Audio Inputs

The Audio Inputs page allows you to name and enable the audio inputs you want to record. The exacqVision
System ships with the audio input positions disabled due to legal restraints on audio recording in some
jurisdictions. You may want to seek legal guidance prior to recording any audio inputs.
1. Enter a name for the audio input channel.
2. Select Enabled to enable audio recording on the input.
3. Repeat this process until all audio inputs have been named, and then click the Apply button.
4. Click Listen to verify the audio input connected to a channel. This is sometimes helpful when assigning
names to multiple audio inputs.
5. The Recording Mode column shows the recording mode selected for the audio input on the Schedule
page.
