamp and the drain Tighten the clamp until the screw hose using heat insulation sponge. head is less than 4 mm from the hose ①. ①. - Metal clamp - Metal clamp ②.
Page 183 DC Inverter Package R32 Floor Ceiling Type Unit 2) Wind the insulating tape from bottom to top. 3) The whole pipeline should be wound with insulating tape and fixed onto the wall with saddles. (2) If the outdoor unit is above the indoor unit, arrange the pipeline according to the following diagram.
Page 184: Electrical Installation
DC Inverter Package R32 Floor Ceiling Type Unit 3.2.6.4 Testing of Drain Piping (1) After piping work is finished, check if drainage flows smoothly. (2) As shown in the figure, pour water into the drain pan from the right side to check that water flows smoothly from the drain hose.
Page 185 DC Inverter Package R32 Floor Ceiling Type Unit Do not draw power from another power circuit. ③. The air conditioner circuit should be at least 1.5m away from any inflammable surface. ④. The external power cord, connection wire of indoor and outdoor units and the communication cords must be effectively fixed.
Page 186 DC Inverter Package R32 Floor Ceiling Type Unit 3.3.2 Electrical Parameters 3.3.2.1 Wire Specifications and Fuse Capacity Circuit Min. sectional Fuse Power supply breaker area of power capacity Model capacity cord V/Ph/Hz Indoor 220-240V 1N~50Hz 3.15 unit 208-230V 1N~60Hz Circuit Min.
Page 187 DC Inverter UPackage R32 Floor Ceiling Type Unit specifications according to national standards. ⑤ Specifications of circuit breaker are based on a working condition where the working temperature is 40℃. If working condition changes, please adjust the specifications according to national standards. ⑥...
Page 188 DC Inverter Package R32 Floor Ceiling Type Unit tighten up the terminal screw (as shown below). How to connect the connection wire and power cord: Lead the connection wire and power cord through the insulation tube. Then fix the wires with wire clamps (as shown in the next figure.) Warning Before working, please check whether the indoor and outdoor units are ①.
Page 189 DC Inverter Package R32 Floor Ceiling Type Unit Wire between indoor and outdoor units. Single-phase unit: 35-50-70-85 Outdoor Unit Indoor Unit L1N1 Wired Controller Breaker Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz Outdoor Unit Indoor Unit Wired Controller Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz 35 IU + 35 OU 50 IU + 50 OU ①...
Page 190 DC Inverter Package R32 Floor Ceiling Type Unit Single-phase unit: 100-140 Outdoor Unit Indoor Unit Wired Controller Breaker Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz Outdoor Unit Indoor Unit Wired Controller Breaker Power:220-240V~50Hz/208-230V~60Hz Power:220-240V~50Hz/208-230V~60Hz 100 IU + 100 OU ① Power cord 3×4.0mm² ② Power cord 3×1.0mm² ③...
Page 191 DC Inverter U-match Series Floor Ceiling Type Unit Three-phase unit: 100-140-160 Outdoor Unit Indoor Unit Wired Controller Breaker Breaker Power:220-240V~50Hz/208-230V~60Hz Power:380-415V 3N ~ 50Hz/60Hz Outdoor Unit Indoor Unit Wired Controller Breaker Power:220-240V~ 50Hz/208-230V~60Hz Power:380-415V 3N ~ 50Hz/60Hz 100 IU + 100 OU 3PH 140 IU + 140 OU 3PH 160 IU + 160 OU 3PH ①...
Page 192 DC Inverter Package R32 Floor Ceiling Type Unit (5) Electrical wiring of indoor unit and Electrical wiring of outdoor unit Warning High and low voltage wires should be led through different rubber rings of the ①. electric box cover. Do not bundle up the connection wire and communication wire of wired control ②.
Page 193 DC Inverter Package R32 Floor Ceiling Type Unit 2）Outdoor side Remove the big handle/front panel of the outdoor unit and insert one end of the communication cord and the power cord to the terminal board. Single-phase: 35-50-70-85 a) Wire routing of separated power supply: b) Wire routing of unified power supply：...
Page 194 DC Inverter Package R32 Floor Ceiling Type Unit b) Wire routing of unified power supply for single phase. The communication wire gets in from the upper hole The power cords of outdoor unit and indoor unit get in from the lower hole. Three-phase: 100-140-160 a) Wire routing of separated power supply for three phase.
Page 195 DC Inverter Package R32 Floor Ceiling Type Unit Only for 160 3PH b) Wire routing of unified power supply for three-phase...
Page 196 DC Inverter Package R32 Floor Ceiling Type Unit Only for 160 3PH Power cord should be secured along with the right side plate and fixed to the hook with a wire clamp so as to avoid contacting the pipeline. The communication line between indoor and outdoor units should also be laid along with the right side plate but away from the power cord.
Page 197: Check After Installation
DC Inverter Package R32 Floor Ceiling Type Unit 3.4 Check after Installation Check Items after Installation Possible events due to improper Check items installation The unit may fall down, vibrate or Is the main body installed securely? produce noise. Cooling capacity become Did you do water leakage test?
Page 198: Operation Specification
DC Inverter Package R32 Floor Ceiling Type Unit (6) Press the swing button or speed control button on remote control or wired control to see if the fan can run normally. NOTICE： ① If you use remote control to turn off the unit and then immediately turn the unit on again, compressor will need 3min to restart.
Page 199: Maintenance
DC Inverter Package R32 Floor Ceiling Type Unit 5 Maintenance 5.1 Failures Not Caused by Faults of the AC (1) If your air conditioner fails to function normally, please first check the following items before maintenance: Problem Cause Corrective measure If you turn off the unit and then immediately turn it on, in order to protect the...
Page 200 DC Inverter Package R32 Floor Ceiling Type Unit (2) The following situations are not operation failures. Problem Time of occurrence Cause Mist comes If the unit is running under high from the air During operation. humidity, the wet air in the room conditioner.
Page 201: Error Code
DC Inverter Package R32 Floor Ceiling Type Unit Notice: Check the above items and adopt the corresponding corrective measures. If the air conditioner continues to function poorly, please stop the air conditioner immediately and contact Gree’s authorized local service center. Ask our professional service staff to check and repair the unit. 5.2 Error Code Warning If abnormal things (for example, awful smell) occur, please stop the unit...
Page 202 DC Inverter Package R32 Floor Ceiling Type Unit Number Error code Error DC fan error Driver out-of-step protection Pfc protection Startup failure Compressor phase-sequence protection Power protection IDU and ODU unmatched 4–way valve switch-over error Driver reset protection Over-current protection Master control and driver communication error Driver module sensor error Driver module high temperature protection...
Page 203: Unit Maintenance
DC Inverter Package R32 Floor Ceiling Type Unit (3) Indicating Lamp of “HEAT”: The indicating lamp will shine when “HEAT” is activated, while it will go out when “HEAT” is deactivated. (4) Indicating Lamp of “TIMER”: The indicating lamp will shine when “TIMER” is activated, while it will go out when “TIMER”...
Page 204 DC Inverter Package R32 Floor Ceiling Type Unit 5.3.1 Clean Air Filter (1) Disassembly method of filter screen and electric box cover How to clean the air filter ① Open the air inlet grille. a) Firstly unfix two buckles on the grille as shown on the picture.
Page 205 DC Inverter Package R32 Floor Ceiling Type Unit (2) At the Start of the Seasonal Use. 1) Check if there is blockage at the inlet or outlet vent of air conditioner. 2) Check if the earth wire has been attached reliably by the skilled serviceman. 3) Check if the exhausted batteries of the wireless controller have been replaced.
Page 206: Notice On Maintenance
DC Inverter Package R32 Floor Ceiling Type Unit conditioner to “ON” status before 8h of operation, to preheat the crankcase of outdoor compressor; (6) Check if the installation of outdoor unit is firm, if not, please contact with Gree appointed maintenance center. 5.3.5 Maintenance at the end of the Using Season (1) Cut off the main power of air conditioner;...
Page 207 DC Inverter Package R32 Floor Ceiling Type Unit avoided. The area around the workspace shall be sectioned off. Ensure that the conditions within the area have been made safe by control of flammable material. 5.4.1.4 Checking for Presence of Refrigerant The area shall be checked with an appropriate refrigerant detector prior to and during work, to ensure the technician is aware of potentially flammable atmospheres.
Page 208 DC Inverter Package R32 Floor Ceiling Type Unit maintenance and service guidelines shall be followed. If in doubt consult the manufacturer’s technical department for assistance. The following checks shall be applied to installations using flammable refrigerants: (1) The charge size is in accordance with the room size within which the refrigerant containing parts are installed;...
Page 209 DC Inverter Package R32 Floor Ceiling Type Unit 5.4.2 Repairs to Sealed Components 5.4.2.1 During repairs to sealed components, all electrical supplies shall be disconnected From the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
Page 210 DC Inverter Package R32 Floor Ceiling Type Unit 5.4.4 Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of ageing or continual vibration from sources such as compressors or fans.
Page 211 DC Inverter Package R32 Floor Ceiling Type Unit 5.4.7 Charging Procedures In addition to conventional charging procedures, the following requirements shall be followed. (1) Ensure that contamination of different refrigerants does not occur when using charging equipment. Hoses or lines shall be as short as possible to minimize the amount of refrigerant contained in them.
Page 212 DC Package R32 Floor Ceiling Type Unit removed from various parts of the system. (6) Make sure that cylinder is situated on the scales before recovery takes place. (7) Start the recovery machine and operate in accordance with manufacturer's instructions. (8) Do not overfill cylinders (No more than 80 % volume liquid charge).
Page 213: After-Sales Services
DC Inverter Package R32 Floor Ceiling Type Unit with leak-free disconnect couplings and in good condition. Before using the recovery machine, check that it is in satisfactory working order, has been properly maintained and that any associated electrical components are sealed to prevent ignition in the event of a refrigerant release.
Page 214 REGULATION (EU) No. 517/2014 - F-GAS The unit contains R32, a fluorinated greenhouse gas with global warming potential (GWP) = 675. Do not release R32 into the atmosphere. 35 1PH Kg. 0,78 = 0,53 Tonn CO 2 equiv. 50 1PH Kg.
Page 215 PACKAGE DCI R32 Wireless Remote Controller Please read this manual carefully before installing and using the air conditioner, and retain for future refer ence. V 01/20...
Page 216 Content Buttons on remote controller ................. Introduction for icons on display screen ..............Introduction for buttons on remote controller............Function introduction for combination buttons ............Operation guide..................... Replacement of batteries in remote controller ............
Page 217: Buttons On Remote Controller
Buttons on remote controller ON/OFF button MODE button FAN button TURBO button ▲/ button button button T-ON / T-OFF button I FEEL button CLOCK button SLEEP button WiFi button button LIGHT button TEMP button Introduction for icons on display screen Set fan speed 、...
Page 218: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status.
Page 219 Introduction for buttons on remote controller Note: ● For preventing cold air, after starting up heating mode, indoor unit will delay 1~5 minutes to blow air (actual delay time is depend on indoor ambient temperature). ● Set temperature range from remote controller: 16~30℃ (61-86°F); Fan speed: auto, low speed, low-medium speed,medium speed, medium-high speed,high speed.
Page 220 Introduction for buttons on remote controller ● When setting T-ON, T-OFF or CLOCK, press "▲" or " " button to adjust time. (Refer to CLOCK, T-ON, T-OFF buttons) When setting T-ON, T-OFF or CLOCK press "▲" or " " button to adjust time. (Refer to CLOCK,T-ON, T-OFF buttons) button Press this button can select left &...
Page 221 Introduction for buttons on remote controller T-ON / T-OFF button ● T-ON button "T-ON" button can set the time for timer on. After pressing this button, " " icon disappears and the word "ON" on remote controller blinks. Press "▲" or "...
Page 222 Introduction for buttons on remote controller CLOCK button Press this button to set clock time. " " icon on remote controller will blink. Press "▲" or " " button within 5s to set clock time. Each pressing of "▲" or " "...
Page 223 Introduction for buttons on remote controller LIGHT button Press this button to turn off display light on indoor unit. " " icon on remote controller disappears. Press this button again to turn on display light. " " icon is displayed. TEMP button By pressing this button, you can see indoor set temperature, indoor ambient temp- erature or outdoor ambient temperature on indoor unit’s display.
Page 224: Function Introduction For Combination Buttons
Function introduction for combination buttons Energy-saving function Under cooling mode, press "TEMP" and " CLOCK" buttons simultaneously to start up or turn off energy-saving function. When energy-saving function is started up, "SE" will be shown on remote controller, and air conditioner will adjust the set temperature automatically according to ex-factory setting to reach to the best energy-saving effect.
Page 225: Operation Guide
Operation guide After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner. Press "MODE" button to select your required mode: AUTO, COOL, DRY, FAN, HEAT. Press "▲" or " " button to set your required temperature. (Temperature can’t be adjusted under auto mode).
Page 226 www.argoclima.com...
Page 276 PACKAGE DCI R32 Wireless Remote Controller Please read this manual carefully before installing and using the air conditioner, and retain for future refer ence. V 01/20...
Page 277 Content Buttons on remote controller ................. Introduction for icons on display screen ..............Introduction for buttons on remote controller............Function introduction for combination buttons ............Operation guide..................... Replacement of batteries in remote controller ............
Page 278: Buttons On Remote Controller
Buttons on remote controller ON/OFF button MODE button FAN button TURBO button ▲/ button button button T-ON / T-OFF button I FEEL button CLOCK button SLEEP button WiFi button button LIGHT button TEMP button Introduction for icons on display screen Set fan speed 、...
Page 279: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status.
Page 280 Introduction for buttons on remote controller Note: ● For preventing cold air, after starting up heating mode, indoor unit will delay 1~5 minutes to blow air (actual delay time is depend on indoor ambient temperature). ● Set temperature range from remote controller: 16~30℃ (61-86°F); Fan speed: auto, low speed, low-medium speed,medium speed, medium-high speed,high speed.
Page 281 Introduction for buttons on remote controller ● When setting T-ON, T-OFF or CLOCK, press "▲" or " " button to adjust time. (Refer to CLOCK, T-ON, T-OFF buttons) When setting T-ON, T-OFF or CLOCK press "▲" or " " button to adjust time. (Refer to CLOCK,T-ON, T-OFF buttons) button Press this button can select left &...
Page 282 Introduction for buttons on remote controller T-ON / T-OFF button ● T-ON button "T-ON" button can set the time for timer on. After pressing this button, " " icon disappears and the word "ON" on remote controller blinks. Press "▲" or "...
Page 283 Introduction for buttons on remote controller CLOCK button Press this button to set clock time. " " icon on remote controller will blink. Press "▲" or " " button within 5s to set clock time. Each pressing of "▲" or " "...
Page 284 Introduction for buttons on remote controller LIGHT button Press this button to turn off display light on indoor unit. " " icon on remote controller disappears. Press this button again to turn on display light. " " icon is displayed. TEMP button By pressing this button, you can see indoor set temperature, indoor ambient temp- erature or outdoor ambient temperature on indoor unit’s display.
Page 285: Function Introduction For Combination Buttons
Function introduction for combination buttons Energy-saving function Under cooling mode, press "TEMP" and " CLOCK" buttons simultaneously to start up or turn off energy-saving function. When energy-saving function is started up, "SE" will be shown on remote controller, and air conditioner will adjust the set temperature automatically according to ex-factory setting to reach to the best energy-saving effect.
Page 286: Operation Guide
Operation guide After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner. Press "MODE" button to select your required mode: AUTO, COOL, DRY, FAN, HEAT. Press "▲" or " " button to set your required temperature. (Temperature can’t be adjusted under auto mode).
Page 287 www.argoclima.com...
