PORTABLE AIR CONDITIONER (LOCAL)
EVAN PLUS
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance work.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Store these instructions in a safe place for future reference.
V 01/22
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVAN PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo EVAN PLUS

Summary of Contents for Argo EVAN PLUS

  • Page 1 PORTABLE AIR CONDITIONER (LOCAL) EVAN PLUS OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance work. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Store these instructions in a safe place for future reference.
  • Page 2 Appliance is filled with flammable gas R290. Before installing and using the appliance, read the owner manual. Before installing the appliance, read the installation manual. Any repairs you need, contact the nearest authorized Service Centre and strictly follow manufacturer’s Service Manual. The Refrigerant R290 ...
  • Page 3 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a local air conditioner designed for domestic use.  Only use this air-conditioner as described in this manual.  Ensure that the required voltage and frequency (220-240V/50 Hz) match the available power source. ...
  • Page 4  Do not install the air conditioner in rooms where it may receive water splashes (e.g. laundry rooms, bathrooms) or in humid environments.  This air conditioner can be used by children of 8 years of age or older, and by persons with reduced physical, sensory and mental abilities or who lack the necessary know-how and experience to operate it, if under the supervision or instruction of a person responsible for their safety, so that they are fully aware of the attendant risks.
  • Page 5  Make sure the power outlet is intact, and after plugging the power cord into the outlet, check that the cord is placed where it cannot be walked on to prevent it from being accidentally pulled out of the outlet. PRECAUTION! ...

  • Page 6: Description Of The Appliance

     Do not use insecticides, oils, detergents or spray paints near the appliance; do not use aggressive chemical detergents to clean the casing: this may damage the finish and colour.  Close all open windows to maximise air conditioning efficiency. The manufacturer will not be held liable if safety and accident prevention rules are not observed.

  • Page 7: Appliance Start-Up

    Min/max operating limits (internal temperature) Cooling: 16 °C DB / 35 °C DB Dehumidification: 16 °C DB / 35 °C DB Heating: 7°C DB / 35°C DB Cooling mode room temperature adjustment range: 16 °C DB / 31 °C DB PRE-OPERATING CHECKS AND OPERATIONS Position the product vertically on a flat and stable surface, as close as possible to a window and at least 50 cm from walls or other nearby obstacles.
  • Page 8 USE WITH END FITTING FOR WINDOW Connect the flat fitting to the hose, extend the hose as far as necessary for reaching the outside and it connect to the back of the air conditioner. Connect the round window fitting (1) to the end of the hose then the end fitting for the window (2) Open the windows and lock one of the two leaves with the handle.

  • Page 9: How To Use The Appliance

    HOW TO USE THE APPLIANCE This appliance can be used for cooling, heating, dehumidifying and ventilating. When switching between modes, the fan continues to rotate but the compressor stops: the compressor will start after 3 minutes. This delay protects the compressor from potential damage. Cooling, Fan, Heating Dehumidifying THE DISCHARGE TUBE MUST ALWAYS BE CONNECTED to the appliance: the only exception is when the...
  • Page 10 4. VENTILATION MODE (FAN ONLY)  Press the MODE button until the Fan icon appears.  In this mode, the fan speed can be adjusted.  The temperature cannot be adjusted. HOW TO ELIMINATE CONDENSATE This appliance automatically vaporizes the condensation in cooling. When the air conditioner operates in Cooling, it is not necessary to have continuous condensate drainage;...

  • Page 11: Remote Control Operation

    REMOTE CONTROL OPERATION 1. Swipe to open the cover in the direction indicated by the arrow. 2. Insert the alkaline batteries (type AAA, LR03 / 1,5V - supplied) compliant with the Battery Directive no.2006 / 66 / EC and amendments by Directive 2013/56 / EC into the remote control, respecting the indicated polarity.
  • Page 12 FOR OPTIMUM OPERATION OF THE REMOTE CONTROL, ADDRESS THE TRANSMITTER HEAD TOWARDS THE RECEIVER LOCATED ON THE AIR CONDITIONER. SIGNAL TRANSMITTER DISPLAY A. Mode indicator: COOL, FAN, DRY B. Temperature and time C. Sleep on/off D. Speed setting E. Display timer and temperature 1.

  • Page 13: Safety Functions

    (3) FAN SPEED ADJUSTMENT BUTTON Press this button when the appliance is switched on for adjusting the ventilation speed in cooling or heating mode High -> Medium (Med) -> Low The fan speed cannot be adjusted in DRY mode and is fixed to low speed. (4)(6) BUTTONS + - FOR TEMPERATURE AND TIMER ADJUSTMENT The temperature can be adjusted to between 16 °C and 31 °C.

  • Page 14: Care And Maintenance

    AUTOMATIC DEFROSTING When it works in heating, there is a risk that the ice will form on the battery: in this case the air conditioner stop working, to melt the ice and then starts again. CARE AND MAINTENANCE WARNING! Prior to carrying out any cleaning or maintenance, unplug the unit from the power socket. 1.
  • Page 15 18 ºC for the cooling mode, and above 10 ºC for dehumidification mode. REGULATION (EU) No. 517/2014 – F-GAS EVAN PLUS The unit contains R290, a natural greenhouse gas with global warming potential (GWP) = 3 - Kg. 0,21 = 0,00063 Tons CO equiv.
  • Page 16 Specialist’s Manual Aptitude requirement for maintenance man (repairs. should be done only be specialists). a) Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specifìcation.
  • Page 17  Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. lf a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with. lf the fault cannot be corrected immediately but it is necessary to continue operation, an adequate temporary solution shall be used.
  • Page 18 • open the circuit by cutting or brazing. The refrigerant charge shall be recovered into the correct recovery cylinders. For appliances containing flammable refrigerants, the system shall be flushed with OFN to render the unit safe. This process may need to be repeated several times. Compressed air or oxygen shall not be used for purging refrigerant systems.
  • Page 19 flammable refrigerants. In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition. Before using the recovery machine, check that it is in satisfactory working order, has been properly maintained and that any associated electrical components are sealed to prevent ignition in the event of a refrigerant release.
