Oven Control Functions

For satisfactory use of your oven, become familiar with the various features and functions of the oven.
1 2
4 5
8
7
10
Oven Control Keypads
1. Timer - Used to set or cancel Timer.
2. Add 1 Minute - Used to add additional minutes to Timer.
3. Cook Time- Used to enter the length of the cook time
desired.
4. Delay Start - Used with Bake, Conv Bake, Conv Convert
and Flex Clean functions to program a delay start time
or delay start self-cleaning cycle.
5. Slow Cook - Used to select the Slow Cook function.
6. Warm - Used to set the Warm & Hold function.
7. Preheat - Used to pre-condition the oven.
8. Cakes & Breads - Used to select the cakes & breads.
9. Conv Convert - Used to select the Convection Convert
function.
10. Clean - Used to set a 2 to 4 hours Self-Clean cycle.
Minimum & maximum

control settings

All of the features listed below have
minimum and maximum time or
temperature settings that may be
entered into the control. An ENTRY
acceptance beep will sound each
time a control pad is touched (the
Oven Lockout pad is delayed 3
seconds).
An ENTRY ERROR tone (3 short
beeps) will sound if the entry of the
temperature or time is below the
minimum or above the maximum
settings for the feature.
3
6
9
11
16
Feature
PreHeat
Bake
Broil
Timer
Flex Clean
Conv Bake
Conv Convert
Conv Roast
Slow Cook
Cook Time
Delay Time 12 Hr.
Delay Time 24 Hr.
12 13 14
17
18
11. Conv Bake - Used to select the Convection Bake feature.
12. Bake - Used to enter the normal bake feature.
13. START - Used to start oven functions.
14. Broil - Used to select Broil feature.
15. Conv Roast - Used to select the Convection Roast
function.
16. Oven Light - Used to turn oven light ON and OFF.
17. STOP - Used to cancel any oven function previously
entered except Clock and Timer.
18. Clock Set - Used to set the time of day.
19. Oven Lockout - Used to lock oven functions and door.
0 thru 9 number - Used to enter temperature and times.
Min. Temp. or time
170°F/77°C
170°F/77°C
400°F/205°C
0:01 Min.
2 hours
170°F/77°C
170°F/77°C
170°F/77°C
Lo (225°F/180°C)
0:01 Min.
1:00 Hr./Min.
0:00 Hr./Min.
14
15
Max. temp. or time
550°F/288°C
550°F/288°C
550°F/288°C
11:59 Hr./Min.
4 hours
550°F/288°C
550°F/288°C
550°F/288°C
Hi (225°F/180°C)
11:59 Hr./Min.
12:59 Hr./Min.
23:59 Hr./Min.
19
