PTZ Configuration

This section discusses the PTZ Control section of the Camera Settings page, which allows you to identify a camera
as a PTZ device and configure PTZ presets.
1
1. Select the camera's COM port from the Serial Port drop-down list. This port is configured on the Serial
Ports page.
2. Select the camera's Address as configured on the camera hardware. (The protocol is automatically
displayed based on the Serial Port selected.)
3. The Settings button under PTZ opens the PTZ Settings window, which is described on the following page.
4. To enable digital PTZ functions on the Live and Search pages, select the Digital checkbox. This is available
even if the camera is not mechanically capable of PTZ functions.
5. The Settings button under Digital PTZ opens the Digital PTZ Settings window, which is described after the
Analog PTZControl description.
NOTE: When you create a PTZ preset, it is initially named New_preset_1 by default. Then, if a PTZ preset named
New_preset_1 exists, the next PTZ preset is named New_preset_2. However, if you create a new digital preset, it
will also be named New_preset_1, regardless of whether there is already a PTZ preset with that name. To avoid
having both a PTZ preset and a digital preset with the same name, make sure you enter a unique name for each
preset that you create.
